- Page 2 ©2019 OBSIDIAN CONTROL SYSTEMS all rights reserved. Information, specifications, diagrams, images, and instructions herein are subject to change without notice. Obsidian Control Systems logo and identifying product names and numbers herein are trademarks of ADJ PRODUCTS LLC. Copyright protection claimed includes all forms and matters of copyrightable materials and in- formation now allowed by statutory or judicial law or hereinafter granted.
-
Page 3: Table Of Contents
C O N T E N T S GENERAL INFORMATION LIMITED WARRANTY SAFETY GUIDELINES OVERVIEW SOFTWARE CONNECTIONS FUSE REPLACEMENT MAINTENANCE SPECIFICATIONS DIMENSIONS... -
Page 4: General Information
G E N E R A L I N F O R M AT I O N INTRODUCTION Please read and understand the instructions in this manual carefully and thoroughly before attempting to operate this device. These instructions contain important safety and use information. UNPACKING Every device has been thoroughly tested and has been shipped in perfect operating condition. -
Page 5: Limited Warranty
(730 days). 2. For warranty service, send the product only to the Obsidian Control Systems service center. All shipping charges must be pre-paid. If the requested repairs or service (including parts replacement) are within the terms of this warranty, Obsidian Control Systems will pay return shipping charges only to a designated point within the United States. -
Page 6: Safety Guidelines
This device is a sophisticated piece of electronic equipment. To guarantee a smooth operation, it is important to follow all instructions and guidelines in this manual. OBSIDIAN CONTROL SYSTEMS is not responsible for injury and/or damages resulting from the misuse of this device due to the disregard of the information printed in this manual. -
Page 7: Overview
The NX4 is a comprehensive feature packed control surface. With a well-arranged combination of motorized and manual faders, as well as an array of playback buttons, the NX4 offers 44 total playbacks in a compact yet extremely powerful package. As a member of the innovative ONYX platform from Obsidian Control Systems, the NX4 is feature rich and never restricted in its capabilities. -
Page 8: Connections
90-264V 50/60Hz. Do not connect it to power outside this range. Damage resulting from incorrect connection is not covered under warranty. North America: A cable with a NEMA 15-5P plug is provided for use with the NX4 in the USA and Canada. This approved cable must be used in North America. - Page 9 C O N N E C T I O N S : F R O N T & S I D E ( R ) P A N E L S The surface panel offers a USB device socket in the top left-hand corner. This connector is ideally suited for USB memory sticks or a USB desk lamp.
- Page 10 C O N N E C T I O N S : R E A R P A N E L 4 x DMX / RDM Universe In/Out: 5-pin locking XLR External Display: 2x DisplayPort (up to 4k) External Display Power: 12V, 2x Molex 8pin Network: 2x Gigabit EtherCon for Art-Net, sACN and ONYXX-Net Storage and Peripherals: 3x USB 3.0, 3x USB 2.0 Audio Out, Mic In: 2x 6.3mm Jack...
-
Page 11: Fuse Replacement
F U S E R E P L A C E M E N T 1. Fold the desk lights as if transporting, which is straight on the back of the controller. 2. The open screen is used to hold the front panel in the open position. With a Torx T-20 screwdriver, unscrew the 4 screws below the handrest, and lift the front panel. - Page 12 3. Using a 4mm flat screw-driver, open the fuse holder with a quarter clockwise turn to pull the fuse holder out of its socket. See compliance label at the bottom of the controller for replacement fuse size. To close the fuse holder, press the fuse holder back in the socket and turn a quarter turn clockwise until closed.
-
Page 13: Maintenance
Fuse Replacement: Single fuse in the Line side; the NX4 is protected by a single 2A slow blow mains fuse in a fuse holder on the inside of the controller on the PSU cover. Disconnect the product from AC mains power before replacing the fuse as parts of the... -
Page 14: Specifications
SPECIFICATIONS Control Surface Physical 10x 60 mm motorized playback faders, each with 4x Length: 16.9 in. (431mm) function-assignable buttons, digital backlit labels Width: 36.5 in. (928mm) 12x 45mm Sub Playback Fader with Flash keys Height: 5.8 in. (149mm) 22x Playback Executors Weight: 36.1 lbs. -
Page 15: Dimensions
D I M E N S I O N S (Drawing not to scale) 15.1” (383mm) 5.8” (149mm) 36.5” (928mm) 13.5” (343mm) ~4.3” (109mm) ~4.7” (119mm) 17.0” (431.6mm) 16.4” (415.6mm) 38.25” (972mm)
