Table 8. Default switch module settings
Setting
Switch name
Default switch mode
IP address
Subnet mask
Gateway IP address
Username
Password
Table 9. Default access gateway mode settings
Setting
N-ports: automatic failover
N-ports: automatic failback
APC policy default
Group policy default
ADS policy default
Preferred secondary failover
Table 10. Default access gateway mode port mapping
Internal port: F_port / Server port
1
2
3
4
5
6
7
8
9
10
11
12
13
14
Description
Dell EMC MXG610s
Access Gateway mode
Before factory restore defaults: 10.77.77.77
After factory restore defaults: 192.168.0.200+(SlotID[1~2])
After factory restore defaults: 255.255.255.0
After factory restore defaults: 192.168.0.1
admin
admin
Description
Enabled on all ports
Enabled on all ports
Disabled
Enabled
Disabled
None specified
External port: N_port / Fabric port
0
17
18
19
20
21
22
23
24
25
26
27
28
29
HBA Mezzanine Port
Lane 0 of Server Sled 1
Lane 0 of Server Sled 2
Lane 0 of Server Sled 3
Lane 0 of Server Sled 4
Lane 0 of Server Sled 5
Lane 0 of Server Sled 6
Lane 0 of Server Sled 7
Lane 0 of Server Sled 8
Lane 1 of Server Sled 1
Lane 1 of Server Sled 2
Lane 1 of Server Sled 3
Lane 1 of Server Sled 4
Lane 1 of Server Sled 5
Lane 1 of Server Sled 6
