Summary of Contents for Turbolock TL-201
- Page 1 In order to continue serving our customers and providing the best products, our product information including our user manuals may receive updates from time to time. Please check our website for the latest user manuals and product materials. Ver. 2.0 1/16/19...
- Page 2 Customer Service: 855-850-8031...
-
Page 3: Table Of Contents
Table of Contents Section 1 Section 5 Section 9 Information & Safety Warnings Using the Lock Maintenance 1.1 Introduction Section 6 Section 10 1.2 Safety Warnings Keypad Passwords Troubleshooting 1.3 End-of-Life Disposal 6.1 Changing the Admin Password Section 2 Section 11 6.2 Adding User Passwords Overview Warranty... -
Page 4: Information & Safety Warnings
1.1 Introduction This user manual will guide you through the functions and usage of your TurboLock TL-201. It is important that you follow all instructions and regard all notes that appear throughout this manual. Consult this manual before you attempt to use your lock. -
Page 5: End-Of-Life Disposal
The substances contained inside the battery present chemical risks to the environment. The recommended disposal for any TurboLock TL-201 at its end-of-life is to dispose of the entire unit at or through an e-waste recycling center, program, or facility. Local regulations and laws pertaining to the recycling and disposal of certain batteries and/or products containing them will vary according to country, state, and local governments. -
Page 6: Overview
” 3 / 8 ” 2 3 / 4 Adjustable Latch Assembly Mounting Screws Wood Screws Inside Screws Strike Plate 2-3/8” (60 mm) or 2-3/4” (70 mm) TurboLock TL - 201 ” 3 / 8 ” 2 3 / 4... -
Page 7: Product Parts
2.2 Product Parts Battery Compartment (Batteries not included.) Keypad Battery Cover L/R Switch Keyhole Reset Button Thumb Turn Micro USB Port TurboLock TL - 201... -
Page 8: Battery Information
• For easier installation, have another person help hold the lock. • Remove all parts of any old lock before installing the TL-201. In some cases, the old strike plate and/or box may be used. • For your convenience, installation instructions are broken into segments. Read and follow the instructions for both Pre- Installation and Main Installation. - Page 9 Step 1. With the door open, check it from the back and/or inside of the room. The lock’s parts should be oriented differently depending on whether the lock will be on the left side or right side of the door. TurboLock TL - 201...
-
Page 10: Main Installation
” 2 3 /4 inserting. • It’s highly recommended to leave the door open and keep the keys in the lock during installation. • Make sure the power cables are under the latch. Latch Pin (Fig. 4) TurboLock TL - 201... - Page 11 • Thread the cables through the opening in the corner of plate. ” ” ” ” ” 3 / 8 ” 2 3 / 4 (Fig. 5) TurboLock TL - 201...
- Page 12 Step 6. With the inside section flat against the back of the door, use the 4 x inside screws to fasten it to the back of the door. Note the placements for the different sized screws. Make sure all screws are tightened. (Fig 8.) Silver Center Part Latch Pin (Fig. 7) (Fig. 8) Plate TurboLock TL - 201...
-
Page 13: Installation (New)
Installation (New) This section details installation steps needed if you are installing the TL-201 on a door without a cutout. If you are using the TL-201 to replace an old lock or if your door otherwise already has a cutout, please go back to page 8. - Page 14 Insert the latch back into the door. Step 5. Add 2x wood screws and use a screwdriver (not included) to secure them. TurboLock TL - 201...
- Page 15 During chiseling, it’s highly recommended to stop and check that the strike plate sits flush in the doorframe over the strike box. If not, chisel a little more and check again. Be careful not to chisel too deep; otherwise, the lock may not function correctly after installation. TurboLock TL - 201...
- Page 16 Step 2. Remove the battery cover from the inside section of the lock and adjust the L/R Switch and thumb turn as needed. Latch on the right Latch on the left L/R switch pushed to L/R switch pushed to R side + thumb turn L side + thumb turn horizontal vertical Inside Section Inside Section TurboLock TL - 201...
-
Page 17: Main Installation
Do NOT force the screw through the cables as this will damage the lock and/or make it unusable. ” ” ” ” ” 3/ 8 ” 2 3/ 4 (Fig. 11) TurboLock TL - 201... - Page 18 Step 6. With the inside section flat against the back of the door, use the 4x inside screws to fasten it to the back of the door. Note the placements for the different sized screws. Make sure all screws are tightened. (Fig. 13) Silver Center Part Latch Pin (Fig. 12) (Fig. 13) TurboLock TL - 201...
-
Page 19: Using The Lock
In general, there are two ways to unlock your door: using keys or using the keypad to enter the password, then pressing the button. The lock will engage. Regardless of unlock method, the TL-201 will not lock again on its own. To lock the door, close it, wait for the keypad light turns off, then press the button. -
Page 20: Keypad Passwords
• For security, it is highly recommended that you change the Admin Password from the default. Step 1. First, make sure the TL-201 is fully unlocked. Then, use the keypad to enter the default (‘123456’) or current Admin Password, then press the button. -
Page 21: Changing User Passwords
• User passwords must be 4~6 digits long. • Do not use the same combination for admin and user passwords. Step 1. First, make sure the TL-201 is fully unlocked. Use the keypad to enter the current Admin Password, then press the button. -
Page 22: Deleting All User Passwords
6.4 Deleting all User Passwords First, make sure the TL-201 is fully unlocked. Then, use the keypad to enter the current Admin Password, then press the button. The lock should beep and the backlight should turn blue again. Quickly enter ‘4’ and press the button before the light turns off. -
Page 23: Resetting The Lock
Step 2. Press and hold the reset button for at least three seconds. Option 2 Step 1. First, make sure the TL-201 is fully unlocked. Use the keypad to enter the Admin Password, then enter Step 2. Wait for the backlight to flash red and then blue. Enter ‘9’ and then press before the blue back light turns off. -
Page 24: Maintenance
• Do not let water and liquids get into the lock’s electric parts or battery compartment. Section 10 Troubleshooting If none of the following resolves your issue, please visit our website at www.turbolock.com or contact customer service at 855-850-8031. Problem... - Page 25 I forgot my codes. The codes were not properly recorded. back of the door. Once a reset is performed, record the passwords in memory or a secure location. TurboLock TL - 201...
-
Page 26: Warranty
One-Year Limited Hardware Warranty Your TurboLock TL-201 (“Product”) includes a One-Year Limited Hardware Warranty (“Warranty”). The Warranty covers product defects in materials and workmanship under normal use. This Warranty is limited to residents of the United States and Canada and is available only to original purchasers. - Page 27 THE ABOVE LIMITATION OR EXCLUSION MAY NOT APPLY TO YOU. THE DURATION AND REMEDIES OF ALL IMPLIED WARRANTIES, INCLUDING WITHOUT LIMITATION THE WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE ARE LIMITED TO THE DURATION OF THIS EXPRESS LIMITED WARRANTY. TurboLock TL - 201...
- Page 28 COPYRIGHT @ 2018 TURBOLOCK. ALL RIGHTS RESERVED.
