Summary of Contents for EMC Ionix SCA
- Page 1 ® Ionix Storage Configuration Advisor Version 2.0 Installation Quick Reference P/N 300-010-422 Rev A01 EMC Corporation Corporate Headquarters: Hopkinton, MA 01748-9103 1-508-435-1000 www.EMC.com...
- Page 2 Copyright © 2010 EMC Corporation. All rights reserved. Printed March 2010 EMC believes the information in this publication is accurate as of its publication date. The information is subject to change without notice. THE INFORMATION IN THIS PUBLICATION IS PROVIDED “AS IS.” EMC...
- Page 3 • Java 1.6.0_14 or above plug-in for browser. For support information including supported arrays, fabrics, providers, host and array discovery, refer to the EMC Ionix Storage Configuration Advisor Support Matrix. ® Important: All SCA documentation is available on the EMC Powerlink website (http://Powerlink.EMC.com).
-
Page 4: Installation Documentation
Installation documentation You need the EMC Ionix Storage Configuration Advisor Installation Guide for complete information on how to install SCA. SCA documentation list Complete SCA documentation list is as follows: • EMC Ionix Storage Configuration Advisor 2.0 Administration Guide •... -
Page 5: Installation Overview
The following tasks are required to install the hardware appliance onto your network, and to begin using the software. Detailed steps appear in the EMC Ionix Storage Configuration Advisor 2.0 Installation Guide. Task 1: Assemble the appliance hardware This section describes how to install the SCA 1U server into the cabinet. - Page 6 Figure 2 on page 6displays the rear view of the Dell R610 appliance. Figure 2 Appliance rear view Table 2 on page 6 describes the components seen on the rear view of the Dell R610 appliance. Table 2 Dell appliance components (rear view) Item Indicator, Button, or Connector DRAC6 Enterprise...
- Page 7 Install the appliance in a rack or cabinet Take the appliance out of the box and mount it into the rack as follows: “Mounting kit parts” on page 7 “Removing inner rails from the universal rail kits” on page 7 “Attaching the inner rails”...
- Page 8 Slide the white disconnect tab forward to release the inner rail from rest of the assembly, and then remove the rail. CL4346 Figure 3 Removing the inner rails from the rail assembly Attaching the inner rails Figure 4 on page 8shows how to attach inner rails to each side of the appliance.
- Page 9 Click! Click! CL4348 Figure 5 Installing universal rails Installing the appliance in the cabinet WARNING ! The enclosure is heavy and should be installed into a rack by two people. To avoid personal injury and/or damage to the equipment, do not attempt to lift and install the enclosure into a rack without a mechanical lift and/ or help from another person.
- Page 10 Slide the blue release tab and then push the appliance into the cabinet. An audible click indicates that the slide rails are engaged and locked. Click! CL4350 Figure 7 Securing the appliance in the cabinet To further secure the rail assembly in the cabinet, insert and tighten a stabilizer screw directly behind each bezel latch.
- Page 11 CL4408 Figure 9 Installing the bezel Wire the appliance: a. Plug the LAN cable into the Gb1 connector. b. Plug a monitor into the Video port and a keyboard and mouse into USB ports, or alternatively use a KVM connection. c.
-
Page 12: Technical Support
Task 2: Run installation script After hardware installation, you must configure the appliance for your site, and then run the installation script as described in the EMC Ionix Storage Configuration Advisor Installation Guide. Have the following site information handy: •...
