- Page 1 Installation Manual...
-
Page 2: Table Of Contents
TORX is a registered trademark of Acument Intellectual Properties, LLC. FUTRO is a registered trademark of Fujitsu Client Computing Limited. EIZO, the EIZO Logo and DuraVision are registered trademarks of EIZO Corporation in Japan and other countries. All other company names, product names, and logos are trademarks or registered trademarks of their respective companies. - Page 3 (included with PCSK-03R; 1 pcs.) Thumb screw : M4x8 (included with PCSK-03R; 1 pcs.) Attention • Attaching PCSK-03R will reduce the monitor’s tilt range. Without PCSK-03R: -5° to 35° With PCSK-03R: -5° to 17° How to Install a PC on a Monitor...
-
Page 4: Hp T520 Thin Client
HP t520 Thin Client Parts required • Screws: M4x8 (included with PCSK-03R; 4 pcs.) Tools required • Phillips screwdriver (#2) • TORX driver (T10) Screws: M4x8 (included with PCSK-03R; 4 pcs.) HP t520 Thin Client Before installing A, remove the four TORX screws attached to the PC. -
Page 5: Hp T310 Zero Client
HP t310 Zero Client Parts required • F7X24AA (Optional mounting bracket for HP) • Screws (included with F7X24AA; 4 pcs.) Tools required • Phillips screwdriver (#2) HP t310 Zero Client F7X24AA (Optional mounting bracket for HP) Screws (included with F7X24AA; 4 pcs.) Position of a screw hole (four positions) HP t310 Zero Client... -
Page 6: Hp Z2 Mini G3 Workstation / G4 Workstation
HP Z2 Mini G3 Workstation / G4 Workstation Parts required • Screws: M4x8 (included with PCSK-03R; 4 pcs.) Tools required • Phillips screwdriver (#2) HP Z2 Mini G3 Workstation / G4 Workstation Before installing A, remove four rubber feet attached to the PC. -
Page 7: Hp Elitedesk800 G3 Dm
HP EliteDesk800 G3 DM Parts required • Screws: M4x8 (included with PCSK-03R; 4 pcs.) Tools required • Phillips screwdriver (#2) HP EliteDesk 800 G3 DM Screws: M4x8 (included with PCSK-03R; 4 pcs.) You can also install the PC in the orientations shown below. -
Page 8: Hp Elite Slice
HP Elite Slice Parts required • X8U74AA (Optional mounting bracket for HP) • Screws: M4x8 (included with PCSK-03R; 4 pcs.) Tools required • Phillips screwdriver (#2) HP Elite Slice X8U74AA (Optional mounting bracket for HP) Screws: M4x8 (included with PCSK-03R; 4 pcs.) -
Page 9: Hp T310 G2 Zero Client
HP t310 G2 Zero Client Parts required • Screws: M4x8 (included with PCSK-03R; 4 pcs.) Tools required • Phillips screwdriver (#2) HP t310 G2 Zero Client Screws: M4x8 (included with PCSK-03R; 4 pcs.) You can also install the PC in the orientations shown below. -
Page 10: Hp T530 Thin Client
• EM870AA (Optional HP Quick Release Attachment) - Quick Release Attachment (2 types) - Screws : M4x12 (4 pcs.) - Spacer with a thickness of 2 mm • Screws: M4x8 (included with PCSK-03R; 4 pcs.) Tools required • Phillips screwdriver (#2) HP t530 Thin Client Remove the cover. - Page 11 Attachment supplied with the EM870AA Screws supplied with the EM870AA Spacer supplied with the EM870AA HP t530 Thin Client Screws: M4x8 (included with PCSK-03R; 4 pcs.) Attachment supplied with the EM870AA HP t530 Thin Client...
-
Page 12: Dell Wyse 3010Tc / T10 / 5030Pcoip / P25
Dell Wyse 3010TC / T10 / 5030PCoIP / P25 Parts required • Mounting bracket (included with Wyse 3010TC / T10 / 5030PCoIP / P25) • Screws: M4x8 (included with PCSK-03R; 4 pcs.) Tools required • Phillips screwdriver (#2) Wyse 3010TC / T10 / 5030PCoIP / P25... -
Page 13: Dell Wyse 5010Tc / D10D / D10Dp
Dell Wyse 5010TC / D10D / D10DP Parts required • Screws: M4x8 (included with PCSK-03R; 4 pcs.) Tools required • Phillips screwdriver (#2) Wyse 5010TC / D10D / D10DP Before installing A, remove four screws attached to the PC. Screws: M4x8 (included with PCSK-03R;... -
Page 14: Gigabyte Gb-Bki7Ht2-7500 / Gb-Bki7Ht-7500
GIGABYTE GB-BKi7HT2-7500 / GB-BKi7HT-7500 Parts required • Mounting bracket (included with GB-BKi7HT2-7500 / GB-BKi7HT-7500) • Screws (included with GB-BKi7HT2-7500 / GB-BKi7HT-7500; 2 pcs.) • Screws: M4x8 (included with PCSK-03R; 4 pcs.) Tools required • Phillips screwdriver (#2) Screws (included with GB-BKi7HT2-7500 / GB-BKi7HT-7500; 2 pcs.) Before attaching A and the bracket, install two screws on the PC side. -
Page 15: Lenovo Thinkstation P320 Tiny
Lenovo ThinkStation P320 Tiny Parts required • ThinkCentre Tiny VESA Mount II 4XF0N03161 (Optional mounting bracket for ThinkStation) • Screws (included with 4XF0N03161: 2 types; total of 6 pcs.) Tools required • Phillips screwdriver (#2) Screws (included with 4XF0N03161; 2 pcs.) ThinkCentre Tiny VESA Mount II 4XF0N03161 (Optional mounting bracket for ThinkStation) ThinkStation P320 Tiny... -
Page 16: Fujitsu Futro S740
FUJITSU FUTRO S740 Parts required • Mounting bracket (included with FUTRO S740) • Screws (included with FUTRO S740: 2 types; total of 8 pcs.) Tools required • Phillips screwdriver (#2) FUTRO S740 Mounting bracket (included with FUTRO S740) Machine screws (included with FUTRO S740;... - Page 17 Hang the heads of the four thumb screws on the four hollows of the mounting bracket to mount the unit. Thumb screw Mounting bracket (included with FUTRO S740) FUJITSU FUTRO S740...
-
Page 18: Eizo Duravision Dx0211-Ip
EIZO DuraVision DX0211-IP Note • Applies to products with Ver.5.2 of the software or newer versions. Parts required • Screws (included with DX0211-IP; 2 pcs.) Tools required • Phillips screwdriver (#2) Screws (Included with DX0211-IP; 2 pcs.) Position of a screw hole (two positions) - Page 19 03V28232A1 www.eizoglobal.com IM-PCSK-03R-AL Copyright © 2019 EIZO Corporation. All rights reserved. 1st Edition-December, 2019...
