Racelogic TC8V2 Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
RACELOGIC Support Centre
•
08 - TC8 EC declaration of conformity
•
03 - TC8V2 Software Connection
•
08 - TC8v2 Technical Specification
•
06 - Configuring TC8V2 for Video VBOX
•
02 - TC8V2 Modes of Operation
•
VBOX 3i Knowledge Base
•
Quick Start - VBOX 3i Dual Antenna
•
Quick Start - VBOX 3i
•
VBOX 3i Quick Start Guides
•
06 - TC8 Technical Specifications
•
01 - TC8 Introduction
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TC8V2 and is the answer not in the manual?

Questions and answers

Related Manuals for Racelogic TC8V2

Summary of Contents for Racelogic TC8V2

  • Page 1 08 - TC8 EC declaration of conformity • 03 - TC8V2 Software Connection • 08 - TC8v2 Technical Specification • 06 - Configuring TC8V2 for Video VBOX • 02 - TC8V2 Modes of Operation • VBOX 3i Knowledge Base •...
  • Page 2 “Council Directive of 03 May 1989 on the approximation of the laws of the member states relating to electromagnetic compatibility.” DTI Competent Body responsible for issuing certificate of compliance: 3C Test Ltd, Silverstone Technology Park, Silverstone, Northants. NN12 8GX https://racelogic.support/01VBOX_Automotive/04Modules_and_accessories/Thermocouple_Interface/...
  • Page 3 03 - TC8V2 Software Connection To configure TC8 using VBOX Setup software the module needs to be powered up and connected to a PC. To do this, connect TC8 to a powered VBOX using a RLCAB005 cable. Then use the supplied RLCAB042 USB cable to connect TC8 directly to the PC USB port.
  • Page 4 https://racelogic.support/01VBOX_Automotive/04Modules_and_accessories/Thermocouple_Interface/...

  • Page 5: Specification

    08 - TC8v2 Technical Specification Specification Input Channels Input Signals Thermocouple Type K -269.5°C to +1372°C Sample Rate 100 Hz Resolution 24 bit -200°C to -100°C = ±0.8°C System Accuracy -100°C to +1000°C = ±0.5°C 1000°C to 1300°C = ±0.7°C Cold Junction Compensation Accuracy ±0.2°C...
  • Page 6 LEMO Socket connections Connector 1 - CAN/ POWER IN (Lemo 5 PIN) Function RS232 Tx (Reserved for Racelogic use only - do not use) RS232 Rx (Reserved for Racelogic use only - do not use) CAN High CAN Low +12 V Power...
  • Page 7 Connector 2 - CAN OUT (Lemo 5 PIN) Function RS232 Tx (Reserved for Racelogic use only - do not use) RS232 Rx (Reserved for Racelogic use only - do not use) CAN High CAN Low +12 V Power Chassis Ground...

  • Page 8: Module Dimensions

    Module Dimensions https://racelogic.support/01VBOX_Automotive/04Modules_and_accessories/Thermocouple_Interface/...
  • Page 9 06 - Configuring TC8V2 for Video VBOX VBOX Setup Connect TC8 to VBOX Setup software as described here. To allow TC8 to communicate with the Video VBOX it must be set into 'Timed Mode'. In this mode TC8 will send CAN data at intervals determined by the timer value.
  • Page 10 1 on the next power cycle. Frequency output can be calculated as follows: Freq = (1/Timer) * 1000 The Timer value for a required frequency can be calculated as follows: Timer = (1/Freq) * 1000 https://racelogic.support/01VBOX_Automotive/04Modules_and_accessories/Thermocouple_Interface/...

  • Page 11: Video Vbox Setup

    .DBC files for RL modules can be downloaded from our VBOX Automotive website. Note: In order to communicate with Video VBOX units, Racelogic modules must be set into Timed CAN mode. For more information on how to do this, please see the user guide for the module in use.
  • Page 12 When you have opened the relevant .dbc file, select the channels you wish to log. To do this, you simply expand and then tick the desired channels. When you have selected all the channels you need, click ‘Apply’. https://racelogic.support/01VBOX_Automotive/04Modules_and_accessories/Thermocouple_Interface/...
  • Page 13 These are now loaded and will be logged to the VBO file. They can also now be assigned to an element. PLEASE NOTE: You cannot log from the vehicle CAN Bus at the same time as using a Racelogic Input Module. For further information on working with elements and creating scenes, please see the Video VBOX User Manual here.
  • Page 14 Third party data logger (stand-alone mode) In any of these configurations, TC8 can be used in conjunction with other Racelogic modules via the Racelogic proprietary CAN bus. This allows several different VBOX modules to be daisy chained together along the same CAN bus connection.
  • Page 15 VBOX 3i Knowledge Base This page was not added to the PDF due to the following tag(s): article:topic-guide https://racelogic.support/01VBOX_Automotive/01VBOX_data_loggers/VBOX_3i_Range/...
  • Page 16 Note: It is important to connect the antennas to the VB3i SL before power is connected. The VB3i SL adjusts the signal gain to the antenna based on the current incoming GPS signal strength. See these articles if having difficulty obtaining satellite lock: Satellite elevation mask GPS Cold start https://racelogic.support/01VBOX_Automotive/01VBOX_data_loggers/VBOX_3i_Range/...
  • Page 17 5. For normal operation, place the primary antenna (Port A) at the rear of the car, and the secondary antenna (Port B) at the front. All measurements are made from the primary antenna. 6. Power up VB3i SL. 7. Connect VBOX Manager to VB3i SL port dedicated to Racelogic CAN bus (determined in CAN tab of VBOX Tools Setup VBOX Setup).
  • Page 18 You may also like to take slip measurements from other locations on the vehicle, for instance the centre of gravity or slip over the wheels. This can be set using the slip angle translation function in VBOX Manager. https://racelogic.support/01VBOX_Automotive/01VBOX_data_loggers/VBOX_3i_Range/...
  • Page 19 Note: If you are using IMU integration, calculations will made from the antenna/ IMU offset. https://racelogic.support/01VBOX_Automotive/01VBOX_data_loggers/VBOX_3i_Range/...
  • Page 20 GPS signal strength. 3. Connect the power connector to the socket marked ‘PWR’ on the VBOX 3i. When power is connected, the ‘PWR’ LED will illuminate and all of the other LEDs will flash once then go https://racelogic.support/01VBOX_Automotive/01VBOX_data_loggers/VBOX_3i_Range/...
  • Page 21 - Do not remove the CF card or power down whilst the CF LED is flashing. If you need to remove the card or power down whilst the CF LED is flashing, then press the LOG button first to stop the VBOX logging. Failure to do so will result in data loss or corruption. https://racelogic.support/01VBOX_Automotive/01VBOX_data_loggers/VBOX_3i_Range/...
  • Page 22 VBOX 3i Quick Start Guides This page was not added to the PDF due to the following tag(s): article:topic-guide https://racelogic.support/01VBOX_Automotive/01VBOX_data_loggers/VBOX_3i_Range/...
  • Page 23 1000 V DC to processor Over Voltage Protection ±35 V DC CMR (50/60) Hz >92 dB Power Supply Voltage +12 V DC (±10 %) CAN 2.0A or CAN 2.0B compatible Type 250 kbit/s, 500 kbit/s, 1 Mbit/s Baud Rates https://racelogic.support/01VBOX_Automotive/04Modules_and_accessories/Thermocouple_Interface/...

  • Page 24: Unit Dimensions

    Unit dimensions https://racelogic.support/01VBOX_Automotive/04Modules_and_accessories/Thermocouple_Interface/...
  • Page 25 https://racelogic.support/01VBOX_Automotive/04Modules_and_accessories/Thermocouple_Interface/...

  • Page 26: Key Features

    01 - TC8 Introduction The RLVBTC8 8 Channel thermocouple interface module is designed for use with VBOX data logging systems. The module is configured via CAN through Racelogic Config software. Key features • 8 * K-type thermocouple inputs • Supports standard & extended CAN frames •...

  • Page 27: Standard Inventory

    5W lemo plug – 5W lemo plug RLCAB006 Sub D terminal block with integrated Cold Junction DE-PAD-OPT1 Compensation. Optional Accessories Description Product Code 2 m Thermocouple extension with high accuracy RLVBACS002 dynamic CJC. Serial connection cable for firmware upgrades. RLCAB001 https://racelogic.support/01VBOX_Automotive/04Modules_and_accessories/Thermocouple_Interface/...
