Page 1: Table Of Contents
美的慢磨榨汁机 Midea Slow Juicer Contents 安全注意事项 Safety Precautions MJ-JS20A1 产品技术参数 Technical Parameters Model 产品部件名称 Part Names 附件说明 Description of Accessories 使用说明 User Instructions 清洁保养 Cleaning and Maintenance Abnormality Analysis and Troubleshooting 营养蔬...
Page 2: 安全注意事项
安全注意事项 Safety Precautions In order to ensure the safety in use and avoid causing injury and property damage to you or others, please be sure to comply with the following safety precautions. Failure to follow the safety warnings and incorrect use may lead to accidents.
Page 3 安全注意事项 Safety Precautions While working, moving products or touching components in motion are forbidden, so as to avoid accident. 禁止将电源线掛於锋利的物体上，且不能连接到可移动的物体。 The power cord is forbidden from hanging on the sharp objects and it cannot be connected to object in motion. 禁止在倾斜的台面或不稳定的台面使用本产品...
Page 4 安全注意事项 Safety Precautions 散发出異味。 After using the product, clean the parts in contact with food as the residual food may corrode to emit a peculiar smell if the product is to be kept idle for long. 如果旋转滤网损坏, 请不要使用器具。 If the rotary strainer is damaged, please do not use the appliance. 产品使用後，请及时拔掉电源及清洗产品。...
Page 5: 产品技术参数
产品尺寸 (mm) 功率（W) 型号工作时间 Operating time Model Product size Power ≤20min 每次 325x191x410 MJ-JS20A1 ≤20min per time 产品部件名称 Part Names 榨汁杯盖主体 Hopper Base 开关 Switch 清洗刷螺旋推进器...
Page 6: 附件说明
附件说明 Description of Accessories 附件名称附件名称数量数量数量附件名称 Accessory name Accessory name Quantity Quantity Accessory name Quantity 滤网果汁杯推料棒 Juice container Strainer Pusher 豆腐盒压块豆腐盒纱布 Tofu box compressing plate Tofu box Gauze 毛刷说明书出汁口盖 Brush Instruction Manual Juice spout cover 注：因产品外观各有差異，上图仅供参考，具体请以包装箱内实体为準...
Page 7 使用说明 User Instructions 4.使用低温保管的紅蘿蔔榨汁时，因材料含水量少，所以最好与梨或橙等水分多的材料一起榨，效果更好。 To juice carrots preserved at low temperature which have less moisture content, it is suggested to put some juicy materials like pear or orange to achieve a better effect. 5.如果材料不新鲜，榨汁量会减少。用冰箱里保管的较乾的材料榨汁时，先把材料泡在清水里充分吸水後再榨汁，效果就更好。 The amount of juice will be reduced if the materials used are not fresh. To extract juice from less juicy materials preserved in refrigerator, you can soak the materials in clean water to fully absorb water before juicing, which will provide a better effect.
Page 8 使用说明 User Instructions 组装方法 Assembly Instruction 1 .榨汁杯底部橡胶垫片的组装方法 How to assemble the rubber gasket at the bottom of juicing bowl 将榨汁底部橡胶垫片一边拔出後，请按下图方向插入。 Pull out one side of the rubber gasket at the bottom of juicing bowl, and insert it in the direction shown in the figure below.
Page 9 使用说明 User Instructions 5.将螺旋推进去安装到滤网中间。 Install the squeezing screw in the middle of the strainer. Install the squeezing screw in the middle of the strainer. 6 .安装榨汁杯盖 Install the hopper 榨汁杯盖标示点 Mark point 榨汁杯示点 Mark point on ”...
Page 10 使用说明 User Instructions 使用方法 How to Use 榨汁：将果蔬往下推榨汁 Juicing: Push fruits or vegetables downward to extract juice 反转：将果蔬往上回笼，能避免正转时发生的卡死现象 Reverse Rotation: Push fruits or vegetables upward to avoid jamming which may occur during forward rotation. 警告：请不要用湿手操作开关。投入...
Page 11 使用说明 User Instructions 榨汁结束後，请旋至“停止”档位，拔下电源线插头。 When juicing is finished, please turn the switch to the “Stop” position and unplug the machine. 警告：榨完的果汁请不要长时间保存。 Warning: Do not preserve the juice for a long period of time. 不适用於粉碎谷物、甘蔗和硬水果的压榨(易造成电机卡死，发生机械性能故障)。 The product is not suitable for processing or pulverizing hard materials such as grains, sugarcanes and hard fruits (because such materials may cause jamming or mechanical failure easily).
Page 12: Cleaning And Maintenance
使用说明 User Instructions ③ 3. 抓住榨汁杯上的出汁口，朝上方向上提即可分离(如图③所示)。 Grasp the juice spout on the juicing bowl and lift it upward to separate the juicing bowl from the base (see Fig. ③. ④ 4. 将榨汁杯里面的螺旋推进器+滤网+刷架组合件取出(如图④所示)。 Take the auger + strainer + brush rack assembly out of the juicing bowl (see Fig. ④). ⑤...
Page 13: 清洁保养
清洁保养 Cleaning and Maintenance 乾乾淨 2. 不要将主体放入水中清洗，一定要使用拧的柔软的布料擦。 Wipe the base clean with a wrung-out soft cloth instead of cleaning it in water. 乾 3. 清洗後，请把清洗乾淨的部件擦，放在乾淨通风的地方保管。 After cleaning, wipe the cleaned parts dry and put them away in a clean and ventilated area. 注意：...
Page 14: Abnormality Analysis And Troubleshooting
Abnormality Analysis and Troubleshooting 故障分析及排除 Troubleshooting 故障可能性原因分析解決对策 Symptom Possible cause Solution 电源插头是否插好将插头插进插座 The power plug is Properly insert the plug into the socket improperly inserted 後先旋转“反转”档位4-5秒，使里面的材料往上返回，後再旋转到“正转”档位（此操作反复做3次左右）。运行中的机器突然一次投入量太多後...
Page 15 Abnormality Analysis and Troubleshooting 異常处理 Abnormality Handling 異異 1.产品如出现常情况如: 常噪音、气味、烟雾等,应立即切断电源,停止使用。 Once the abnormal conditions occur, such as abnormal noise, odors and smoke, disconnect the power and stop using the product. 2.如出现产品不能工作:请检查电源是否连接好,开关是否调至开的位置,配件是否装到位 If the product does not work: please check whether the power supply is connected, the switch is on and the accessories are assembled in place.
Page 16: 营养蔬果汁配方
营养蔬果汁配方 Healthy Recipes for Fruit & Vegetable Juice 材料步骤名称 Name Ingredients Steps 1.冬瓜去皮、去核，切成块。冬瓜：150克 Peel the wax gourd, remove its seeds, and cut it into pieces Wax gourd: 150g 2.苹果带皮去核，切成块。柠檬：30克 Remove the core of the apple without peeling, and cut it Lemon: 30g into pieces.
Page 17 营养蔬果汁配方 Healthy Recipes for Fruit & Vegetable Juice 名称材料步骤 Name Ingredients Steps 1.将雪梨去皮及核，切成块。雪梨：1个 Peel the snow pear, remove its core, and cut it into pieces. Snow Pear: 1 2.将柚子去皮，取一半切成块。蜂蜜雪梨柚子汁柚子：1个 Peel the pomelo; take half of the peeled pomelo and cut it into pieces.
Page 18 营养蔬果汁配方 Healthy Recipes for Fruit & Vegetable Juice 名称材料步骤 Name Ingredients Steps 红萝蔔淨洗，去皮，切成块。苹果：1个 Rinse and peel the carrot, and cut it into pieces. 淨 2.苹果洗，去皮、去核，切成块；橙去皮 Apple: 1 蔔红萝苹果橙汁剥成瓣。...
Page 19: 豆腐制作方法
豆腐制作方法 How to Make Tofu 建议比例： Suggested amounts of ingredients: 泡好的黄豆500克，水1000 ，石膏粉2.7 克克 Soybeans having been soaked in water: 500g; water: 1000g; gypsum powder: 2.7g 黄豆泡发，按一定比例放入水将黄豆浸泡，建议泡豆时间：夏季6-9小时，春秋季8- 12小时，冬季 ① 11-16小时。(附图①) Soak the soybeans in water at a certain soybean-water ratio. Suggested soaking ②...
