- Page 1 Hanshow Stellar-XXXXL E31 Series Product Manual V1.0.2 HS-ESL-STELLAR102001 For more information, visit our website at: http://www.hanshow.com...
- Page 2 Hanshow. Offenders will be liable for any and all damages caused by their offence hereof and will be subject to all remedies that Hanshow is entitled to seek under applicable laws. Hanshow Copyright Reserved ©...
-
Page 3: About The Document
Hanshow Stellar-XXXXL E31 Series Product Manual V1.0.2 ABOUT THE DOCUMENT Thank you very much for using the Stellar-XXXXL E31 series products of Hanshow. The document introduces the role of label, functional, hardware parameters, features and precautions, etc. Please read the product manual carefully before using this product, retain the manual for subsequent use or for the next owner. -
Page 4: Symbol Description
Hanshow Stellar-XXXXL E31 Series Product Manual V1.0.2 SYMBOL DESCRIPTION Icon Description Information indicated with this icon should be paid special attention and attached great importance by the reader Information indicated with this icon is the explanation on the formal text for... -
Page 5: Table Of Contents
4.2 Precautions for use ..................... 8 5 FCC ID warning ......................9 5.1 Warning for nameplate ..................9 5.2 Warning for product manual ................9 6 Application scenarios introduction ................10 Hanshow Copyright Reserved © Zhejiang Hanshow Technology Co., Ltd. - Page 6 List of Figures List of Figures Figure 2-1 Front area of Stellar-XXXXL E31 ..........2 Figure 2-2 Rear panel of Stellar-XXXXL E31 ..........3 Hanshow Copyright Reserved © Zhejiang Hanshow Technology Co., Ltd.
- Page 7 Table 2-3 Stellar-XXXXL E31 specifications ..........3 Table 2-4 Stellar-XXXXL E31 usage scenarios ..........5 Table 2-5 Stellar-XXXXL E31 basic function ..........5 Table 3-1 Stellar-XXXXL E31 series product performance ......7 Hanshow Copyright Reserved © Zhejiang Hanshow Technology Co., Ltd.
-
Page 8: Overview
Hanshow Stellar-XXXXL E31 Series Product Manual V1.0.2 1 Overview Stellar-XXXXL E31 series are an Electronic Shelf Label (ESL) researched and developed independently by Hanshow Technology Co., Ltd. It is an important part of the Hanshow electronic shelf label system, interacting with AP and ESL- Working for data and information. -
Page 9: Product View
Hanshow Stellar-XXXXL E31 Series Product Manual V1.0.2 @ is: LED indicator 2.2 Product view The following sections introduce the appearance area of the front and rear of Stellar-XXXXL E31 series. Front area 2.2.1 The front area of Stellar-XXXXL is shown in... -
Page 10: Rear Area
Hanshow Stellar-XXXXL E31 Series Product Manual V1.0.2 Name Description e-paper screen, support three colors (black/white, black/white/red and Screen area black/white/yellow) display schemes, NOT SUPPORT grayscale Red dotted square NFC sensing area Rear area 2.2.2 The rear area of Stellar-XXXXL is shown in Figure 2-2. - Page 11 Hanshow Stellar-XXXXL E31 Series Product Manual V1.0.2 Name Description Product dimensions 235.5*174.0*12.6 (mm*mm*mm) Active display area 215.5*143.7 (mm*mm) Product weight (g) 365.0 Product appearance Elegant White (customizable with different-color frame) Display size (inch) 10.2 Resolution (pixel) 960*640 [2-2] 113 [2-2]...
-
Page 12: Function Introduction
Hanshow Stellar-XXXXL E31 Series Product Manual V1.0.2 Note: [2-2]: The resolution and DPI vary with different screen. [2-3]: For EPD label with black/white/yellow, the working life is about 3 years, while for EPD label with black/white or black/white/red, the working life is about 5 years at room temperature. - Page 13 Hanshow Stellar-XXXXL E31 Series Product Manual V1.0.2 Name Function Description Supports RGB tricolor LED display function Flashing light LED flash cycle configurable [2-4] (Optional) Supports marquee function Flashing light Supports flashing light function Remote control function Page switch Supports page switch for remote controller ...
-
Page 14: Product Function Features
3 Product function features This chapter introduces the performance parameters and benefits of Stellar- XXXXL E31 series. 3.1 Performance parameters The performance parameters of Stellar-XXXXL E31 series are shown in Table 3-1. Table 3-1 Stellar-XXXXL E31 series product performance RF parameters... -
Page 15: Precautions
Temperature never exceed 40℃ during transporting 4.2 Precautions for use The precautions for use of Stellar-XXXXL E31 series are as follows: Keep ESLs working temperature in the range of 0℃ ~ 30℃ It's highly prohibited ESLs temperature is over 60℃... -
Page 16: Fcc Id Warning
Hanshow Stellar-XXXXL E31 Series Product Manual V1.0.2 Don’t use chemical detergent to wipe the screen. It is forbidden to install ESLs in a strong magnetic environment. Do not violently disassemble the ESLs 5 FCC ID warning 5.1 Warning for nameplate This device complies with Part 15 of the FCC Rules. -
Page 17: Application Scenarios Introduction
Hanshow Stellar-XXXXL E31 Series Product Manual V1.0.2 6 Application scenarios introduction ESLs can be applied to various areas and shelves of hypermarket, supermarket and retail stores. Stellar-XXXXL E31 series products are widely used for the below areas and scenes: Regular shelf racking areas ...
