Tecnoalarm TP8-64 BUS Installer Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
TP8-64 BUS
TP8-64 BUS MET
864 ZONES
CONTROL PANEL
INSTALLER MANUAL
Release:
Update:
Language
FW version :
2.0
September 2009
English
1.5

Advertisement

loading
Need help?

Need help?

Do you have a question about the TP8-64 BUS and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Tecnoalarm TP8-64 BUS

  • Page 1 TP8-64 BUS TP8-64 BUS MET 864 ZONES CONTROL PANEL INSTALLER MANUAL Release: Update: September 2009 Language English FW version :...
  • Page 2 The features of the control panel can be subject to change without notice. Unauthorized reproduction or distribution of this manual, or any portion of it, on any device and in any form, is prohibited. The contents of this manual may be subject to change without notice. Installer Manual - TP8-64 BUS...
  • Page 3 CONFORMITY Hereby, Tecnoalarm srl declares that the present equipment is in compliance with the essential requirements and other relevant provisions of the R&TTE 1999/05/EC directive. The declaration of conformity is available on the website: www.tecnoalarm.com. TP8-64 BUS - Installer Manual...
  • Page 4 Installer Manual - TP8-64 BUS...
  • Page 5 NOTES FOR ALL INPUT EXPANSIONS 2A-15 2A.9 DIP-SWITCH SETTINGS 2A-15 2A.10 CASING 2A-15 OUTPUT EXPANSION MODULES 2B.1 OUTPUT EXPANSION WITH LOGIC OUTPUTS ESP32-OCN 2B-1 2B.1.1 Electronic board 2B-1 2B.1.2 Casing 2B-1 2B.1.3 Installation 2B-2 TP8-64 BUS - Installer Manual Index...
  • Page 6 433MHz section 2G-2 2G.1.4 868MHz section 2G-2 2G.1.5 Casing 2G-2 2G.2 RX300/433868 WIRELESS RECEIVER 2G-3 2G.2.1 Electronic board 2G-3 2G.2.2 Dip-switch settings 2G-4 2G.2.3 Casing 2G-4 2G.3 TX240-3 WIRELESS KEY 2G-5 2G.3.1 Functioning keys 2G-5 Index Installer Manual - TP8-64 BUS...
  • Page 7 Connection of the PC to the control panel 4-39 4.7.2 Upload (send) configuration 4-39 4.7.3 Indicators of system configuration coherence 4-42 4.7.4 Download (receive) configuration 4-43 PROGRAMMING BY CONSOLE PRELIMINARY REMARKS PROGRAMMING SEQUENCE ZONE CONFIGURATION TP8-64 BUS - Installer Manual Index...
  • Page 8 Programming of the standard user codes 5-32 5.18 PROGRAMMING OF THE KEYS 5-33 5.18.1 Learning of the keys 5-33 OTHER SETTINGS - WHEN REQUIRED 5.19 ACTIVATION/DEACTIVATION OF THE REMOTE CONTROLS 5-34 5.20 EXCLUSION OF MODULES/ZONES 5-34 5.21 TEST 5-35 Index Installer Manual - TP8-64 BUS...
  • Page 9 CONTROL BY TP SK6N KEY READER WITH MINI KEYPAD 7.1.1 Arming 7.1.2 Disarming 7.1.3 By-pass 7.1.4 Release of panic alarm CONTROL THROUGH TP SKN INTERFACE FOR ELECTRONIC KEYS AND ATPK KEY READERS 7.2.1 Arming 7.2.2 Disarming 7.2.3 By-pass SPECIAL OPERATING CONDITIONS TP8-64 BUS - Installer Manual Index...
  • Page 10 7-14 7.5.4 Learning 7-14 TECHNICAL SPECIFICATIONS TP8-64 BUS CONTROL PANEL TP8-64 BUS MET CONTROL PANEL INTERNAL INPUT EXPANSION MODULE 8.3.1 Expansion module with 4 inputs SERIAL INPUT EXPANSIONS 8.4.1 Expansion module with 8 inputs and power supply (SPEED ALM8 PL) 8.4.2...
  • Page 11 FIRMWARE UPGRADE VOCABULARY UPGRADE UPLOAD OF THE OPENING MESSAGE B-12 APPENDIX C - CODE MANAGEMENT MODIFICATION OF CODE BY USER C.1.1 Procedure of modification of the codes MODIFICATION OF CODE BY MASTER CODE INSTALLER CODE TP8-64 BUS - Installer Manual Index...
  • Page 12 Index Installer Manual - TP8-64 BUS...
  • Page 13 CASING ABS casing TP8-64 BUS - Size (L x H x D): 300 x 390 x 100mm Metal casing TP8-64 BUS MET - Size (L x H x D): 455 x 365 x 110mm Battery bay (12V - 7Ah) INPUTS Maximum 64 zone inputs: •...
  • Page 14 • complete voice description of the active alarms Digital transmissions using the following formats: • registered formats: SLOW, DTMF, FSK (CESA, SIA) • Tecnoalarm formats: FAST (FSK 1200 Baud compatible) WIRELESS MODULES (OPTIONS) / WIRELESS SECTION Supervision and antimasking control Control of max.
  • Page 15 Verification of the presence and the version of the vocabulary Sounding test of the wired sirens (indoor and outdoor) and the wireless sirens. REMOTE PROGRAMMING AND MONITORING TP8-64 BUS can be entirely programmed and monitored via telephone line using the Tecnoalarm modem and programming and monitoring software. ALARM DEVICES WARNING Consider that the alarm devices (sirens, logic outputs, telephone transmitters) have to be programmed.
  • Page 16 General features Installer Manual - TP8-64 BUS...
  • Page 17 DEVELOPMENT (OPTION) Wireless consoles (max. 4) Wireless control units (max. 32) Wireless sirens (max. 4) TP8-64 BUS MET The TP8-64 BUS MET control panel is the same as TP8-64 BUS but: CPU board including: • 3A power supply TP8-64 BUS MET Battery of max.
  • Page 18 Power supply (battery + separate transformer 230V AC - 30V approx. 40VA) Serial bus (connection of serial bus RS485 + RS232 programming interface and a PC) Connectors for plug-in cards (vocabulary, input expansion) Telephone section Terminals Hardware Installer Manual - TP8-64 BUS...
  • Page 19 TP8-64 BUS MET The same as a TP8-64 BUS but: PROTECTION The detector power supply outputs are protected by a 315mA rapid fuse COMPOSITION Power supply (battery + separate transformer 230V AC - 28V approx. 60VA ) TP8-64 BUS - Installer Manual...
  • Page 20 To fix the plastic casing to the wall use 2 plastic dowels (diameter 8mm + apposite screws) and introduce them into the holes A and B as indicated in the fig. 1 FIG. 1 Hardware Installer Manual - TP8-64 BUS...
  • Page 21 To fix the metal casing to the wall use 4 plastic dowels (diameter 8mm + apposite screws) and introduce them into the holes A, B, C, D as indicated in the fig. 2 FIG. 2 TP8-64 BUS - Installer Manual Hardware...
  • Page 22 The control panel is not equipped with a mains switch. Thus, it is compulsory installing a bipolar mains switch (230V~) next to the control panel. Being subject to contact pressure, the power cord must in no case be connected by soft welding to the terminals. Hardware Installer Manual - TP8-64 BUS...
  • Page 23 The power cord (double insulation) is introduced into the casing through an apposite plastic passing tube as indicated by n. 5 (see fig.1) which is included. The power cord is not icluded. Fig. 1 TP8-64 BUS - Installer Manual Hardware...
  • Page 24 The control panel is not equipped with a mains switch. Thus, it is compulsory installing a bipolar mains switch (230V~) next to the control panel. Being subject to contact pressure, the power cord must in no case be connected by soft welding to the terminals. Hardware Installer Manual - TP8-64 BUS...
  • Page 25 (red +, black -). WARNING If mains connection is missing, the control panel will not work automatically if powered by battery only. For this, insert the jumper JP7 for some seconds, then remove it again. TP8-64 BUS - Installer Manual Hardware...
  • Page 26 13.8 V to supply RS485 serial bus The CPU board provides to control the good functioning of the following items: Presence-absence of the voltage of the mains (230V AC) Présence-absence of the battery voltage Hardware Installer Manual - TP8-64 BUS 2-10...
  • Page 27 = line switched to the control panel (devices connected to the TEL terminals are inhibited) = line not switched to the control panel LED D29 yellow Blinking = follows the rings = line on-hook TP8-64 BUS - Installer Manual Hardware 2-11...
  • Page 28 * NC (0 Ohm) - NO (superior to 2K Ohm) - BIL (2K Ohm … 4K Ohm) - B24 (2K Ohm … 4K Ohm) default settings WARNING As far as the logic outputs are concerned, the values quoted refer to the normal status, functioning logic may however be inverted. Hardware Installer Manual - TP8-64 BUS 2-12...
  • Page 29 SIREN OUTPUTS There are a series of terminals for the connection of the indoor and outdoor sirens auxiliary and self-powered. The terminal +14V provides the battery recharge voltage for the self-powered sirens. TP8-64 BUS - Installer Manual Hardware 2-13...
  • Page 30 The logic outputs OUT1+ and OUT2- are programmable, i.e. their functioning logic may be inverted: Normal polarity Reversed polarity OUT1+ stand-by: high impedance OUT1+ stand-by: +13.8V alarm: +13.8V alarm: high impedance OUT2- stand-by: high impedance OUT2- stand-by: 0V alarm: alarm: high impedance Hardware Installer Manual - TP8-64 BUS 2-14...
  • Page 31 * NC (0 O hm ) - NO (su p e rio r to 2K O hm ) - BIL (2K O h m … 4K O h m ) - B24 (2K O h m … 4K O h m ) TP8-64 BUS - Installer Manual...
  • Page 32 Hardware Installer Manual - TP8-64 BUS 2-16...
  • Page 33 The inputs manage the RDV and Zone Bus detectors. Transformer on separate base ABS casing - size (L x H x D): 345 x 285 x 90mm Design by 1 combined antiopening and antidetachment tamper switch TP8-64 BUS - Installer Manual Input expansion modules 2A-1...
  • Page 34 TRANSFORMER TA14/3 Mains input section (primary winding): 230V~ (red) Output section (secondary winding): 30V~ / 1,3A (blue) Frequency: 50/60Hz Power: 40VA Primary protection fuse: T 200mA Input expansion modules Installer Manual - TP8-64 BUS 2A-2...
  • Page 35 Input RS485 serial bus RS485 serial bus Output * NC (0 Ohm ) - NA (supe rior to 2000 Ohm ) - BIL (2000...4000 Ohm ) - B24 (2000…4000 Ohm ) TP8-64 BUS - Installer Manual Input expansion modules 2A-3...
  • Page 36 The inputs manage the RDV and Zone Bus detectors. ABS casing C90 or C100P (option) 2A.2.1 ELECTRONIC BOARD WARNING The jumper JP4 must be inserted only on the last device of the serial bus RS485. Input expansion modules Installer Manual - TP8-64 BUS 2A-4...
  • Page 37 Output * NC (0 Ohm ) - NO (Supe rior to 2K Ohm s) - BIL (2K Ohm s … 4K Ohm s) - B24 (2K Ohm s … 4K Ohm s) TP8-64 BUS - Installer Manual Input expansion modules...
  • Page 38 The inputs manage the RDV and Zone Bus detectors. Plastic casing C90 or C100P (option) 2A.3.1 ELECTRONIC BOARD WARNING The jumper JP6 must be inserted on the last device of the serial bus RS485 only. Input expansion modules Installer Manual - TP8-64 BUS 2A-6...
  • Page 39 INPUT EXPANSION SPEED 8 STD The expansion is composed of: Electronic board with 8 inputs The inputs DO NOT manage the RDV and Zone Bus detectors. Plastic casing (option) 2A.4.1 ELECTRONIC BOARD TP8-64 BUS - Installer Manual Input expansion modules 2A-7...
  • Page 40 Input RS485 serial bus RS485 serial bus Output * NC (0 Ohm ) - NA (supe rior to 2000 Ohm ) - BIL (2000...4000 Ohm ) - B24 (2000…4000 Ohm ) Input expansion modules Installer Manual - TP8-64 BUS 2A-8...
  • Page 41 Electronic board with 8 inputs and 1.8A power supply Transformer on separate base ABS casing - Size (L x H x D): 345 x 285 x 90mm 1 combined antiopening and antidetachment tamper switch TP8-64 BUS - Installer Manual Input expansion modules 2A-9...
  • Page 42 F1 of 200mA. The transformer kit is composed of: Input section (primary winding): 230V AC (red) Output section (secondary winding): 30V/1.3A (blue). Frequency: 50/60Hz Power: 40VA Fuse: F1 T 200mA Input expansion modules Installer Manual - TP8-64 BUS 2A-10...
  • Page 43 To connect a detector type MINIEXPLORER DOPPLER BUS having two separates parties, always use the two nearest inputs began to the impaire position (ex: inputs Z1 and Z2, or Z5, Z6 but never Z2 and Z3). TP8-64 BUS - Installer Manual Input expansion modules 2A-11...
  • Page 44 To connect a detector type MINIEXPLORER DOPPLER BUS having two separates parties, always use the two nearest inputs began to the impaire position (ex: inputs Z1 and Z2, or Z5 and Z6 but never Z2 and Z3). Input expansion modules Installer Manual - TP8-64 BUS 2A-12...
  • Page 45 INPUT EXPANSION MODULE SPEED 4 PLUS The expansion module is composed of: Electronic board 4+4 inputs with memory cards Eeprom recording events ABS casing C90 or C100P (optional) 2A.7.1 ELECTRONIC BOARD TP8-64 BUS - Installer Manual Input expansion modules 2A-13...
  • Page 46 Se nsor bus 13.8V DC Output RS485 serial bus power supply GND (earth) Output Input Sensor bus Sensor bus Output Synchronization MINIEXPLORER BUS Synchronization Output * = de fa ult se ttings Input expansion modules Installer Manual - TP8-64 BUS 2A-14...
  • Page 47 1 micro against wrenching + 1 micro against opening C100P design by Dimensions (L x H x D): 260 x 160 x 60mm Tamper: 1 combined micro against wrenching and opening TP8-64 BUS - Installer Manual Input expansion modules 2A-15...
  • Page 48 Input expansion modules Installer Manual - TP8-64 BUS 2A-16...
  • Page 49 The output expansion module ESP32-OCN permits to extend the outputs of the control panel providing supplementary system status signaling. The output expansion module must be connected via serial bus RS485 and configurated by dip-switch SW1. 2B.1.1 ELECTRONIC BOARD 2B.1.2 CASING TP8-64 BUS - Installer manual Output expansion modules 2B-1...
  • Page 50 The SW1 dip-switch permits programming of the address of the modules on serial bus. There must not be two devices with the same address. WARNING The control panel manage max. 14 input expansion modules, therefore only the addresses from 1 to 14 are valid. Output expansion modules Installer Manual - TP8-64 BUS 2B-2...
  • Page 51 Remote control active LED off Remote control deactived STAND-BY PROGRAMS STATUS LED on Program disarmed (stand-by) LED off Program armed ALARM PROGRAM STATUS LED on Program alarm active LED off Program in stand-by TP8-64 BUS - Installer manual Output expansion modules 2B-3...
  • Page 52 ADDRESS 3 GENERAL ALARMS LED on Alarm or status active LED off Alarm or status not active Output expansion modules Installer Manual - TP8-64 BUS 2B-4...
  • Page 53 Zone tamper alarm, open zone, zone trouble, prealarm LED on Alarm memory, tamper memory LED off Zone closed ADDRESSES 6 AND 7 ZONE ALARM OR TAMPER ALARM STATUS LED on Alarm active LED off No alarme TP8-64 BUS - Installer manual Output expansion modules 2B-5...
  • Page 54 Output expansion modules Installer Manual - TP8-64 BUS 2B-6...
  • Page 55 10 seconds. LINE LINE DISTURBED Interferences or serial bus is badly connected. DISTURBED The diagnostics are repeated approx. every 10 seconds alternately in Italian, French, English, Spanish and German. TP8-64 BUS - Installer Manual Console 2C-1...
  • Page 56 The SW1 dip-switch permits programming of the address of the modules on serial bus. There must not be two devices with the same address. WARNING The control panel manage max. 14 input expansion modules therefore only the addresses from 1 to 14 are valid. Console Installer Manual - TP8-64 BUS 2C-2...
  • Page 57 The semitransparent label once you have written the program names on it must be delicately inserted by the slit in the lower part of the console, just above the hinges of the keypad protection lid. TP8-64 BUS - Installer Manual Console 2C-3...
  • Page 58 Console Installer Manual - TP8-64 BUS 2C-4...
  • Page 59 KEYPOINTS TP8-64 BUS can be controlled by a total of 15 keypoints. Among the keypoints count all the secondary control units, i.e.: Electronic keypad TP SDN Reader of electronic keys with mini keypad TP SK6N Interface for electronic keys TP SKN 2D.1...
  • Page 60 6 programs with electronic key. TP SK6N is composed of a key reader for electronic keys and a keypad with 9 function keys. It has to be connected via serial bus RS485. WARNING If all the LED are blinking, the serial bus is missing or connected incorrectly. Keypoints Installer Manual - TP8-64 BUS 2D-2...
  • Page 61 The interface for electronic keys comprises a total of 4 key readers connected via serial bus and permit the control of the first 3 programs with electronic keys MPKEY. The interface is to be connected via serial bus RS485. Keypoints TP8-64 BUS - Installer Manual 2D-3...
  • Page 62 If all the LED are blinking, the serial bus is missing or connected incorrectly. 2D.3.2 TAMPER PROTECTION OF THE KEY READERS It is recommended to mount the key readers inside special tamper protected casings. Keypoints Installer Manual - TP8-64 BUS 2D-4...
  • Page 63 The SW1 dip-switch permits programming of the address of the modules on serial bus. There must not be two devices with the same address. WARNING The control panel manage max. 14 input expansion modules therefore only the addresses from 1 to 14 are valid. Keypoints TP8-64 BUS - Installer Manual 2D-5...
  • Page 64 Keypoints Installer Manual - TP8-64 BUS 2D-6...
  • Page 65 The connection with the PC is made by means of a standard 9-wires serial cable whereas for the connection with the control panel a 10-wires TTL telephone cable is used. WARNING Connect the programming interface to the control panel first, and only then to the PC. Programming interfaces TP8-64 BUS - Installer Manual 2E-1...
  • Page 66 9-wires serial cable. For the connection with the control panel TP16-256 a 10-wires TTL telephone cable is used. The other ports are reserved for the connection of different types of Tecnoalarm devices. Programming interfaces Installer Manual - TP8-64 BUS...
  • Page 67 If the button has been pressed unwillingly, to return to normal functioning without losing firmware programming of the control panel, press S1 again. The PROG led is switched off. Programming interfaces TP8-64 BUS - Installer Manual 2E-3...
  • Page 68 SPEED RS485. The jumpers W1 to W4 and W6 are reserved to the Tecnoalarm staff and must not be used. They must all be removed. Consider that an improper use of the jumpers may cause malfunctioning of the serial bus RS485.
  • Page 69 2E.3.2 CASING WARNING The serial bus extension module SPEED RS485 has to be mounted inside the casing TKBOX/A using the plastic spacers included. Programming interfaces TP8-64 BUS - Installer Manual 2E-5...
  • Page 70 Programming interfaces Installer Manual - TP8-64 BUS 2E-6...
  • Page 71 The jumper JP1 for end of RS485 serial bus must only be inserted on the last device connected via serial bus. For functioning with the TP8-64 BUS control panel, the TECNOCELL-PRO PL must communicate at 38,400 bps via serial bus, therefore insert the H.SPEED jumper.
  • Page 72 Telephone communicator with GSM module Installer Manual - TP8-64 BUS 2F-2...
  • Page 73 2G. WIRELESS EXPANSION MODULES (OPTIONAL) WARNING It is possible to connect a total of 2 wireless receiver-transmitters RTX200/433868 or RX300/433868 to TP8-64 BUS control panel. 2G.1 RTX200/433868 WIRELESS RECEIVER-TRANSMITTER RTX200/433868 is a wireless receiver-transmitter (wireless data transmission) connected via RS485 serial bus and communication with the control panel with a high-speed serial bus protocol (38,400 Baud).
  • Page 74 2G.1.4 868MHZ SECTION The 868MHz wireless receiver section can be enabled and disabled by the jumper W2: Jumper inserted = 868MHz section enabled Jumper removed = 868MHz section disabled 2G.1.5 CASING Wireless expansion modules Installer Manual - TP8-64 BUS 2G-2...
  • Page 75 The jumper W1 for end of RS485 serial bus must only be inserted on the last device connected via serial bus. It is possible to connect max. 2 wireless devices (RTX200/433868 or RX300/433868) to the TP8-64 BUS control panel. TP8-64 BUS - Installer manual Wireless expansion modules 2G-3...
  • Page 76 2G.2.2 DIP-SWITCH SETTINGS TABLE 2 2G.2.3 CASING Wireless expansion modules Installer Manual - TP8-64 BUS 2G-4...
  • Page 77 Close the plastic shells again and pull the screw tight BATTERY TYPE Use batteries with the following features: Type number: CR2032 (Brands: Maxell, Energizer, Varta, Sony, Renata) Type: Lithium (Li/MnO Voltage: Capacity: 220mAh TP8-64 BUS - Installer manual Wireless expansion modules 2G-5...
  • Page 78 BUT T O N F O R O P ENING O F T HE L ID KEYP AD L ABEL Rec apitulation of the princ ipal c om m ands P L AS T IC L ID SUMMARY OF COMMANDS Wireless expansion modules Installer Manual - TP8-64 BUS 2G-6...
  • Page 79 2G.4.1 ELECTRONIC BOARD 2G.4.2 DIP-SWITCH SETTINGS TP8-64 BUS - Installer manual Wireless expansion modules 2G-7...
  • Page 80 Verify siren sounding by arming the control panel and violating a zone Close the cover Quit the maintenance mode on the control panel and check end of the low battery signaling Wireless expansion modules Installer Manual - TP8-64 BUS 2G-8...
  • Page 81 DIPSWIT CH 2 = ON - FUNCT IONING LEVEL C Loca l sound signa l a fte r 2 hours of inte rruption of communica tion w ith the control pa ne l TP8-64 BUS - Installer manual Wireless expansion modules...
  • Page 82 Wireless expansion modules Installer Manual - TP8-64 BUS 2G-10...
  • Page 83 3. SET-UP The control panel TP8-64 BUS can be programmed using either a console with liquid crystal display or a PC equipped with the Tecnoalarm programming and monitoring software. Programming by PC can be made at distance via telephone line or on the spot connecting the PC to the control...
  • Page 84 Open the user archive by clicking on the opposite icon. On the screen is viewed: Enter a new record (user) by clicking on the opposite icon and fill in the form. On the screen is viewed: Set-up Installer Manual - TP8-64 BUS...
  • Page 85 Using a TP8-64 BUS control panel with telephone connection PSTN, select the STANDARD call type. Modem no. Number of the modem used for callback towards the TP8-64 BUS (necessary when the monitoring station uses several modems for the connection to the various sytems.
  • Page 86 Programming of max. 62 user codes + master code (name, value, enabling, association of codes to the programs, other functions) Programming of max. 32 user keys (name, enabling, association of keys to the programs, other functions) Programming of max. 32 wireless keys (name, function-key association, programming of the attributes) Set-up Installer Manual - TP8-64 BUS...
  • Page 87 Comparison of the hardware programmed by PC with the devices connected and viewing of coherence and incoherence. System analysis RSC Analysis of the communication with the Sensor Bus devices and viewing of the attempts at connecting and the quantity of communication errors for every single device TP8-64 BUS - Installer Manual Set-up...
  • Page 88 Set-up Installer Manual - TP8-64 BUS...
  • Page 89 If you confirm the addition of the module, it is added to the system configuration viewed. The console is added to the system configuration viewed. Next to the module the dipswitch address is shown. TP8-64 BUS - Installer Manual Set-up...
  • Page 90 Electronic keypad for arming/disarming or activation/deactivation and by-pass of the first 4 premiers programs. TP SK6N Keypoint with 6 keypads permitting arming/disarming and by-pass of the first 6 programs. TP SKN Keypoint without keypad permitting arming/disarming of the first 3 programs Set-up Installer Manual - TP8-64 BUS...
  • Page 91 It is possible to connect up to 2 receiver-transmitters RTX200/433868 or RX300/433868. SAEL 2000 WL Bidirectional wireless siren. TX240-3 Wireless key with 3 function keys. LCD300 WL Wireless console Modules on BUS SAEL2000BUS/L/F Siren on BUS TP8-64 BUS - Installer Manual Set-up...
  • Page 92 (4 wires for RS485 serial bus + 1 wire for voice report on the consoles). Connect all modules in series (all modules in sequence). If you make star-shaped connections use an RS485 extension module. Set-up Installer Manual - TP8-64 BUS 3-10...
  • Page 93 3.3.2 CONNECTION OF THE MODULES ON SENSOR BUS AND SIRENS BUS TP8-64 BUS - Installer Manual Set-up 3-11...
  • Page 94 The Tecnoalarm programming and monitoring software assigns the addresses automatically according to the order in which they are added to the hardware configuration and taking into account all the necessary limitations.
  • Page 95 4. PROGRAMMING BY PC TP8-64 BUS can be programmed by LCD console or by PC. Using a PC, this must be connected to the control panel using a special RS232-RS485 interface (PROG 32 or PROG USB) and equipped with the Tecnoalarm programming software.
  • Page 96 Sierns bus parameters 4.1.1 ZONE LIST TP8-64 BUS can control max. 64 zones. These can be selected freely among the zone inputs provided by the modules connected to the control panel, i.e.: 8 RSC inputs of the CPU board (always present) 4 inputs of the local expansion board (plug-in connection onto the CPU board) max.
  • Page 97 WARNING TP8-64 BUS can control up to 64 zones which can be freely selected among those provided by the hardware modules connected. Zone: By zone is intended the area protected by a determined device independently from its position. The control panel is able to control a total of 64 zones.
  • Page 98 SBUS for the control of the sensor bus devices (EXPLORER BUS, MINIEXPLORER DOPPLER BUS, DUAL BUS 05,etc). RADIO zones are available if a wireless module (RTX200/433868 or RX300/433868) is connected. Programming by PC Installer Manual - TP8-64 BUS...
  • Page 99 Permits programming of the beam power at four levels (off, low, medium, high). Repeat the procedure for every zone to be configured (max. 64), then press: to confirm and quit Abandon to quit without saving TP8-64 BUS - Installer Manual Programming by PC...
  • Page 100 Each parameters on the right side can be programmed with the type of the detector. Repeat the procedure for every zone to be configured (max. 64). Once all the zones have been configured, press: to confirm and quit Abandon to quit without saving Programming by PC Installer Manual - TP8-64 BUS...
  • Page 101 The zones checked are associated to the group of common zones and are included in several programs each. As a consequence, they are enabled for the detection of alarms only if all the programs they are included in are armed. TP8-64 BUS - Installer Manual Programming by PC...
  • Page 102 16 characters. All further characters will be cut off. Repeat the operations for every program (max. 8). Once you have created the programs, press: to confirm and quit Abandon to quit without saving Programming by PC Installer Manual - TP8-64 BUS...
  • Page 103 If the voice report is enabled it is recommended to disable the buzzer of the consoles in order to avoid the superimposition of signaling. To disable the buzzer of the consoles, use the dip-switch (dip 10) on the electronic boards of the consoles. TP8-64 BUS - Installer Manual Programming by PC...
  • Page 104 Every level of wireless transmission a different output power of the wireless receiver-transmitter corresponds to (RTX200/433868). WARNING Prior to setting the level of wireless transmission check for possible output power limitation in your country Programming by PC Installer Manual - TP8-64 BUS 4-10...
  • Page 105 To enable an option, click on the box beside it. Once you have set the system options, press: to confirm and close the zone configuration tables Abandon to undo the system option settings TP8-64 BUS - Installer Manual Programming by PC 4-11...
  • Page 106 OUT2 - stand-by: high impedence OUT2 - stand-by: alarm: alarm: high impedence Once the output configuration has been completed, press: to confirm and quit Abandon to quit without saving Programming by PC Installer Manual - TP8-64 BUS 4-12...
  • Page 107 Bidirectional sweep tone (default setting) Monodirectional sweep tone Bitone PREALARM The siren is actived in case of prealarm of at least one of the programs it is associated to. The sound type is fixed. TP8-64 BUS - Installer Manual Programming by PC 4-13...
  • Page 108 Sounding and falshing light are actived To enable an option, click on the box beside it. Once all the options required have been enabled, press: to confirm and quit Abandon to quit without saving Programming by PC Installer Manual - TP8-64 BUS 4-14...
  • Page 109 The control panel is able to transmit alarm signaling or other data using either digital protocols or pre-recorded vocal messages (composed of words of the vocabulary). It can transmit and receive alarm signaling using the digital Tecnoalarm protocol or the most frequently used digital protocols. Programming upload and download is possible using the Tecnoalarm protocol only.
  • Page 110 On reception of the corresponding command, the control panel checks if there are events waiting to be transmitted. If there are no more events to be transmitted or a single type protocol has been programmed, the alarm call cycle of the active Tecnoalarm channel is stopped. On the contrary, the following events are transmitted.
  • Page 111 Enables the playing of the opening message prior to the alarm message during vocal message transmission. Once the configuration of the telephone interface has been completed, press: to confirm and quit Abandon to quit without saving TP8-64 BUS - Installer Manual Programming by PC 4-17...
  • Page 112 Enable guided menu (terminal S) The control panel TP8-64 BUS composes the voice messages itself with the help of the onboard vocabulary and communicates it together with telephone number to send the message to via S-wire (speaker terminal on the CPU board) to the telephone communicator with GSM module.
  • Page 113 If the alarm or event to be defined is not viewed, click on the scroll bar and move downwards until you reach the requested event. Once the report codes have been programmed, press: to confirm and quit Abandon to quit without saving TP8-64 BUS - Installer Manual Programming by PC 4-19...
  • Page 114 The opening message is a voice message that is reproduced during every outgoing telephone call. It can be recorded by the user in different ways: using the Tecnoalarm programming and monitoring software, a special sound manager resident on your PC, loading from a prerecorded WAV file or by telephone.
  • Page 115 Press the Vocabulary button in the lower part of the window. The English vocabulary can be found in the following directory C:\Program files\Tecnoalarm\Centro\WAV2\ENG Select the file Msg_cnf.tcn. Once you have finished programming of the opening message and set the language of the vocabulary, press:...
  • Page 116 Repeat the operations for every remote control to be configured (up to 8). Once the messages for remote control have been programmed, press: to confirm and quit Abandon to quit without saving Programming by PC Installer Manual - TP8-64 BUS 4-22...
  • Page 117 2m and siren delay is 1m:30s, the sirens will be active for 30s. Alarm time (mm:ss) This parameter indicates the duration of signaling for zone alarm (indoor-outdoor-radio sirens/supervisory boards). TP8-64 BUS - Installer Manual Programming by PC 4-23...
  • Page 118 Once you have finished programming of the time parameters press: to confirm and quit Abandon to quit without saving Programming by PC Installer Manual - TP8-64 BUS 4-24...
  • Page 119 Qualified arming (avoid arming in the presence of low battery, power failure, tamper, supervision, fault and antimasking alarm). TP8-64 BUS - Installer Manual Programming by PC 4-25...
  • Page 120 Select the item Condition and subsequently the condition of execution requested (i.e. always or armed). Once you have finished programming of the timers and the test call cycle, press: to confirm and quit Abandon to quit without saving Programming by PC Installer Manual - TP8-64 BUS 4-26...
  • Page 121 Every holiday-eve Every holiday Every sunday Every saturday Deactivation time To program the deactivation time of the access period, select the item next to the frequency and enter the time (hh:mm). TP8-64 BUS - Installer Manual Programming by PC 4-27...
  • Page 122 Once you have finished the configuration of the access periods and the association to the codes and keys, press: to confirm and quit Abandon to quit without saving Programming by PC Installer Manual - TP8-64 BUS 4-28...
  • Page 123 A crossed sun will be shown next to the date. Subsequently select Winter time and click once on the day of end of summer time. A sun will be shown next to the date. TP8-64 BUS - Installer Manual Programming by PC 4-29...
  • Page 124 2 to 3 o'clock or from 3 to 2 o'clock of the selected day. Repeat the procedure for the second year (Customization 2nd year). Once you have finished programming of the biannual calendar, press: to confirm and quit Abandon to quit without saving Programming by PC Installer Manual - TP8-64 BUS 4-30...
  • Page 125 The code length is relevant for all the codes of the system, i.e. once programmed it is the same for all the codes. The control panel accepts 4 to 6-digits codes. The default code length is 5 digits. TP8-64 BUS - Installer Manual Programming by PC 4-31...
  • Page 126 Repeat the procedure for all of the user codes (1 to 62). Once the codes have been programmed, press: to confirm and quit Abandon to quit without saving Programming by PC Installer Manual - TP8-64 BUS 4-32...
  • Page 127 (disarming confirmation delay), otherwise a silent hold-up alarm will be released. TP8-64 BUS - Installer Manual Programming by PC 4-33...
  • Page 128 Arming program Arming of the associated program (1 to 8). Disarming program Disarming of the associated program (1 to 8). On/off remote controle Toggling of the associated remote control (1 to 8). Programming by PC Installer Manual - TP8-64 BUS 4-34...
  • Page 129 (1 impulse). Repeat the procedure for all the wireless keys (1 to 32). Once you have finished programming of the wireless keys, press: to confirm and quit Abandon to quit without saving TP8-64 BUS - Installer Manual Programming by PC 4-35...
  • Page 130 Volume of sounding for alarm is always set at the maximum. Siren mode The siren can be programmed so as to work either as an indoor or an outdoor siren. Programming by PC Installer Manual - TP8-64 BUS 4-36...
  • Page 131 The control panel administers max. 4 wireless consoles individually programmable with the following parameters: Programming of the attributes of the consoles SELECTION OF THE CONSOLE Select the corresponding item and scroll down the list. TP8-64 BUS - Installer Manual Programming by PC 4-37...
  • Page 132 (arrow right key) and confirm with Yes. Commands available to confirm saving to quit without saving If the system configuration is saved on floppy, it is saved as TP64BXXXX.TCN (XXXX = user ID). Programming by PC Installer Manual - TP8-64 BUS 4-38...
  • Page 133 PC and to the serial interface PROG32 or PROG USB. Connect the other terminal of the interface PROG32 or PROG USB to the serial port of the CPU board of the control panel TP8-64 BUS.
  • Page 134 (viewed in the lower right hand part of the screen) is green with a red dot running from the left to the right and back. If the arrow is white, the communication is interrupted. Programming by PC Installer Manual - TP8-64 BUS 4-40...
  • Page 135 Commands available to confirm and reset test call timer to deny and upload without resetting test call timer TP8-64 BUS - Installer Manual Programming by PC 4-41...
  • Page 136 2 Indicator of the user archive (configuration saved on the hard disk of the PC). 3 Indicator of the external storage device (configuration saved on floppy). 4 Indicator of the control panel connected Programming by PC Installer Manual - TP8-64 BUS 4-42...
  • Page 137 Once the download has been completed correctly, system configuration is available and viewed in the local programming window. The indicators 1 (local programming window) and 4 (control panel) should then have the same colour. TP8-64 BUS - Installer Manual Programming by PC 4-43...
  • Page 138 Programming by PC Installer Manual - TP8-64 BUS 4-44...
  • Page 139 5. PROGRAMMING BY CONSOLE WARNING Programming of the control panel is only possible by PC using the Tecnoalarm programming software or LCD console (LCD300/S). The secondary control units (indicated as keypoints) do not permit programming. To program the control panel by console enter the installer programming menu by - ACCESS - entering the installer code (default code 54321) on the console.
  • Page 140 If you deny (by pressing the *NO key), the description will only be used as voice message. N.B. The display can view descriptions of maximum 16 digits, all further character will be cutoff. The descriptions can be modified manually only by PC. Programming by console Installer Manual - TP8-64 BUS...
  • Page 141 18) Module-zone exclusion (Menu 17) Paragraph 5.20 19) Test (Menu 18) Paragraph 5.21 ATTENTION While a console is in use, all the other consoles of the system are disabled and view Waiting. TP8-64 BUS - Installer Manual Programming by console...
  • Page 142 5.3.2 INPUT-ZONE ASSOCIATION (CREATION OF THE ZONE LIST) TP8-64 BUS controls a total of 64 zones freely associable to the physical zone inputs Zone 001 provided by the hardware installed: Ass. inputs...
  • Page 143 WARNING TP8-64 BUS, different from the other control panels by TECNOALARM, can control up to 64 zones which can be freely selected among those provided by the hardware modules connected. Zone: By zone is intended the area protected by a determined device independently from its position.
  • Page 144 (normally closed) (normally open) ZBUS (Zone Bus by Tecnoalarm) - relevant for the inputs of the expansion modules 1 to 14 only, not for the CPU board SBUS (Sensor Bus by Tecnoalarm) - relevant for the inputs of the expansion...
  • Page 145 (e.g. IrR programmed but contact learnt). In case of error, quit by pressing the EXIT key and re-enter the learning menu, then repeat the entire procedure. TP8-64 BUS - Installer Manual Programming by console...
  • Page 146 Panic Press simultaneously the ARROW UP+ARROW DOWN keys yw Quick remote control Quickly active/deactive the remote control by pressing in sequence y followed by the number of the remote control and #YES Programming by console Installer Manual - TP8-64 BUS...
  • Page 147 The serial number of the control panel is used in every communication with the sirens Wireless and the wireless receivers-transmitters. It is to avoid interferences with other wireless Sn. Ctrl panel systems placed near TP8-64 BUS. Commands available to learn the wireless siren/console selected to delete the wireless sirens/console selected...
  • Page 148 The control panel TP8-64 BUS permits the creation of maximum 8 programs, every program can be composed of maximum 64 zones.
  • Page 149 The zone viewed has already been associated to the program selected. Commands available + #YES to associate the zone viewed to the function + *NO to cancel a possible existing association + EXIT to accept programming and quit the submenu TP8-64 BUS - Installer Manual Programming by console 5-11...
  • Page 150 Defines the duration of end-of-by-pass warning (buzzer on the consoles) prior to re-enabling of the zones excluded. Time Warn. autom. Automatic arming warning (mm:ss) Warn. autom. Defines the duration of warning (buzzer on the consoles) of Programming by console Installer Manual - TP8-64 BUS 5-12...
  • Page 151 Pulse buzzer (the buzzer sounds for 2 seconds on every opening of the zone) Exit (exit time) The buzzer sounds during the exit time. Buzzer Prealarm Prealarm The buzzer sounds during the entry time. TP8-64 BUS - Installer Manual Programming by console 5-13...
  • Page 152 Cut telephone line Remote control 6 Indoor siren Prealarm Remote control 7 Outdoor siren Remote control 8 Commands available + yw to select the meaning + #YES to confirm the selection Programming by console Installer Manual - TP8-64 BUS 5-14...
  • Page 153 [ # ] Function enabled Commands available + yw to select the function + #YES to select and activate the function + *NO to deactivate the function + EXIT to confirm and quit the submenu TP8-64 BUS - Installer Manual Programming by console 5-15...
  • Page 154 Permits programming of the starting hour of the test call cycle. Commands available + yw to select the item + 0...9 to enter the value + EXIT to accept programming and quit the submenu Programming by console Installer Manual - TP8-64 BUS 5-16...
  • Page 155 Permits the skipping of the next intervention of the timer selected. The timer is reactivated upon the next but one intervention of the timer. Viewing of the current settings ] Timer active [ # ] Timer blocked TP8-64 BUS - Installer Manual Programming by console 5-17...
  • Page 156 (the voice message will be used as Copy into desc.? descripton too) + *NO #YES to deny and quit (the voice message will only be used for voice alarm messages and the voice report of the console) Programming by console Installer Manual - TP8-64 BUS 5-18...
  • Page 157 + EXIT to accept programming and quit the submenu WARNING The symbol 4 behind the console number indicates that the console has actually been connected via serial bus to the control panel. TP8-64 BUS - Installer Manual Programming by console 5-19...
  • Page 158 (1 impulse). Viewing of the current settings ] Attribute has not been associated to the wireless key selected [ # ] Attribute has been associated to the wireless key selected Programming by console Installer Manual - TP8-64 BUS 5-20...
  • Page 159 Global block single type protocol has been programmed, it closes the communication and blocks the active phone call cycle of this channel. In all the other cases, the next event is transmitted. TP8-64 BUS - Installer Manual Programming by console 5-21...
  • Page 160 Block the single channel Ring back [ # ] Block all the channels Digit. block Interruption of all the active digital calls using non Tecnoalarm protocols. On reception of the blocking command, the control panel can: Setting • Block the single channel...
  • Page 161 For digital data transmission, it is Channel D necessary to define a digital protocol according to the kind of device (Tecnoalarm or non-Tecnoalarm device) connected to and the ID code. The system is compatible with Telephone the most commonly used digital protocols (see table).
  • Page 162 + EXIT to accept programming and quit the submenu WARNING By default the channels are set for the digital transmission protocol Tecnoalarm (000). 5.14.4 PROGRAMMING OF THE CALLBACK NUMBERS The callback function is indispensable for remote programming of the control panel.
  • Page 163 Enables answering to incoming calls with voice messages of the guided menu. [ # ] Guided menu enabled Mobile No. rings Permits programming of the number of rings before No. rings answering (from 1 to 15). TP8-64 BUS - Installer Manual Programming by console 5-25...
  • Page 164 + EXIT to accept programming and quit the submenu WARNING The heading of the SMS message can have a maximum length of 40 characters. All further characters will be cut off. Programming by console Installer Manual - TP8-64 BUS 5-26...
  • Page 165 RS485 is interrupted for more than 30 seconds. A typical emergency message would be "Attention emergency message TECNOCELL-PRO PL”. WARNING The emergency SMS is always transmitted with warning signal. TP8-64 BUS - Installer Manual Programming by console 5-27...
  • Page 166 CHANNEL ASSOCIATION + yw to select the channel (A...H) Viewing of the current settings ] Channel not associated to the event selected [ # ] Channel associated to the event selected Programming by console Installer Manual - TP8-64 BUS 5-28...
  • Page 167 Siren activation for antimasking alarm enabled Key ON/OFF Defines the functioning mode of the key zone: Pulse (permitting the connection of a button) [ # ] ON/OFF (permitting the connection of a mechanic key) TP8-64 BUS - Installer Manual Programming by console 5-29...
  • Page 168 ] Option not enabled [ # ] Option enabled Commands available + #YES to enable the option selected + *NO to disable the option selected + EXIT to accept programming and quit the submenu Programming by console Installer Manual - TP8-64 BUS 5-30...
  • Page 169 Enables the manual communicator block after disarming (entering the code). Entering the code again followed by the EXIT key all the active phone call cycles and those queued up are interrupted. TP8-64 BUS - Installer Manual Programming by console 5-31...
  • Page 170 Programming by console Installer Manual - TP8-64 BUS 5-32...
  • Page 171 Learning of the keys will only be possible, if you enter programming with the master code. Viewing of the current settings Key 01 ] Key has not yet been learnt Learn. [ # ] Key has been learnt TP8-64 BUS - Installer Manual Programming by console 5-33...
  • Page 172 [ # ] Device or zone excluded Commands available + #YES to exclude the selected device + *NO to enable the selected device + EXIT to accept programming and quit the submenu Programming by console Installer Manual - TP8-64 BUS 5-34...
  • Page 173 (S1, S2, S3 and S4): Yes Yes --- Communication (TX/RX) without errors Communication (TX/RX) with negative issue - - - No wireless siren associated to this position Commands available + EXIT to quit the submenu TP8-64 BUS - Installer Manual Programming by console 5-35...
  • Page 174 WARNING During the test, the wireless outdoor sirens work according to programming (see § 5.4), i.e. not active, sounding, flashing, sounding+flashing. The sounding or flashing time, however, is irrelevant. Programming by console Installer Manual - TP8-64 BUS 5-36...
  • Page 175 Signal ***** Commands available + EXIT to quit the submenu Ver. 1.5 WARNING During the test, the GSM telephone communicator must be connected to the control panel through the serial line. TP8-64 BUS - Installer Manual Programming by console 5-37...
  • Page 176 Programming by console Installer Manual - TP8-64 BUS 5-38...
  • Page 177 1 master code (default code 12345) The master code is usually reserved for the owner of the system and gives access to the master programming menu as well as the standard arming/disarming and parset functions. TP8-64 BUS - Installer Manual Control by console...
  • Page 178 The modification of the standard user codes is subject to enabling by the installer. If the master is not enabled for the management of the standard user codes, it will permit only viewing and and modification of itself. Control by console Installer Manual - TP8-64 BUS...
  • Page 179 62 standard user codes (default code 00000) Every code can be enabled individually for arming/disarming or by-pass of determined programs. TP8-64 BUS - Installer Manual Control by console...
  • Page 180 OPERATIONS WITHOUT CODE Control by console Installer Manual - TP8-64 BUS...
  • Page 181 = program alarm active WARNING On arming of the program in presence of open zones, the alarm devices programmed (sirens/logic outputs/telephone channels) are activated unless the open zones are excluded with a procedure explained lateron. TP8-64 BUS - Installer Manual Control by console...
  • Page 182 EXCLUDE ? with # to exclude the zone selected Select another zone to be excluded with the keys arrow up and arrow down yw or Zone xxx exclude sequential zones pressing repeatedly # (hash). Control by console Installer Manual - TP8-64 BUS...
  • Page 183 It is not permitted in case of trouble/general alarm or fault (low battery, power failure etc.). At the attempt at doing so, on the display is viewed ! ARM. DENIED ! followed by the kind of alarm. TP8-64 BUS - Installer Manual Control by console...
  • Page 184 Outside the access periods associated the codes are not accepted by the control panel and any attempt at acceding to the system will have no effect. When trying to do so, on the display is viewed ACCESS ! DENIED !. Control by console Installer Manual - TP8-64 BUS...
  • Page 185 On every keystroke the counter is reset. Select the programs to be disarmed, e.g.: + 12 Procede as for disarming with master code (see § 6.2.1). 6.2.2.1 TOTAL DISARMING See § 6.2.1.1. TP8-64 BUS - Installer Manual Control by console...
  • Page 186 Act. by-pass + 12 Program 1 On the display is viewed Act. by-pass followed by the program partset. For the time the by-pass is active the corresponding program LED is blinking. Control by console Installer Manual - TP8-64 BUS 6-10...
  • Page 187 Deact. by-pass maximum by-pass time and the yellow program LED on the console become lit. According to programming, the buzzers of the consoles are activated, too. TP8-64 BUS - Installer Manual Control by console 6-11...
  • Page 188 The blocking command stops all the active alarm calls cycles as well as those waiting. The block of the telephone calls is not permitted in case of hold-up alarm. In this case, the cycle continues uninterrupted. Control by console Installer Manual - TP8-64 BUS 6-12...
  • Page 189 Answer with confirmation - all events confirmed Answer Answer ok M. answ. ko Answer without confirmation - no event confirmed - GSM WARNING The events cannot be deleted from the event buffer. TP8-64 BUS - Installer Manual Control by console 6-13...
  • Page 190 The active alarms are not stopped upon reset of alarm memory signaling. LED signaling for tamper and general alarm (e.g. low battery, power failure) cannot be reset by the user. Consult the installer. Control by console Installer Manual - TP8-64 BUS 6-14...
  • Page 191 VIEWING OF ALARM OF A SPECIFIC PROGRAM Viewing To view the stored alarms of a specific alarm, preced the MEM key with the program Program 1 number, e.g.: + 1 MEM TP8-64 BUS - Installer Manual Control by console 6-15...
  • Page 192 Control by console Installer Manual - TP8-64 BUS 6-16...
  • Page 193 The common zone (entrance), however, is activated only if the programs of both appartments it is included in are armed simultaneously. Control by keypoint TP8-64 BUS - Installer Manual...
  • Page 194 If the programs selected contain delayed zones, on expiry of the zone exclusion time follows the exit time and the programs in question are only armed on expiry of the exit time. Installer Manual - TP8-64 BUS Control by keypoint...
  • Page 195 It is possible to define up to 8 access periods of the electronic keys. As a consequence, the electronic keys are enabled for by-pass during the access periods associated by the installer or the holder of the master code only. Control by keypoint TP8-64 BUS - Installer Manual...
  • Page 196 The common zone (entrance), however, is activated only if the programs of both appartments it is included in are armed simultaneously. Installer Manual - TP8-64 BUS Control by keypoint...
  • Page 197 WARNING On arming of a program in presence of open zones, the alarm devices programmed (sirens/logic outputs/telephone channels) are activated unless the open zones are exluded with a procedure explained lateron. Control by keypoint TP8-64 BUS - Installer Manual...
  • Page 198 7.2.2.1 SINGLE ARMING Introduce an electronic key enabled for the program armed into the key reader. The program is disarmed and the corresponding led is switched off. Remove the key from the key reader. Installer Manual - TP8-64 BUS Control by keypoint...
  • Page 199 LED 6 general alarm of the electronic keypads start blinking. To stop the alarm introduce a key or enter a user code (master or standard user) on one of the control units connected. Control by keypoint TP8-64 BUS - Installer Manual...
  • Page 200 If a trouble/general alarm is active (the corresponding LED is blinking), arming of the control panel by key is not permitted unless the key has been enabled for the by-pass of the general alarms. Installer Manual - TP8-64 BUS Control by keypoint...
  • Page 201 Open zones/active zone alarms are not signalled unless you try to arm the control panel. In the arming phase the yellow LED 7 OCG signals zone status: LED blinking = open zones LED off = zones ok Control by keypoint TP8-64 BUS - Installer Manual...
  • Page 202 It is possible to define up to 8 access periods of the codes. As a consequence, the codes are enabled for arming and disarming during the access periods associated by the installer or the holder of the master code only. Installer Manual - TP8-64 BUS Control by keypoint 7-10...
  • Page 203 It is possible to define up to 8 access periods of the codes. As a consequence, the codes are enabled for by-pass during the access periods associated by the installer or holder of the master code only. Control by keypoint TP8-64 BUS - Installer Manual 7-11...
  • Page 204 If a general alarm is active (the corresponding LED is blinking), arming of the control panel is not permitted with code unless the code is enabled for the by-pass of the general alarms. Installer Manual - TP8-64 BUS Control by keypoint...
  • Page 205 On the console the LED corresponding to the programs previously armed by this wireless key are switched off. The buzzer of the console is activated for approx. 2 seconds The programs previously armed by this wireless key, are disarmed. Control by keypoint TP8-64 BUS - Installer Manual 7-13...
  • Page 206 To activate by-pass, simply press the corresponding function key. 7.5.4 LEARNING The wireless key must be recognized from the control panel before use. The name of this function is learning (see § 5.13.1). Installer Manual - TP8-64 BUS Control by keypoint 7-14...
  • Page 207 Outdoor siren battery recharge (7Ah): Max. 230mA Power supply detectors: Max. 800mA Logic outputs: Max. 100mA Expansion modules: Max. 40mA Power supply via serial bus RS485: Max. 500mA Max. capacity battery: -7Ah Operating temperature: +5°C...+40°C TP8-64 BUS - Installer Manual Technical specifications...
  • Page 208 Primary protection fuse: T 200mA WARNING The following batteries may be used: Trade mark: YUASA Model: NP 7-12 F.R. (7Ah) Case flame class: UL94V0 or equivalent batteries with case flame class of UL94V2 or better. Technical specifications Installer Manual - TP8-64 BUS...
  • Page 209 TP8-64 BUS MET CONTROL PANEL Producer: Device: TP8-64 BUS MET Description: Serial control panel Connection type: RS485 serial bus Number of zones: 8 to 64 completely programmable zones 1 tamper input Outputs: 1 relay output (outdoor siren) - 1 logic output (indoor siren)
  • Page 210 INTERNAL INPUT EXPANSION MODULE 8.3.1 EXPANSION MODULE WITH 4 INPUTS Device: ESP4-IN Description: Internal input expansion module Number of inputs: 4 wired zone inputs Operating temperature: +5°C .. +40°C To be inserted on the CPU board. Technical specifications Installer Manual - TP8-64 BUS...
  • Page 211 Operating temperature: +5°C...+40°C WARNING The following batteries may be used: Trade mark: YUASA Model: NP 7-12 F.R. (7Ah) Case flame class: UL94V0 or equivalent batteries with case flame class of UL94V2 or better. TP8-64 BUS - Installer Manual Technical specifications...
  • Page 212 4 completely programmable zone inputs Outputs: 1 programmable logic output Serial bus: 1 RS485 serial port for the connection of other serial modules Tamper protection: 1 antiopening switch + 1 antidetachment switch Casing: Plastic (optional) Technical specifications Installer Manual - TP8-64 BUS...
  • Page 213 Logic outputs, detector power supply: Max. 500mA (*) Operating temperature: +5°C...+40°C NOTE (*) For the modules that are not equipped with proper power supply, the current supplied depends on the power supply they are connected to. TP8-64 BUS - Installer Manual Technical specifications...
  • Page 214 UL94V2 or better. TRANSFORMER TA14/3 Voltage primary winding: 230V ~ (red) Voltage secondary winding: 30V ~ / 1.3A (blue) Frequency: 50/60Hz Power: 40VA Class: Primary protection fuse: T 200mA Technical specifications Installer Manual - TP8-64 BUS...
  • Page 215 Casing: ABS casing (not included) POWER SUPPLY SECTION Operating voltage: Rated Detector power supply voltage: Min. Max. Current available for: Module: Max. 55mA Logic outputs and detectors: Max. 100mA (*) Operating temperature: +5°C...+40°C TP8-64 BUS - Installer Manual Technical specifications...
  • Page 216 1 combined antiopening and antidetachment tamper switch Operating voltage: Rated Min. Max. Consumption: Stand-by: 14mA Programming: 48mA Permanently backlit display and sound report: 120mA Max. comsumption: 85mA Operating temperature: +5°C...+40°C Design by: Technical specifications Installer Manual - TP8-64 BUS 8-10...
  • Page 217 Electronic keys: MPKEY Connection type: Serial RS485 Tamper protection: 1 antiopening switch Operating voltage: Rated Min. Max. Consumption: Max. 28mA Consumption per key reader: Max. (for every LED lit) Operating temperature: +5°C...+40°C TP8-64 BUS - Installer Manual Technical specifications 8-11...
  • Page 218 Supervisory board with signaling LED Number of outputs: 32 LED outputs Connection type: Serial RS485 Tamper protection: 1 combined antiopening and antidetachment tamper switch Operating voltage: Rated Min. Max. Max. consumption: 150mA Operating temperature: +5°C...+40°C Technical specifications Installer Manual - TP8-64 BUS 8-12...
  • Page 219 Operating temperature: +5°C...+40°C 8.8.3 RS485 SERIAL BUS EXTENSION Device: SPEED RS485 Description: RS485 serial bus extension module Connection type: Serial RS485 Operating voltage: Rated Min. Max. Max. consumption: 30mA Operating temperature: +5°C...+40°C TP8-64 BUS - Installer Manual Technical specifications 8-13...
  • Page 220 Connection type: Serial RS485 Operating voltage: Rated Min. 10.5V Max. Consumption: 48mA @ 12V 130mA (with max. power) Reception bands: 433.05MHz...434.99MHz 868.70MHz...869.20MHz Transmission band: 869.40MHz...869.65MHz Power: Mode1 10mV Mode2 25mV Operating temperature: +5°C...+40°C Technical specifications Installer Manual - TP8-64 BUS 8-14...
  • Page 221 Reception frequency: 433.05MHz...434.79MHz 868.70MHz...869.20MHz Operating temperature: +5°C...+40°C 8.10.3 WIRELESS KEY Device: TX240-3//868 Description: Wireless key with 3 function keys Lityhium battery: 3V- 220mA Transmission frequency: 868.40MHz...868.65MHz Power: Max. 15mW Operating temperature: +5°C...+40°C TP8-64 BUS - Installer Manual Technical specifications 8-15...
  • Page 222 Technical specifications Installer Manual - TP8-64 BUS 8-16...
  • Page 223 TP8-64 BUS APPENDIX A TRANSMISSION PROTOCOLS TP8-64 BUS - Installer Manual Protocols - Appendix A...
  • Page 224 Appendix A - Protocols Installer Manual - TP8-64 BUS...
  • Page 225 RADIONICS (confirmation 2300) RADIONICS (confirmation 1400) RADIONICS (confirmation 1400) RADIONICS WITH PARITY (confirmation 2300) RADIONICS WITH PARITY (confirmation 2300) RADIONICS WITH PARITY (confirmation 1400) RADIONICS WITH PARITY (confirmation 1400) UNDEFINED UNDEFINED TP8-64 BUS - Installer Manual Protocols - Appendix A...
  • Page 226 To avoid the undesired communicator block of all the chanels, use the vocal 09 voice message protocol with confirmation. Appendix A - Protocols Installer Manual - TP8-64 BUS...
  • Page 227 TP8-64 BUS APPENDIX B SPECIAL PROCEDURES TP8-64 BUS - Installer Manual Special procedures - Appendix B...
  • Page 228 Appendix B - Special procedures Installer Manual - TP8-64 BUS...
  • Page 229 (i.e. no telephone number, no zone configuration, no function programmed) and the default codes as as well as the default code length: Default installer code 54321 Default master code 12345 Default standard user codes 00000 (unvalid code) Default code length 5 digits TP8-64 BUS - Installer Manual Special procedures - Appendix B...
  • Page 230 On the screen is viewed: Click on the opposite icon on the menu bar. On the screen is viewed: BACKUP Click on the Receive (Backup) button The backup procedure is started. Appendix B - Special procedures Installer Manual - TP8-64 BUS...
  • Page 231 Pressing Yes, the process is completed and on the screen is viewed the opposite message. Commands available to confirm and quit. TP8-64 BUS - Installer Manual Special procedures - Appendix B...
  • Page 232 Enter the user archive and select the corresponding system from the user list. On the screen is viewed: Click on the opposite icon on the menu bar. On the screen is viewed: Appendix B - Special procedures Installer Manual - TP8-64 BUS...
  • Page 233 Click on the Abandon button and explore the CD until you find the directory containing the new firmware version of the control panel TP8-64 BUS. On the screen is viewed: Select the corresponding file (tp64bENG_12.bin) and click on the Open button.
  • Page 234 On the display of the console is viewed the new firmware version. Click on the Exit button in the Firmware window on (c) Tecnoalarm PC to quit the menu. TP64B v.1.2 ENG The process has been completed. Appendix B - Special procedures Installer Manual - TP8-64 BUS...
  • Page 235 Enter the user archive and select the corresponding system from the user list. On the screen is viewed: Click on the opposite icon on the menu bar. On the screen is viewed: TP8-64 BUS - Installer Manual Special procedures - Appendix B...
  • Page 236 Click on Abandon and explore the data medium until you find the directory containing the new version of the TP8-64 BUS control panel vocabulary. Select the corresponding file (Msg_eng_2.bin) with the mouse and click on Open. Click on Send to start the process.
  • Page 237 The procedure of vocabulary upgrade is initialized and the progress of uploading is viewed. Once uploading of the opening message has been completed correctly (Transmission OK), click on Exit to terminate and quit. TP8-64 BUS - Installer Manual Special procedures - Appendix B B-11...
  • Page 238 Enter the user archive and select the corresponding system from the user list. Open the telephone configuration tables by clicking on the opposite icone. On the screen is viewed: Appendix B - Special procedures Installer Manual - TP8-64 BUS B-12...
  • Page 239 If need be, click on the Stop button to interrupt the process. Once uploading of the opening message has been completed correctly (Transmission OK), click on the Exit button to terminate and quit. TP8-64 BUS - Installer Manual Special procedures - Appendix B B-13...
  • Page 240 Appendix B - Special procedures Installer Manual - TP8-64 BUS B-14...
  • Page 241 TP8-64 BUS APPENDIX C CODE MANAGEMENT TP8-64 BUS - Installer Manual Code management - Appendix C...
  • Page 242 Appendix C - Code management Installer Manual - TP8-64 BUS...
  • Page 243 C. CODE MANAGEMENT The control panel TP8-64 BUS distinguishes the following codes: 1 installer code 1 master code 62 standard user codes C.1 MODIFICATION OF CODE BY USER If during programming (either by PC or console) the modification of the codes by the users has been enabled (see chapter 4 §...
  • Page 244 The installer does not run the risk that his code is discovered. The installer can continue to enter the installer menu using the new procedure only in case his code has been cloned. Appendix C - Code management Installer Manual - TP8-64 BUS...
  • Page 245 TP8-64 BUS - Installer Manual Code management - Appendix C...
  • Page 246 TP8-64 BUS INSTALLER MANUAL Appendix C - Code management Installer Manual - TP8-64 BUS...

This manual is also suitable for:

Tp8-64 bus met
