Conbrov T17 Dash Cam
User Manual
Model No.: T17

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the T17 and is the answer not in the manual?

Questions and answers

Summary of Contents for Conbrov T17

  • Page 1 Conbrov T17 Dash Cam User Manual Model No.: T17...
  • Page 2: Table Of Contents

    Table of Contents Part 1:Before First Use ..........1-2 Part 2:Quick Guide ............3 Part 3: Detailed User Manual ......... 4-24 Part 3 Detailed User Manual What's included ............6 Button specification ..........8-9 Charging your camera ..........10 Installing SD card ............10 Setting the date and time ..........
  • Page 3: Part 1:Before First Use

    Part1: Before First Use Charging the camera Before the first use, please charge the camera to full power. While charging, the LED lights turn yellow and then turn off when the camera is fully charged. Yellow indicator Yellow indicator Formatting the micro SD card Before the first use, please format the micro SD card to FAT 32 format.
  • Page 4 Part1: Before First Use Resetting the camera If the camera malfunctions for any reason, reset it with the included pin. A small paper clip can also be used.
  • Page 5: Part 2:Quick Guide

    Part2: Quick Guide A.Install the micro SD card B.Set up the camera C. Turn On/Off and record D.Play the video USB2.0 For more detailed information, see Part 3:Detailed User Manual.
  • Page 6: Part 3: Detailed User Manual

    Safety precautions • Read this instruction manual carefully before using the camera. It contains important information for your safety as well as operating and maintenance instructions. • Follow all safety precautions in order to prevent damage due to improper use of the camera. •...
  • Page 7 Warning on invasion of privacy The camera should be used for legal purpose only. Follow the laws of your country. Recording and circulating an image of an individual may constitute an infringement of their privacy for which you could be liable. Ask for authorization before filming individuals, particularly if you want to keep your recordings and/or circulate images on the Internet or any other medium.
  • Page 8: What's Included

    What's included Car charger Camera Car bracket USB cable Card reader Conbrov T17 Dash Cam User Manual Model No.: T17 User manual...
  • Page 9 T17 diagram Menu Record/Enter Mode Power Micro SD Down card Reset...
  • Page 10: Button Specification

    Button specification A.Power B.Record/Confirm Press and hold the power button for In standby mode, press”OK” 2 seconds, the camera makes a button and switch to recording start-up sound and the screen lights mode. up and then enters into standby mode; press the power button for 2 seconds again, the camera makes a shutdown sound and its screen goes out and...
  • Page 11 Button specification E.Select up/down In menu/mode mode, press “up/down” button, then you can choose the menu items. F. Reset If the camera malfunctions for any reason, You can use the included pin to push the reset button to reset. When resetting is successful, the camera will turn off right away.
  • Page 12: Charging Your Camera

    Directions for your Conbrov T17 Camera 1. Charging your camera Yellow indicator Yellow indicator (1)There are two ways of charging: one is charging by car charger(included) and the other is charging via your PC. (2)The yellow LED is on while charging and turns off when the camera is fully charged.
  • Page 13: Setting The Date And Time

    Directions for your Conbrov T17 Camera 3. Setting the date and time Press the menu button into menu items two times, then press the“down” button to select ”Date/Time”, press the “OK” button, and you'll see the date and time. Then, press the “up”...
  • Page 14: Directions For Function Operation

    Directions for your Conbrov T17 Camera 1. How to Record Manually Press and hold the power button to turn on the camera into standby mode, and press the “OK” button to start recording. Then, you'll see a flashing red icon on the screen.
  • Page 15: About Menu Button

    Directions for your Conbrov T17 Camera 5. A bout Loop Recording When in standby mode, press “menu” button into menu items and select “Loop recording”.Then press “OK”. You'll see “Off”,“Three Minute,”“Five Minute” ,and “Ten Minute” options. If you choose “Off”, it will turn off the loop recording function.
  • Page 16: About Loop Recording

    Directions for your Conbrov T17 Camera 3. About Menu Button When in standby mode, press the “menu” button to enter into the menu items. Then, you can press the “up” and “down” buttons to select menu items. 4. About Mode Button In standby mode, you can press the “mode”...
  • Page 17: About Date Stamp

    Directions for your Conbrov T17 Camera 7. A bout Date Stamp When in standby mode, press menu button to menu items and select “Date Stamp”. Then press “OK”. You'll see “Off” and “On”options. When you choose ”On”, press “OK”. Press the menu button two times to get back to standby mode.
  • Page 18: About Language Setting

    Directions for your Conbrov T17 Camera 9. A bout Language Setting When in standby mode, press menu button two times into the menu items and select “Language”. Then press ”OK”. You'll see several language options. Choose your national language and press “OK” to save the setting.
  • Page 19: About Automatic Screen Savers

    Directions for your Conbrov T17 Camera 11. A bout Automatic Screen Savers When in standby mode, press menu button two times to menu items and select “Screen Savers”. Then, press “OK”. You'll see “Off”,“Three Minute”, “Five Minute” and ‘“Ten Minute” options. If you choose “Off”, t h e c a m e r a w o n ' t s h o w u p S c r e e n S a v e r s automatically during recording.
  • Page 20: About Frequency

    Directions for your Conbrov T17 Camera 13. A bout Frequency When in standby mode, press menu button two times to menu items and select “Frequency”. Then, press “OK.” You'll see “50HZ” and “60HZ” options. Select the option you need and press “OK” to save the setting.
  • Page 21: About Video Rotate

    Directions for your Conbrov T17 Camera 15. A bout Sensor Flip When in standby mode, press menu button two times to menu items and select “Sensor Flip” .Then, press “OK.” You'll see “Off” and “On” options. When you choose “Off”, videos won't rotate with the direction of the camera when recording, in this case, the video would be upside-down.
  • Page 22: About Video Preview

    Directions for your Conbrov T17 Camera 17. A bout Video Preview When in standby mode, press menu button to menu items, and press and hold the MODE button to enter into the Video Preview Interface. Then, press “up” and “down” buttons to select videos. Press “OK” to start playing the video.
  • Page 23: About Photographing

    Directions for your Conbrov T17 Camera About Photographing While in standby mode, press the “mode” button, then camera icon will be on the top left corner of the screen. Press the “OK” button, it will take photos. 20. A bout Recording Audio In standby mode, press “menu”...
  • Page 24: Technical Specifications

    Technical Specifications  1.5 inch LCD Size Car Charger; Power Supply Output: 5V,1A 85mAh Battery Capacity  Video Format VGA 640×480,HD1280×720 Resolution HFD1920×1080 110° Lens Angle SD Card Capacity MAX 32GB Supported Range Power Consumption 220mAh Micro 5P USB Interface Type...
  • Page 25: Led Status

    LED Status Steady yellow Charging Yellow LED turns off Fully charged No indicated light,Flashing red Recording icon on the screen No indicated light,Red Recording Paused icon stops flashing No indicated light,Screen Reading Data from shows USB mark SD card No indicated light,Screen No MicroSD connected shows no SD card connected...
  • Page 26: Faqs

    FAQS 1. Q: What should I do when all the operations malfunctioned? A: Please try to reset the camera, there is a pin included in the package, and you can use it to push the reset button to reset the camera. 2.
  • Page 27: Warranty

    Warranty All products sold by the Conbrov Group are covered by a 12-month full replacement warranty. Happy with it? Share your experience with an Amazon review. Or any questions? Our friendly customer service team is ready to help: support@conbrov.com Contacting us via the above email address,which is the quickest way to reach our support team.
  • Page 28 All trademarks or registered trademarks are the property of their respective owners. About Us Conbrov Electron Co., Ltd. founded in 2003 is an innovative technology research company specialized in personal surveillance cameras and on-dash cameras. Conbrov products and technology are patent protected by PCT or U.S. Patent Office.
