TouchTunes 600157-001 Product Information

June 2012
900656-001 Rev. 00
Wireless Microphone Receiver and Two Microphones Kit

About This Document

This document is intended for Operators of TouchTunes Virtuo SmartJukes running Karaoke events,
TouchTunes Field Service, Customer Support, and Sales personnel.
It provides information about the TouchTunes Wireless Microphone Receiver and Wireless Karaoke
Microphones, provided as kits, with the TouchTunes parts numbers as follows:
Mic Pair Color
AB Red / Blue
CD Green / Gold
EF Black / Silver

Included in this Kit

Verify that your kit includes all of the following items:
Quantity Description
1 Wireless Microphone Receiver
2 Wireless Karaoke Microphone
4 9-volt batteries
1 Wireless Microphone Receiver and Two Microphones Kit Product
Information Guide (this document)

Microphone Frequency Pairs

In order to reduce the possibility of interference with other locations (or a
second Karaoke installation within a single location), TouchTunes Karaoke
has three distinct frequency pairings of microphones and wireless
microphone receivers.
Pairing 1
A B C
Pairing 3
E * F
* The black ring might be hard to
see, due to the microphone being
black, so if you do not see a
colored ring, you may safely
assume that your microphone has
a black ring.
Product Information
TouchTunes part #
600157-001
600157-002
600157-003
Each wireless receiver is pre-
Pairing 2 configured to operate with two
microphones of a set frequency. The
D
microphones within a pairing are color
coded with a ring around the center.
To make sure you received the correct
microphones, look on the back of the
wireless receiver for two colored
stickers that will show you the colors of the two microphones that it is set to
work with. The wireless receiver and the wireless microphones' frequencies
are set at the factory, and cannot be changed, so as long as the stickers on
the receiver match the microphones, then they are set to function together.
1 of 4
