Asaklitt MF-H05 Instruction Manual

Rechargeable Head Torch
Art.no 36-6069 Model MF-H05
Please read the entire instruction manual before using the product and then
save it for future reference. We reserve the right for any errors in text or images
and any necessary changes made to technical data. If you have any questions
concerning technical problems please contact our Customer Services.
Safety
• Do not point the light beam into anyone's eyes.
• Do not let children play with the product.
• Never charge the torch in flammable environments or on flammable
surfaces.
• Only use the rechargeable batteries provided with the product.
• Only use the provided charger cable, connected to a USB port, for
charging the torch.
• Never use a defective charger cable.
• Never expose the batteries to fire or high temperatures.
• Avoid contact with leaking batteries.
Product description
1 2 3
6 7 8
10 11 12 13
GREAT BRITAIN • CUSTOMER SERVICE tel: 020 8247 9300 e-mail: customerservice@clasohlson.co.uk internet: www.clasohlson.co.uk postal: 10 – 13 Market Place, Kingston Upon Thames, Surrey, KT1 1JZ
1. LED lamp
2. Magnetic headband mounts (for LED lamp and battery pack)
3. Handlebar or pipe mount for worklight use
4. Battery pack
5. Magnetic charger connection
6. Charging indicator
7. Magnetic charger lead connector
8. Charger cable
9. USB charger plug
10. Batteries: Type 18650 (2 ×)
11. Battery cover
12. Focus ring
13. Battery pack and LED lamp magnetic mounts, used together with (2) or (3)
14. Power switch
Inserting the batteries
Remove the battery cover (11) and insert
the included rechargeable 18650 type
batteries according to the battery pack's (4)
polarity markings. Note: The batteries are
connected in parallel and should all point
the same direction when inserted into
the battery holder. Press the lid firmly onto
the battery pack.
2 4 5
Charging the head torch
The torch has a magnetic charger connection for the charger cable. The torch
can only be charged using the included charger cable.
1. Connect the supplied charger cable to a USB charger.
2. Connect the other end of the charger cable to the magnetic charger
connection (5) on the battery pack. The charging indicator (6) shines
red while the torch battery is charging. When the battery is fully charged
the indicator will shine green.
3. The battery will need at least 10 hours to fully charge (applies when using
a USB charger providing a charging current of 1 A) the first time it is
charged. Charging using a computer's USB port will double the standard
charge time as the amperage from it will be lower.
4. The charge connection is held together magnetically, make sure that
the lead's plug is positioned correctly. Note: Charging time can vary
depending on the type of charge source used.
9
Use
Areas of use: Head torch, worklight and bicycle headlight.
14
The LED lamp and battery pack are held in place magnetically both
on the headband and handlebar mount, or also on any ferrous metal
surfaces, e.g. iron and steel.
1. Press the power switch (14) to turn on the torch. Select the desired mode
by pressing the power switch the required number of times: high power
(350 lm) – low power (150 lm) – off.
2. The torch also has a boost-mode for increasing light intensity (450 lm).
To activate boost-mode: Hold the power switch down for about 4
seconds until light intensity powerfully increases. Boost-mode lasts for
about 60 seconds and then returns to high-power mode.
3. Adjust the light beam by moving the focus ring (12) forwards or
backwards.
ENGLISH
Head torch Work light
Bicycle headlight
Loosen and remove the lock knob (15).
Bend and open the ring bracket so that you
can place it onto the handlebars. Insert one
or several of the rubber spacers (16) into
the ring bracket to attain a perfect and tight
fit onto the handle bars. Re-insert and tighten
the locking knob, making sure the handlebar
mount sits securely onto the handlebars.
Care and maintenance
Clean the torch using a soft, damp cloth.
Never use cleaning agents or other chemicals.
Responsible disposal
This symbol indicates that this product should not be disposed of
with general household waste. This applies throughout the entire EU.
In order to prevent any harm to the environment or health hazards
caused by incorrect waste disposal, the product must be handed in
for recycling so that the material can be disposed of in a responsible
manner. When recycling your product, take it to your local collection
facility or contact the place of purchase. They will ensure that
the product is disposed of in an environmentally sound manner.
Specifications
Charging voltage 5 V DC from a USB charger
(USB charger sold separately)
Li-ion-battery 2800 mAh (type 18650) (2 ×)
Battery
Operating time Up to 3.5 hours (on high power),
up to 6 hours (on low power)
Colour temperature 6000 K
Ra 70
Colour rendition
Power 10 W
Lumens 450 lm (60 sec in boost-mode),
350 lm (high power), 150 lm (low power)
Operating temperature −20 to +50 ºC
Protection class IPX4
Weight Approx 325 g (battery pack, LED lamp
and headband)
16 15
