Summary of Contents for Converters.TV 443
- Page 1 HDMI Digital scaler with ultra high bandwidth ID #443 Operation Manual...
- Page 2 Introduction Congratulations on your purchase of the HDMI Digital scaler with ultra high bandwidth. The HDMI Digital scaler with ultra high bandwidth is designed to convert PC, SD, HD, and HDMI to Digital HDMI at a variety of HDTV and PC resolutions. It handles input and output at 205 MHz ultra high Bandwidth.
- Page 3 • 3D noise reduction. • Operates through on-screen OSD menu control and remote control. Operating Functions and Controls Front Panel 1. Power: Press the button to turn ON or turn OFF (standby) the power of the unit. 2. +/- button: The buttons provide 3 functions: a.
- Page 4 accepts both interlaced component input (480i, 576i) and de-interlaced progressive input (480p, 576p... 1080p). The input range is 480i, 570i-1080i, 1080p. Rear Panel 1. PC in: Connects this PC input connector to the VGA output of your PC. The acceptable PC resolutions range from VGA-WUXGA. 2.
- Page 5 5. HDMI/DVI input: Press the button to directly select DVI (or HDMI) input. 6. Output resolution: Select buttons: Press any one of the button to directly select output resolution. For other output resolutions that are not covered by these buttons please enter Menu/Output page to select them 7.
- Page 6 Installation Input Connection...
- Page 7 The HDMI Digital scaler with ultra high bandwidth accepts component, PC and DVI inputs. The formats supported by these inputs are as follows: Component Input − When connecting to a PC source use a 15-pin D-sub cable to connect the output of a PC to the D-Sub input connector of the HDMI Digital scaler with ultra high bandwidth.
- Page 8 And use a DVI to HDMI connector adapter to connect to the other end of the DVI cable. The HDMI connector of the adapter is then connect to the HDMI input of the HDMI Digital scaler with ultra high bandwidth. The HDMI Digital scaler with ultra high bandwidth can automatically detect the input resolution of all three inputs.
- Page 9 OSD Operation After power on the unit, press the "menu" button will bring up the main menu as follows: Use +, - button to move highlight bar to your desired parameter, then press MENU/ENTER to enter into sub-menu of your selected parameter.
- Page 10 - High - Off Note (PC): Available only when PC is selected as input. To adjust picture quality, Use “+,-” to move the highlight bar to your desired adjust item, press the Menu/Enter to confirm your selection. At this point, the selected parameter will turn red, you can then use “+,-”...
- Page 11 Normal: Normal color tone setting where white is pue white. Warm: Warm color tone makes white reddish. Cool: Cool color tone makes white bluish. Output: The HDMI Digital scaler with ultra high bandwidth can output a wide variety of PC and HD resolutions as follows. Native: When it is selected, the HDMI Digital scaler with ultra high bandwidth will automatically adjust its output timing to match the native timing of the display.
- Page 12 Specifications HDMI 1.2 Compliant Input format(Up to 165MHz) YPbPr/YCbCr: 480i, 480p, 576i, 576p, 720p@(50/60Hz), 1080i@(25/30), 1080p@(50/60) VGA: VGA@(60/72/75/85), SVGA@(56/60/72/75/85), XGA@(60/70/75/85). S X G A @ ( 6 0 / 7 5 / 8 5 ) , U X G A @ 6 0 , W U X G A @ 6 0 DVI(CP-255D): VGA@(60/72/75/85), SVGA@(56/60/72/75/85),...
