PATRIOT™ DB
INSTALLATION GUIDE
Congratulations on your purchase of the PATRIOT DB!
The following seven steps will guide you in installing your system in just a few minutes.
Turn PC Power Off
STEP ONE: Open your PC
STEP TWO: Remove the 5.25 inch face plate
from the front of your PC, and then remove one
of the expansion slot covers on the back.
STEP THREE: Insert the PATRIOT DB into a
drive bay slot and secure using either the screws
provided by Polhemus or the plastic inserts
provided by the PC manufacturer
STEP FOUR: Plug the PC power and the USB
cable in to the back of the PATRIOT.
Page 1 of 2
40 Hercules Drive · P.O. Box 560 · Colchester, VT 05446-0560 · (802) 655-3159 · Fax: (802) 655-1439
U.S. & Canada 1-800-357-4777 · www.polhemus.com · email: sales@polhemus.com
