PPP-SR

TABLE OF CONTENTS

SECTION 1 - DESCRIPTION.......................................................................2
SECTION 2 - SPECIFICATIONS.................................................................4
SECTION 3 - INSTALLATION.....................................................................5
SECTION 4 - CONTROLS AND INDICATORS .........................................6
SECTION 5 - NETWORK MANAGEMENT PORT.....................................9
SECTION 6 - INTERFACE SIGNALS AND CABLING...........................13
SECTION 7 - TROUBLESHOOTING .......................................................17
SECTION 8 - WARRANTY ..........................................................................19
Data Comm for Business, Inc.
807 Pioneer Street
Champaign, IL 61820
March 1, 2000
217-352-3207
Firmware Version: 2.5
8500056

Advertisement

loading
Need help?

Need help?

Do you have a question about the PPP-SR and is the answer not in the manual?

Questions and answers

Summary of Contents for DCB PPP-SR

  • Page 1: Table Of Contents

    PPP-SR TABLE OF CONTENTS SECTION 1 - DESCRIPTION...............2 SECTION 2 - SPECIFICATIONS..............4 SECTION 3 - INSTALLATION..............5 SECTION 4 - CONTROLS AND INDICATORS .........6 SECTION 5 - NETWORK MANAGEMENT PORT........9 SECTION 6 - INTERFACE SIGNALS AND CABLING......13 SECTION 7 - TROUBLESHOOTING ............17 SECTION 8 - WARRANTY ................19...

  • Page 2: Section 1 - Description

    DSU, ISDN Terminal Adapter, modem, radio, or FRAD. Since it connects to the PC using a serial (COM:) port, the PPP-SR provides a simple way to connect small remote offices or SOHO locations to the host router without installing a complex LAN at the remote office.
  • Page 3 Features • 56 or 64 Kbps line speed with optional built-in DSU • Up to 128 Kbps line speed with external DSU • RS-232 interface rates to 115.2 Kbps • Converts synchronous PPP protocol to asynchronous PPP • “AT” command spoofing for Microsoft Windows95 dialer and similar dialers •...

  • Page 4: Section 2 - Specifications

    SPECIFICATIONS General PC port interface: RS-232 implemented in 8-wire RJ-45 jack per EIA/TIA 561 PC port rate: up to 115.2 Kbps asynchronous Router Indicators: Power, Activity, Line Error, Modem Ready, Port 1 Setup DSU Indicators: Transmit Data, Receive Data, Request to Send, Clear to Send, Data Carrier Detect, Test DSU Telco Interface: 8-wire RJ-48S DDS (with built-in DSU) Composite rate: 56 or 64 Kbps synchronous with built-in DSU...

  • Page 5: Section 3 - Installation

    Location Place the PPP-SR in a clear area where you can reach the front panel for setup and the rear panel to connect the cables. The PPP- SR has an external power supply that requires a 120 VAC outlet.

  • Page 6: Section 4 - Controls And Indicators

    CONTROLS AND INDICATORS Front Panel Controls (shown with built-in DSU) TEST SR DATA MULTIPLEXER LINE MODEM PORT 1 LOOPBACK SETUP RESET POWER ACTIVITY ERROR READY SETUP LOOPBACK 4.1.1 Loopback Switch Not Implemented 4.1.2 Setup Switch Enables the unit to be configured using the PC connected to port 1. The Port 1 Setup indicator will light.
  • Page 7 Rear Panel Controls 4.2.1 Dip Switches (for built-in DSU only) The DSU switches are located at the rear of the unit. Switch functions are shown in the following table: Switch Down 64K (optional) Slave Clock Master Clock Must Be Down RTS Normal RTS Forced ON Normal...
  • Page 8 Indicators Indicator Condition Meaning Power Unit has power. Activity Unit is in on-line mode. Line Error Not Used Modem Ready Network DCD is high. Port 1 Setup Network Management Port functions have been mapped to Port 1 for unit configuration. To return to normal operation, press the front panel Port 1 Setup switch.

  • Page 9: Section 5 - Network Management Port

    NETWORK MANAGEMENT PORT Introduction The Network Management port (NMP) provides access to vital statistics and troubleshooting tools. By connecting a terminal or modem to the NMP a vast array of information is at your finger tips. This information can also be accessed via a terminal device (or PC using terminal emulation software) on port 1 when the port 1 setup switch is depressed.
  • Page 10 Show (WAN/Port) IP Address The Show IP Address (SI) command displays the assigned and actual IP addresses for all ports and the PC port status. It also displays a WAN IP address for the PPP-SR unit. 5.4.4 Frame Relay Status The SS command displays the status of the frame relay connection to the telephone company.
  • Page 11 IDs can be a maximum of 15 characters in length. Pressing <Enter> with no entry will leave the ID unchanged. The ID is used only when accessing the PPP-SR from the NMP. Its use is optional. 5.4.10 Activity Counts / Zero The Activity Counts (AC) command shows transmit and receive data statistics for all ports.
  • Page 12 Command syntax is PI 206.3.230.1 to ping IP address 2065.3.230.1 . One ping packet is sent. 5.4.16 Show RS-232 The SR command displays the current state of the five RS-232 control signals for each PC port. 5.4.17 Reset SR To reset the PPP-SR unit type “reset”.

  • Page 13: Section 6 - Interface Signals And Cabling

    INTERFACE SIGNALS AND CABLING Connector Location and Pin Reference Network Network Switches DSU Telco Power Management Port Composite 1 2 3 4 5 6 7 8 PPP-SR Rear Panel and RJ-45 Jack RJ-45 Plug Positions...
  • Page 14 Port Interface 6.2.1 Line Port (RJ-45) For external DSU Signal In/Out Receive Clock Transmit Clock Data Carrier Detect Signal Ground Transmit Data Receive Data Request to Send Clear to Send 6.2.2 PC Ports (RJ-45) Signal In/Out Data Set Ready Data Carrier Detect Busy Signal Ground Receive Data...
  • Page 15 Cables 6.3.1 PC port cable PC Port RJ-45 DB-25S DE-9S 6.3.2 Network Management Port To a TERMINAL Terminal RJ-45 DB-25P To a PC using terminal emulation RJ-45 DE-9S DB-25S...
  • Page 16 To a dial-up MODEM for remote access Modem RJ-45 DB-25P...

  • Page 17: Section 7 - Troubleshooting

    SR from the PC. To do this, open a window (MS-DOS window) on the PC and run the PING program using the IP address of the PPP-SR. For example: C:\windows\PING 206.3.230.4 Reply from 206.3.230.4: bytes=32 time=1ms TTL=64 indicates a good link to the PPP-SR with IP address 206.3.230.4.
  • Page 18 2. Verify that the connection between the host router and the PPP-SR is up. First check the host router statistics for a valid PPP link. If it indicates that a link is up, verify it by pinging the PPP-SR from the host router. The PPP-SR does...

  • Page 19: Section 8 - Warranty

    Returned Material Authorization (RMA) number. To receive an RMA number, call (217) 352-3207 between 8 AM and 5 PM central time. Equipment must be shipped prepaid to DCB and will be returned at DCB's expense. Data Comm for Business, Inc.
