Summary of Contents for Zonda MZ-X90
- Page 1 Code Revision CALIBRATION GUIDE 1.00.52243.01 Model: Emission date: Page MZ X-70 18/09/2002 DAVID ROBERTO Emitted by: Approved by: Rev. Description Date CALIBRATION GUIDE FOR AUDIO...
- Page 2 Revision Code: CALIBRATION GUIDE 1.00.52243.01 Emission date: Model: Page: 18/09/2002 MZ - X90 Obs.: This procedures can be used to orientation , some item can be changed by the factory engineering for best application and improve the factoring process. FM RANGE Tunning in 87,5 MHz, adjust the coil OSC-FM (L.102) to obtain ~ 2,0 V in the tunnig voltage (terminal 28 of IC101 with resistor of 10K in serie with the voltmeter ).
- Page 3 Revision Code: CALIBRATION GUIDE 1.00.52243.01 Emission date: Model: Page: 18/09/2002 MZ - X90 TRACKING-AM It AM sweeping radiates to a ferrite antenna . Tunning in 600 kHz and adjust the coil ANT-AM (T.102) to obtain maximum output signal. Tunning in 1400 kHz and adjust VC.101 to obtain maximum output signal. Remake the adjust three times to obtain the best adjust point.
