Axometrics AXOSTEP-APM-65 Installation Manual

Axostep panel mapper for 65’’ horizontal samples
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Axometrics, Inc.
103 Quality Circle, Suite 215
Huntsville, AL 35806
Phone: (256) 704-3332
Fax: (256) 971-2073
E-Mail: info@axometrics.com
Website: http://www.axometrics.com
AXOSTEP-APM-65
AxoStep Panel Mapper
For 65'' Horizontal Samples
INSTALLATION MANUAL
©2015 Axometrics, Inc. All rights reserved.
AxoStep™, AxoView™, Axometrics™ and the Axometrics logo are all trademarks of Axometrics, Inc.
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AXOSTEP-APM-65 and is the answer not in the manual?

Questions and answers

Summary of Contents for Axometrics AXOSTEP-APM-65

  • Page 1 Huntsville, AL 35806 Phone: (256) 704-3332 Fax: (256) 971-2073 E-Mail: info@axometrics.com Website: http://www.axometrics.com AXOSTEP-APM-65 AxoStep Panel Mapper For 65’’ Horizontal Samples INSTALLATION MANUAL ©2015 Axometrics, Inc. All rights reserved. AxoStep™, AxoView™, Axometrics™ and the Axometrics logo are all trademarks of Axometrics, Inc.

  • Page 2: Table Of Contents

    Contents Caution ............................. 3 Introduction ..........................1 Unpacking Instructions ......................2 Instructional Crate Disassembly ..................2 Moving the machine from the crate to installation site ............ 2 Hardware Removal ......................2 Granite Shipping Brackets ....................4 Level the machine ......................5 Operator Station ........................

  • Page 3: Caution

    Caution Take precaution NOT to do any of the following When lifting the machine, do NOT apply any pressure to the outer aluminum profile wall. Only lift the machine by the inner steel frame. Refer to figure A: Fig. A Aluminum profile Steel frame Do NOT at any time clean the Cal-Vis-2 or the linear rails.

  • Page 4: Introduction

    This manual discusses the detailed unpacking and setup for the AXOSTEP-APM-65H Panel Mapper System. Please read this entire manual before attempting to operate this machine. See the AXOSTEP- APM-65H Hardware Manual for installation procedures not covered in this manual. Contact Axometrics if you need assistance.

  • Page 5: Unpacking Instructions

    Unpacking Instructions Instructional Crate Disassembly 1. Remove the bolts from the top of the crate. 2. Remove the top panel. 3. Remove the top support braces on top of the machine. 4. Proceed to remove the rest of the walls. 5.
  • Page 6 Fig. 2 Shipping Bolt (QTY 3) Fig. 3 Hardware Dongle on Back...

  • Page 7: Granite Shipping Brackets

    Fig. 4 Hardware Dongle on Front Fig.5 Fig. 6 Replace bolts in turret once Take bolt out and replace with red bracket is removed bumper Granite Shipping Brackets 1. Loosen the shipping bracket bolt and the bolts holding the bracket. Refer to figure 7. 2.

  • Page 8: Level The Machine

    Fig.7 Fig.8 Move the brackets (QTY 6) away from Loosen the lateral pusher (QTY 8) until it is the granite no longer touching the granite Fig.9 Vertical Pusher Set Screw Loosen the set screw first then lower the vertical pusher down Level the machine 1.
  • Page 9 Fig. 10 Leveling legs...

  • Page 10: Operator Station

    Operator Station Mounting the monitor 1. Route the monitor cables through the cable hole on the front panel and plug them in the monitor. 2. Now using the 4 screws in the back of the monitor, mount the monitor to the panel. Refer to figures 11 and 12.

  • Page 11: Mounting The Keyboard Tray

    Fig.13 Signal tower Connector Mounting the Keyboard Tray 1. Install the keyboard just below the monitor at the bottom of the panel. Refer to figure 14. Fig.14 Installing the Mouse and Keyboard Pull the mouse and key board cables through the hole on the monitor panel. 2.

  • Page 12: Install Focus Emo-Si Cable To Din Panel

    Fig.15 Fig. 16 Beta Duct Route Cables USB Connectors Install Focus EMO-SI Cable to DIN Panel On systems with Focus stages, install the Focus EMO-SI cable running from the Focus MCU to the Din Panel. Refer to SCHEM-0203A and LAYOUT-0100C in the wiring diagrams package. First, install the provided wire labels (W2.9 for red, DC0V for black) and krimp the provided ring terminals onto the two wires.
  • Page 13 Fig 18 Connect Connect W2.9 DC0V from from FOCUS FOCUS EMO-SI Here EMO-SI Here...

  • Page 14: Tunable Light Source

    Tunable Light Source Light Source Installation 1. To remove the Tunable Light Source (TLS) there are mounting bolts that are holding the TLS in the drawer. Remove the four bolts with a 5mm Allen Wrench. Refer to figure 19. 2. Once you have installed the Lamp, slide the TLS in the drawer. 3.

  • Page 15: Pneumatic And Power

    Refer to figures 20 and 21. 2. The regulators have been set to 0.5 MPa at the Axometrics facility. However, if pressure adjustments need to be made, raise the regulator knob and turn CW or CCW to raise or lower the pressure.

  • Page 16: Electrical Input

    Electrical Input 1. Connect the main power cables to the top sides of the terminal blocks. Refer to figure 24. Fig. 24 Power Input (L, N, G)

  • Page 17: Miscellaneous Items

    Miscellaneous Items Rail Assembly 1. Install the Rail Hanger Bracket on the right side of the system. Attach the ends on the rails with M3x8 flat socket cap screws and hang the rails on the hanger bracket. Refer to figure 25. 2.
