Summary of Contents for Simplek Stick Pro
- Page 1 Pro – Tuningdongle operation manual...
- Page 2 Attention! Before first use, please read the operation and safety instructions carefully! sIMPLEk-Stick Pro – Tuningdongle 1. General remarks and savety instructions 2. Installation 2.1. Bosch Classic 2.2. Bosch Active- and Performance-Line 2.3. Yamaha 2.4. Brose 3. Handling 3.1. Tuningmode 3.2.
-
Page 3: Installation
The sIMPLEk Pro Tuningmodule, obstructed in a compatible E-Bike, causes the suspension of the factory-integrated speed regarding the support of the motor. Thus, the use of the sIMPLEk Pro Tuningmodule, within the scope of the StVO or on public roads, is forbidden and not accepted. - Page 4 Afterwards the speed sensor and the pin connector of the connection cable have to be connected (Fig. 4). The polarity does not need to be considered. Lay the USB connection cable with the supplied cable ties to the desired position of the sIMPLEk-stick Pro. figure 1...
- Page 5 Afterwards the speed sensor and the pin connector of the connection cable have to be connected (Fig. 12). The polarity does not need to be considered. Lay the USB connection cable with the supplied cable ties to the desired position of the sIMPLEk-stick Pro. figure 6...
- Page 6 (audible clicking noise when snapping into place). Then the motor can be fixed in the frame again and all screws can be installed. Lay the USB connection cable with the supplied cable ties to the desired position of the sIMPLEk stick Pro. figure 9...
- Page 7 Insert the cable ends into the terminal block. Observe the label on the terminal block for correct polarity (Fig. 16). The cables are fixed by pressing on the insulation displacement terminal (Fig. 17). Lay the USB connection cable with the supplied cable ties to the desired position of the sIMPLEk-Stick Pro figure 13...
- Page 8 A change from Tuning Mode to Calibration Mode is made by plugging the sIMPLEk into any active USB port for at least 5 seconds. The next time you plug in the sIMPLEk-Stick on the e-bike, the calibration mode starts directly.
-
Page 9: Tuning Mode
The maximal speed displayed to compensate for the difference in the distance traveled will be resetted by plugging the sIMPLEk-Stick into any active USB port for at least 5 seconds. The next time the sIMPLEk- Stick is plugged in, a new calibration is required, which starts automatically. -
Page 10: Calibration Mode
Carry out calibration again: In order to start the calibration mode manually, plug in the sIMPLEk-Stick into any active USB port for at least 5 seconds. The next time you plug in the sIMPLEk-Stick on the e-bike, the calibration mode starts directly. - Page 11 Environmental protection and disposal Please take into account that the device must not be disposed of with household waste. Warranty Insofar as the device was purchased as a consumer within the EU, the respective transposition of Directive 2011/83 / EU into national law, with regard to the minimum standard of warranty, applies. In countries outside the EU, the respective valid minimum warranty claims apply.
