- Page 1 Installation instruction Motor-driven blocking device EasyBlocker 108320 VdS - Class C G 196 089 G 197 051 108320Err_ENG.doc version 6.0a / 06.04.2016 page 1...
-
Page 2: Table Of Contents
MALFUNCTIONS ....................13 Electrical emergency opening ....................14 Mechanic emergency opening....................14 Replace the bolt ......................... 15 TECHNICAL DATA ....................16 DRILLING TEMPLATE....................17 Installation instruction Motor-driven blocking device EasyBlocker 108320 Item No: 108320.x Version: 6.0a / 06.04.2016 MA Document: 108320Err_ENG.doc © Copyright 2016: BSS Baumann Sicherheitssysteme GmbH page 2 version 6.0a / 06.04.2016... -
Page 3: Introduction
Motor-driven blocking device EasyBlocker 108320 Installation instruction 1 Introduction 1.1 General information The blocking device serves to mechanically lock doors in order to avoid unintended entry of specially activated security areas in connection with a burglar alarm system or to refuse access to unauthorized persons for access control applications. -
Page 4: Installation
Motor-driven blocking device EasyBlocker 108320 Installation instruction 2 Installation The most advantageous installation place is as near as possible to the existing striking plate of the lock since in this position it will have minimum effects if the door gets distorted. The blocking device can be installed at any position. -
Page 5: Counterpart
Motor-driven blocking device EasyBlocker 108320 Installation instruction 2.1.2 Counterpart The counterpart is assembled in the door leaf. It needs to be assembled in a way that the bolt can extend to the limit stop without contact. The maximum distance between the cuff plate and the counterpart amounts to 8 mm. -
Page 6: Emergency Opening
Motor-driven blocking device EasyBlocker 108320 Installation instruction 2.1.4 Emergency opening Electrical emergency opening: The connecting wires of the supply voltage need to be led to a position which is easily accessible in case of an error (e.g. behind the bell or the cover of the communicator, or others) in order to be able to use the electrical emergency opening options. -
Page 7: Electrical Connection
Motor-driven blocking device EasyBlocker 108320 Installation instruction 2.2 Electrical connection 8320AB203en.tif Illustration 2-3 - Connection plan Inputs and outputs of the blocking device Signal Lead color Description +12V Supply +12 V Blue Supply 0 V Opened Green Input blocking device "Opened" Closed Brown Input blocking device "Closed"... -
Page 8: General Information
Motor-driven blocking device EasyBlocker 108320 Installation instruction 2.2.1 General information The device can be switched on in 6 different ways. In doing so, the actuation is enabled with a static signal or 2 dynamic signals. The polarity of the input signals is arbitrary due to an mutual connection. Furthermore, there are 2 outputs available which signalize the status of the blocking device. -
Page 9: Actuating With A Static Signal
Motor-driven blocking device EasyBlocker 108320 Installation instruction 2.2.3 Actuating with a static signal This may be the activated and not activated exit of an BURGLAR ALARM CENTER or it may be a timely limited release signal for access control applications. Static signal at the open entry When activating the Open entry the blocking device opens, when deactivating the blocking device closes. -
Page 10: Switching On Several Blocking Devices
Motor-driven blocking device EasyBlocker 108320 Installation instruction 2.2.4 Switching on several blocking devices It is possible to switch blocking devices in parallel so that they all close at the same time. The control output(s) of the BURGLAR ALARM CENTER are only loaded at minimum due to the little input current of the blocking device (about 3 mA per input). - Page 11 Motor-driven blocking device EasyBlocker 108320 Installation instruction Connect several blocking devices in series for standard version 8320AB212en.tif Illustration 2-12 Connect several blocking devices in series for battery version 8320AB213en.tif Illustration 2-13 108320Err_ENG.doc version 6.0a / 06.04.2016 page 11...
-
Page 12: Magnetic Contact And Door Monitoring
Motor-driven blocking device EasyBlocker 108320 Installation instruction 2.3 Magnetic contact and door monitoring The integrated VdS-B magnetic contact (G 197 541) which is completely independent from the blocking device (only for the according items) can be directly connected to a burglary alarm line of the BURGLAR ALARM CENTER. -
Page 13: Malfunctions
Motor-driven blocking device EasyBlocker 108320 Installation instruction ⇒ The bolt must neither contact nor interlock on the counterpart. The bolt extends without performing several locking trials. ⇒ The bolt can extend to full length since otherwise it would open up again after several locking trials. -
Page 14: Electrical Emergency Opening
Motor-driven blocking device EasyBlocker 108320 Installation instruction 3.1 Electrical emergency opening Automatic opening of the blocking device after interrupting and switching on the distribution voltage again Independent from the fact if the control signal is fed, the blocking device will always open up after feeding the distribution voltage. -
Page 15: Replace The Bolt
Motor-driven blocking device EasyBlocker 108320 Installation instruction 3.3 Replace the bolt If necessary, the bolt can be replaced. To do so, please proceed as follow: 1. Disconnect the power supply from blocking device. 2. Dismount the blocking device from the door frame (loose the two screws from cuff plate). -
Page 16: Technical Data
Motor-driven blocking device EasyBlocker 108320 Installation instruction 4 Technical data Operating nominal voltage 12 V DC Operating voltage range 7 V DC to 15 V DC Current consumption at rest (entries inactive) about 1.2 mA (standard version) about 40 µA (battery version) Current consumption during locking process about 35 mA / 12 V DC... -
Page 17: Drilling Template
Motor-driven blocking device EasyBlocker 108320 Installation instruction 5 Drilling template Attention: Drilling templates on a scale of 1:1 Please copy this page and cut out the drilling templates! 8320AB51en.eps 8320AB52en.eps Illustration 5-1 - Drilling template emergency opening Illustration 5-2 Hole (ø6 mm) depending on the position of the cable entry point Drilling template (A) or (B) to be performed at point A' or B' Magnet position at the door leaf...
