TurboStart S12V680 Instructions

TurboStart is committed to bringing you the highest quality battery systems available, but we also stand
®
behind our product. Customer service is just as important as performance at TurboStart
have an excellent core of technicians ready to help you with any product recommendations, installation
questions or any other questions you may have about your TurboStart

12V Battery Specifications

Part Number Length Width
S12V680 7.13" 2.99"
S12V925 6.54" 6.89"
S12V975 7.84" 5.29"
S12V1200 7.76" 6.54"
S12V3465 10.24" 6.89"
S12V31125 12.99" 6.81"

Mounting Position

AGM Series batteries can be mounted either parallel or perpendicular to the frame rails. If you are running a dual battery set-up, make sure that the batteries are hooked up in PARALLEL
(positive post to positive post and negative post to negative post). The AGM Series battery does not require the use of a vent outlet tube.
CAUTION!!! TAKE ALL POSSIBLE PRECAUTIONS TO NOT ARC THE TERMINALS OR TOUCH THE POSITIVE POST AT THE SAME TIME WITH ANY METAL OBJECT
AS THIS COULD CAUSE INTERNAL BATTERY DAMAGE! ALWAYS WEAR SAFETY GLASSES, GLOVES, AND PROTECTIVE CLOTHING WHEN SERVICING OR IN-
STALLING A BATTERY!
"Bolt-In" Terminals Design
The TurboStart AGM Series 12 volt battery features a Bolt-in terminal design, allowing the use of a low profile eyelet style lug terminal at the battery connection. Also available are positive and negative brass
®
SAE top-post adaptors, or stud adaptors that can be threaded into the bolt-in terminals on the top of the battery when using standard SAE, or other style battery terminals. Whether using the stud adaptors or
the brass top post adaptors, the tightening torque should never exceed 8 ft-lbs max!
IMPORTANT: OBSERVE POLARITY CAREFULLY WHEN CONNECTING THE BATTERY CABLES.
12V BATTERY INSTRUCTIONS
Congratulations! You've made the right choice with
your purchase of a quality TurboStart
Product for your vehicle. You have joined thousands
of other satisfied performance enthusiasts, engine
builders, chassis builders and professional race
drivers that rely on the TurboStart
*Height Weight CA @ 32° F CCA @ 0° F RC @ 25 amps
6.58" 13.75lbs. 370
4.92" 22.18lbs. 641
6.68" 26.68lbs. 604
6.69" 34.99lbs. 740
7.01" 49.91lbs. 1150
8.66" 78.31lbs. 1565
product.
®
Ah Max Charge Voltage
235 28 20
425 48 32
440 50 43
600 80 55
850 135 80
1330 273 127
Performance
®
brand name.
®
, which is why we
®
Cells Per Battery Terminals
14.4 6 M6 Bolt-in
14.4 6 M6 Bolt-in
14.4 6 M6 Bolt-in
14.4 6 M6 Bolt-in
14.4 6 M6 Bolt-in
14.4 6 M6 Bolt-in
