ECO RAPID DOOR
USER'S AND INSTALLER'S MANUAL
v4.0
REV. 08/2019

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ECO and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Motorline professional ECO

  • Page 1 ECO RAPID DOOR USER'S AND INSTALLER'S MANUAL v4.0 REV. 08/2019...
  • Page 2: Table Of Contents

    00. CONTENT 01. SAFETY INSTRUCTIONS INDEX STANDARDS TO FOLLOW 01. SAFETY INSTRUCTIONS This product is certified in accordance with European STANDARDS TO FOLLOW Community (EC) safety standards. 02. PACKAGE INSIDE PACKAGE This product complies with Directive 2011/65/EU of the 03. AUTOMATISM European Parliament and of the Council, of 8 June 2011, on TECHNICAL SPECIFICATIONS the restriction of the use of certain hazardous substances in...
  • Page 3 01. SAFETY INSTRUCTIONS GENERAL WARNINGS • Children shouldn’t play with the product or opening devices to avoid the motorized door or gate from being triggered involuntarily. • This manual contains very important safety and usage information. very important. Read all instructions carefully before beginning the WARNINGS FOR TECHNICIANS installation/usage procedures and keep this manual in a safe place that it can be consulted whenever necessary.
  • Page 4 01. SAFETY INSTRUCTIONS RESPONSABILITY • September 2009. • Attach the permanent label for the manual release as close as possible • Supplier disclaims any liability if: to the release mechanism. • Product failure or deformation result from improper installation • Disconnect means, such as a switch or circuit breaker on the electrical use or maintenance! panel, must be provided on the product’s fixed power supply leads in •...
  • Page 5: Package

    02. PACKAGE 03. AUTOMATISM INSIDE PACKAGE TECHNICAL SPECIFICATIONS ECO rapid door are manufactured with own profiles of white lacquered aluminum, suitable for areas with low air pressure. With 1 reinforcement bars. Motor Safe Coverage Aluminum Profile MOTOR TARPAULIN • Power Supply...
  • Page 6: Dimensions - Normal Kit 5A

    03. AUTOMATISM 03. AUTOMATISM DIMENSIONS - NORMAL KIT DIMENSIONS - TUNNEL KIT Dimensions shown in mm. Dimensions shown in mm. Passage Span width - 280 Overall span Passage Span width (max. 3000) height (max. 3000) Passage Passage Span For leg protection, the Span Height Height - 305 installation is made 20mm...
  • Page 7: Installation

    04. INSTALLATION INSTALLATION MAP 1 • 8 • 15 • Aluminum safe profile Connector Connections Photocell fixation plate 2 • 9 • 16 • Lateral Guides Motor unlock lever Mirror fixation plate 3 • 10 • Emergency stop 17 • Motor protection Mirror protection plate 4 •...
  • Page 8: Safe Profile Fixation

    04. INSTALLATION SAFE PROFILE FIXATION MINIMUM DIMENSIONS POSITIONING SAFE 330mm Minimum lintel - Apply the safe to the wall of the installation site, paying attention to the horizontal level 290mm Minimum jamb (engine side) - and 85mm between the base of the support plate and the beginning of the passa span. 155mm Minimum jamb (opposite side) - The safe should be centered with the gap.
  • Page 9: Lateral Guides And Control Board Fixation

    04. INSTALLATION LATERAL GUIDES AND CONTROL BOARD FIXATION APPLY LATERAL GUIDES Place the lateral guides by placing them on the inside of the support plates and against the wall. The tarpaulin must be inside the lateral guides so that it can always go up and down inside.
  • Page 10: Installation Kit Tunnel

    05. INSTALLATION KIT TUNNEL SAFE PROFILE FIXATION Safe profile completely against the walls and ceiling. POSITION SAFE Insert the safe into the tunnel and apply at the desired location for installation, taking into account the horizontal leveling. Based on the holes in the support plates, mark the locations for drilling.
  • Page 11: Lateral Guides And Control Board Fixation

    05. INSTALLATION KIT TUNNEL LATERAL GUIDES AND CONTROL BOARD FIXATION APPLY LATERAL GUIDES Place the legs by placing them on the inside of the support plates and against the wall. The tarpaulin must be inside the legs so that it can always go up and down inside. Secure the legs to the support plates with screws, tightening them to the females on the legs.
  • Page 12: Limit-Switches

    06. LIMIT-SWITCHES LIMIT-SWITCHES ADJUSTMENT • ADJUSTMENT • CONNECTIONS The ring 2 should activate the micro switch from below, and the ring 1 should activate the micro switch from above, as shown in the image below. CLOSE OPEN Manually place the door in the area you want for the opening slowdown. Turn the adjusting screw 2 until the limit switch 2 activates the corresponding microswitch.
