Toptica DL pro Troubleshooting Manual

Advertisement

DL pro
Troubleshooting guide
WARNING
This troubleshooting guide represents only a coarse outline of
the steps necessary to get the laser system back to its
specification. It does only complement, not replace the user
manual.
Before taking any of the following steps the user must
familiarize himself with the hazards involved when mainting a
laser source. READ AND FOLLOW THE SAFETY
INSTRUCTIONS AND WARNINGS in the user manual
carefully before you proceed. TOPTICA cannot be held liable
for injuries and / or damage caused by improper use of its
lasers. If you feel unsure, please contact TOPTICA's service
department first. Proceed at your own risk!
NOTE
The references given in this guide are valid for the DL pro user manual, issue February 2008.
Other (especially older) versions of the manual have a different structure or may not contain all the
information. Please contact us if you wish to receive a printed copy of the most recent manual.
