Summary of Contents for Diamond Engineering X0-90
- Page 1 Installation and Configuration Guide X0-90 Elevation Stage...
-
Page 3: Table Of Contents
Table of Contents OPT-X0-90 - Introduction .......................5 Elevation Stage Assembly - TOP MOUNT ..................6 Elevation Stage Assembly - SIDE MOUNT .................8 AUT mounting holes ...........................10 Software and Controller Installation .....................12 Software Configuration ........................13 X0-90 Specifications ..........................14 Part Drawings - Acrylic Bracket ....................15 Troubleshooting and Support Info. -
Page 5: Opt-X0-90 - Introduction
OPT-X0-90 - Introduction Overview Option X0-90 provides +/- 90 degrees of elevation tilt for the x000 series turntable, this option replaces the legacy +/- 45 degree tilt option. The stage is compatible with any DAMS Conroller and software releases after November 2019. This option includes provisions for both “Top Mount” and Side Mount configurations. -
Page 6: Elevation Stage Assembly - Top Mount
5. Mount turntable to mount sing the 4 x 1/4-20 x 1.25” nylon thumb screws 6. Connect yellow cable with 9p DSUB connector to the rotary stage. 7. Connect other yellow cable with right angle to DAMS Turntable. X0-90 Elevation Stage Installation & Configuration... - Page 7 Elevation Stage Assembly - TOP MOUNT - Complete Installation & Configuration X0-90 Elevation Stage...
-
Page 8: Elevation Stage Assembly - Side Mount
5. Mount turntable to mount sing the 4 x 1/4-20 x 1.25” nylon thumb screws 6. Connect yellow cable with 9p DSUB connector to the rotary stage. 7. Connect other yellow cable with right angle to DAMS Turntable. X0-90 Elevation Stage Installation & Configuration... - Page 9 Elevation Stage Assembly - SIDE MOUNT - Complete Installation & Configuration X0-90 Elevation Stage...
- Page 10 X0-90 Elevation Stage Installation & Configuration...
-
Page 11: Aut Mounting Holes
Turntable AUT mounting holes AUT Mounting Holes The Polarizer’s rotating plate has 20x 10-32 UNC threaded mounting holes in a circular pattern. The dimensions below can be used to make custom mounting brackets. Installation & Configuration X0-90 Elevation Stage... -
Page 12: Software And Controller Installation
Close device manager. If you need a driver it can be found in c:\dams\driver 2. If the COM port is greater than 8 , right click and select properties, and change to 8 or lower X0-90 Elevation Stage Installation & Configuration... -
Page 13: Software Configuration
Software Configuration DAMS Software Configuration for Opt. X0-90 DAMS Software Configuration for X0-90 90 degree tilt feature for x000 series systems (applies to s/n 2018xxx and above controllers) 1. Open the DAMS Measurment software and select “positioner settings” from the upper right corner of the screen. - Page 14 Software Configuration DAMS Software Configuration for Opt. X0-90 Custom Current Configuration (set within positioner settings) 1. Open the DAMS Measurment software and select “positioner settings” from the upper right corner of the screen. Press “Advanced Current Settings” 2. Enable custom current for Y axis only as shown below 3.
-
Page 15: X0-90 Specifications
USB-Mini B to internal RS232 Optional DB9 RS232 serial port with exernal USB adapter Communication cable length: 2 Meters (Included) Input Voltage: 24VDC 2.5A Power Supply (included): 24VDC 2.5A - 110/220v input Motor cable length: 6 Meters Installation & Configuration X0-90 Elevation Stage... -
Page 16: Part Drawings - Acrylic Bracket
Part Drawings - Small Acrylic Bracket X0-90 Elevation Stage Installation & Configuration... - Page 17 Part Drawings - Long Acrylic Bracket Installation & Configuration X0-90 Elevation Stage...
- Page 18 Part Drawings - Aluminum Tripod Bracket X0-90 Elevation Stage Installation & Configuration...
-
Page 19: Troubleshooting And Support Info
Controller to verify which COM Port is assigned to the other controller as they will both have the same name. If you still cannot resolve the issue, please contact us. http://www.DiamondEng.net · Support@DiamondEng.net P.O. Box 2037 Diamond Springs, CA 95619 · 530-626-3857 Installation & Configuration X0-90 Elevation Stage...
