forest river Aviator 2013 Owner's Manual
  1. Manuals
  2. Brands
  3. forest river Manuals
  4. Caravans
  5. Aviator 2013
  6. Owner's manual

forest river Aviator 2013 Owner's Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Owner's Manual
2013 Wright Flyer Edition
Revised September 2012

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Aviator 2013 and is the answer not in the manual?

Questions and answers

Summary of Contents for forest river Aviator 2013

  • Page 1 Owner’s Manual 2013 Wright Flyer Edition Revised September 2012...

  • Page 2: Table Of Contents

    Table of Contents Table of Contents Page 2-7 Legend Page Disclaimer Page Welcome Aboard Page Aviator Limited Warranty Page 10 Component Manufacturers Page 11 Section 1 Owner Information Component Manufacturer’s Warranties Page 12 Taking Delivery Page 12 Making a Service Appointment Page 12 Organize Page 12...

  • Page 3: Table Of Contents

    Table of Contents Section 3 Weight Distribution, Loading and Towing Loading and Weighing Tips Page 28-30 Cargo Capacities Page 28-29 Vehicle Load Limits Page 30 Loading Tips Page 30-31 Weighing Tips Page 31-33 How to Weigh your Aviator Page 32 Computing your Load and Load Distribution Page 33 Travel Trailer Hitch and Sway Control...
  • Page 4 Table of Contents Section 4 Living Quarters, LP and Electrical Living Room Slide Out Page 38 Prolonged Occupancy Page 39 Condensation Page 39 Tips to Help Contain Humidity in your Aviator Page 40 Safety Devices Page 41-42 Smoke Detector Page 41 CO Detector Page 42 LP Detector (General)
  • Page 5 Table of Contents Section 5 Plumbing Plumbing Page 54 Fresh Water Page 54 External Hook-Up (City Water Inlet Connection) Page 54 Attaching to an Outside Source of Water (City Water Inlet Connection) Page 54 To Disconnect from an Outside Source of Water Page 55 Filling the Fresh Water Tank Page 55-56...
  • Page 6 Table of Contents Section 6 Appliances Appliances Page 68 Cooktop Page 68 To Prevent Fire or Smoke Damage (Cooktop) Page 68-69 Lighting the Cooktop Surface Burners Page 70 To Bleed Air from Cooktop LP Line Page 70 Cooktop Match Lit Ignition Page 70 Cooktop Piezo Ignition Page 70-71...

  • Page 7: Legend

    Table of Contents Section 7 Care and Maintenance General Care and Maintenance Page 85 Fiberglass Exterior Page 85 Seals and Adhesives Page 86 Windows and Doors Page 86-87 Frame, Extrusions and Aluminum Surfaces Page 88 Roof Page 88 LP Gas System Page 89 Exterior Lights Page 89...

  • Page 8: Disclaimer

    FOR DIAGNOSIS OR REPAIR OF ANY ISSUE, CONTACT YOUR DEALER. Forest River Inc. and its suppliers are neither responsible nor liable for any damages, injuries, or negative consequences from any action, application use or misuse of this manual, to any person reading or following the information in this manual.

  • Page 9: Welcome Aboard

    One year Limited Warranty included in this manual. Aviator by Forest River, Inc. has no other expressed or implied warranties of any type. You, as the owner, are responsible for providing proper maintenance as outlined in this manual and as set forth in the component manufacturers’...

  • Page 10: Aviator Limited Warranty

    RECREATIONAL VEHICLES BY FOREST RIVER INC. Thank you for choosing to purchase an Aviator Recreational Vehicle by Forest River Inc., a fine product in which design and construction have received the care that quality demands. This important warranty covers many items and is indicative of our desire to stand behind our products and assure our customers’...
  • Page 11   Component Manufacturer contacts Return to Index Item Manufacturer/Supplier Phone Website Sony/RiverPark (800) 442-7717 www.riverparkinc.com Blu Ray Player Sony/RiverPark (800) 442-7717 www.riverparkinc.com Speakers Sony/RiverPark (800) 442-7717 www.riverparkinc.com Exterior Multi Disc Sony/RiverPark (800) 442-7717 www.riverparkinc.com Player Router Linksys/RiverPark (800) 442-7717 www.riverparkinc.com Tablet Sony/RiverPark (800) 442-7717...

  • Page 12: Owner Information

    Section 1 Owner Information Component Manufacturer’s Warranties Return to Index Page 11 lists the individual component manufacturers which were used in the manufacturing of your Aviator. Be sure to check the manufacturer’s literature supplied on your SD Card or in the Aviator RV Owner’s packet to confirm whether they require you to register your purchase with them to validate their warranty.

  • Page 13: Dealer Responsibilities

    Complete and send in all the warranty cards or register your components on the respected vendors’ websites. NOTE: MODIFICATIONS TO YOUR AVIATOR, WITHOUT WRITTEN AUTHORIZATION FROM FOREST RIVER, INC., COULD RESULT IN REDUCTION OR LOSS OF WARRANTY COVERAGE. CONTACT YOUR DEALER BEFORE MAKING SUCH CHANGES. Notes:...

  • Page 14: Owner Responsibilities

    3. Locate all paperwork and ask any questions you may have before leaving the dealership. NOTE: FOREST RIVER, INC. WANTS YOU TO HAVE THE BEST POSSIBLE ADVENTURE WITH YOUR NEW AVIATOR. TO GET THE MOST ENJOYMENT OUT OF YOUR NEW...

  • Page 15: Customer Delivery And Pdi Checklist Sample Forms

    Section 1 Owner Information Customer Delivery and PDI Checklist Sample Forms Return to Index Page 15 Revised September 2012...

  • Page 16: Identification And Safety

    Decals and data plates placed throughout the recreational vehicle aid in its safe and efficient operation, or give service instructions. Read all decals, data and instruction plates before operating your Aviator. FOREST RIVER RECREATIONAL VEHICLE SERIAL NUMBER LABEL SAMPLE MANUFACTURED BY / FABRIQUE PAR:...

  • Page 17: Safety Regulations & Lp Gas

    Section 2 Identification and Safety Safety Regulations & LP Gas Return to Index The following warnings are posted throughout your recreational vehicle to provide information on LP gas safety. They have been installed not only because of the requirement to do so, but also as a constant reminder to occupants of your Aviator to exercise proper caution when using or being around LP gas appliances and equipment.
  • Page 18 Section 2 Identification and Safety Safety Regulations & LP Gas (Cont’d) Return to Index DO NOT STORE LP GAS CONTAINERS, GASOLINE, OR OTHER FLAMMABLE LIQUIDS INSIDE THE VEHICLE AS A FIRE OR EXPLOSION MAY RESULT. A WARNING LABEL HAS BEEN LOCATED NEAR THE LP GAS CONTAINER.
  • Page 19 Section 2 Identification and Safety Fire Safety Return to Index Fire safety is an important part of owning a recreational vehicle. The following basic rules of fire prevention can help eliminate the possibility of a fire. 1. Never store flammable liquids in the recreational vehicle. 2.

  • Page 20: Fire Safety

    Section 2 Identification and Safety Fire Safety (Cont’d) Return to Index Safety Tips BE SURE THAT EVERYONE IN YOUR AVIATOR IS FAMILIAR WITH THE LOCATION OF ALL EXITS, INCLUDING EXIT WINDOWS. IN THE EVENT OF A FIRE EVACUATE YOUR AVIATOR IMMEDIATELY. BE SURE THAT EVERYONE IN YOUR AVIATOR IS FAMILIAR WITH THE OPERATION AND LOCATION OF THE FIRE EXTINGUISHER.
  • Page 21 Section 2 Identification and Safety Fire Safety (Cont’d) Return to Index DO NOT USE WATER TO EXTINGUISH A FIRE. WATER CAN SPREAD SOME TYPES OF FIRE AND ELECTROCUTION IS POSSIBLE. UNDERWRITER LABORATORIES CLASSIFY FIRES INTO THREE TYPES: Class A: Fires in wood, paper, fabric, rubber and certain plastics. Class B: Flammable liquids such as grease, cooking oils, gasoline or kerosene.

  • Page 22: Tire Safety

    Section 2 Identification and Safety Tire Safety Return to Index Use the following information to make tire safety a regular part of your vehicle maintenance routine. Basic Tire Maintenance Return to Index Properly maintained tires improve steering, stopping, traction, and load-carrying capability of your vehicle.

  • Page 23: Checking Tire Pressure

      Section 2 Identification and Safety Checking Tire Pressure Return to Index Because tires are designed to be used on more than one type of vehicle, tire manufacturers list the maximum permissible inflation pressure’ on the sidewall. Your Aviator tires are ST225/75R15D tires and the pressure should be maintained at 65 PSI or 448 kPa.
  • Page 24 Section 2 Identification and Safety Tire Identification breakdown Return to Index Indicates the tire is for passenger vehicles. Next (3 Digit) Number Gives the width in millimeters of the tire from sidewall edge to sidewall edge. In general, the larger the number, the wider the tire. Next (2 Digit) Number Gives the tire’s ratio of height to width, (known as the aspect ratio).

  • Page 25: Tire Identification Breakdown

    Section 2 Identification and Safety Tire Identification breakdown (Cont’d) Return to Index For tires with a maximum speed capability over 149 mph, tire 99 mph 130 mph manufacturers sometimes use the letters ZR. For those with a maximum speed capability over 186 mph, tire manufacturers 106 mph 149 mph always use the letters ZR.

  • Page 26: Tire Tips

    Section 2 Identification and Safety Tire Identification breakdown (Cont’d) Return to Index Tread wear Number This number indicates the tire’s wear rate. The higher the tread wear number is, the longer it should take for the tread to wear down. For example, a tire graded 400 should last twice as long as a tire graded 200.
  • Page 27 Section 2 Identification and Safety Tire Tips (Cont’d) Return to Index 1st Stage 20 to 25 ft/lbs 55 to 60 ft/lbs Stage 90 to 95 ft/lbs TIGHTEN EACH LUG NUT IN THE ORDER SHOWN IN THE CHART NOTE: Start all lug nuts by hand to prevent cross threading. Wheel nut torque requirements vary depending on the size and manufacturer of the wheel.

  • Page 28: Weight Distribution, Loading And Towing

    Section 3 Weight Distribution, Loading and Towing Loading and Weighing Tips Return to Index Cargo Capacities Return to Index Determining the weight of a vehicle includes more than understanding the load limits of the tires. A weight certification label, located on the forward half of the road side of the unit, will indicate the gross axle weight (GAWR).

  • Page 29: Loading And Weighing Tips

    Section 3 Weight Distribution, Loading and Towing Loading and Weighing Tips (Cont’d) Return to Index Cargo Capacities (Cont’d) Return to Index Weight- (Cont’d) The weight of fully filled propane containers is considered part of the weight of the RV before it is loaded with cargo and is not considered part of the disposable cargo load.

  • Page 30: Vehicle Load Limits

    Section 3 Weight Distribution, Loading and Towing Loading and Weighing Tips (Cont’d) Return to Index NOTE: Before filling the fresh water tank, empty the black and gray tanks. Most campgrounds supply dump stations for this purpose. Doing this will provide more cargo capacity. NOTE: If you find that you have exceeded the GVWR of the recreational vehicle, you will have to remove items until you are within the specified limits.
  • Page 31 Section 3 Weight Distribution, Loading and Towing Loading Tips (Cont’d) Return to Index • Do not place heavy items in the overhead cabinets. They could shift and fall during travel. • Luggage and similar cargo stored inside your Aviator must be secured to prevent possible damage if it should become necessary to make a sudden stop.

  • Page 32: Weighing Tips

    Section 3 Weight Distribution, Loading and Towing Weighing Tips (Cont’d) Return to Index DO NOT ADD ANY TYPE OF RACK OR FRAME ADDITION TO YOUR AVIATOR FRAME OR BUMPER. THE ALTERATION TO LENGTH AND/OR WEIGHT DISTRIBUTION MAY RESULT IN UNSTABLE HANDLING, BE A SAFETY HAZARD, OR COULD DAMAGE YOUR AVIATOR COMPONENTS.

  • Page 33: Computing Your Load And Load Distribution

    Choosing the correct hitch for use with your unit will enhance the stability and maneuverability of your unit and tow vehicle combination. Forest River recommends you consult with your Forest River dealer for assistance in selecting the proper weight distribution and sway control systems for your application.

  • Page 34: Travel Trailer Hitch And Sway Control

    These should be installed as per the weight distribution and sway control manufacturer’s instructions. Again your Forest River dealer should be a valuable resource in selecting the proper weight distribution and sway control systems for your unit.
  • Page 35 Sometimes asphalt or grass can have some give to them depending on such things as heat, rain, etc. Forest River suggests that you use some type of material that is strong enough and large enough to give you adequate support. Usually a 2” x 8”, 2” x 10” or 2” x 12” board is used.

  • Page 36: Leveling Your Aviator

    Section 3 Weight Distribution, Loading and Towing Leveling Your Aviator (cont’d) Return to Index If you have difficulty controlling the rig when backing onto the boards, add extra length. The second board should be 5” longer than the first one and the third board should be 5” longer than the second one. You may need various sizes of smaller boards for use under jacks and stabilizers.

  • Page 37: Electric Stabilizer Jacks (Optional)

    DO NOT MAKE MODIFICATIONS TO YOUR AVIATOR BY ADDING AFTER-MARKET ITEMS (gooseneck adapters, hitches, bike racks, ladders, storage racks etc.), WITHOUT FIRST OBTAINING WRITTEN AUTHORIZATION FROM FOREST RIVER, INC. MODIFICATIONS MAY CAUSE DAMAGE TO YOUR AVIATOR AND LIMIT, REDUCE, OR VOID YOUR WARRANTY.

  • Page 38: Living Quarters, Lp And Electrical

    Section 4 LIVING QUARTERS, LP and ELECTRICAL Living Room Slide Out Return to Index Before extending the room, check the exterior of the unit to be sure the room will not hit anything outside when it is fully extended. Locate the rocker switch that reads ‘SLIDE-OUT #1’. Hold the switch in the ‘OUT’...

  • Page 39: Prolonged Occupancy

    Section 4 LIVING QUARTERS, LP and ELECTRICAL Prolonged Occupancy Return to Index Your recreational vehicle was designed for recreational use and short-term occupancy. If you expect to occupy your Aviator for an extended period of time, be prepared to deal with condensation and the humid conditions that may be encountered.

  • Page 40: Tips To Help Contain Humidity In Your Aviator

    Section 4 LIVING QUARTERS, LP and ELECTRICAL Tips To Help Contain Humidity In Your Aviator Return to Index 1. Keep indoor humidity low--if possible below 60%. Ideally between 30 and 50% relative humidity. Relative humidity can be measured with a moisture or humidity meter. The meter is a small, inexpensive ($10-$50) instrument available at most hardware stores.

  • Page 41: Smoke Detector

    Section 4 LIVING QUARTERS, LP and ELECTRICAL Safety Devices Return to Index NEVER IGNORE ALARMS ON SAFETY DEVICES. IF AN ALARM SOUNDS, GET EVERYONE OUT OF YOUR AVIATOR IMMEDIATELY. • Always have a plan of escape. Update and practice your escape plan every six months. •...

  • Page 42: Safety Devices

    Section 4 LIVING QUARTERS, LP and ELECTRICAL Safety Devices (Cont’d) Return to Index NEVER IGNORE ALARMS ON SAFETY DEVICES. IF AN ALARM SOUNDS, GET EVERYONE OUT OF YOUR AVIATOR IMMEDIATELY. CO Detector Return to Index • The carbon monoxide detector is designed to detect carbon monoxide from any source of combustion.

  • Page 43: Lp Gas

    Section 4 LIVING QUARTERS, LP and ELECTRICAL LP Gas (Liquid Propane) Return to Index DO NOT bring or store LP gas cylinders, gasoline or other flammable liquids inside your Aviator.A fire or explosion could result. DO NOT fill container(s) to more than 80% capacity. Overfilling the LP tanks can result in uncontrolled gas flow which can result in an explosion or fire.

  • Page 44: Lp Regulator

      Section 4 LIVING QUARTERS, LP and ELECTRICAL LP Gas (Liquid Propane) (Cont’d) Return to Index The liquid propane (LP) gas system in your recreational vehicle furnishes the fuel for cooking, heating and hot water. LP gas can also be used as an alternate energy source for refrigeration. It is a clean, efficient and safe form of energy when proper handling and safety precautions are observed.

  • Page 45: Lp Regulator Freeze-Up

    Section 4 LIVING QUARTERS, LP and ELECTRICAL LP Gas (Liquid Propane) (Cont’d) Return to Index LP Regulator Freeze-up Return to Index The term ‘regulator freeze-up’ is a misleading one. Regulators and LP gas do not freeze. However, the moisture that can be contained in the gas will freeze as the gas expands and cools passing through the regulator.

  • Page 46: Lp Pigtail

    Section 4 LIVING QUARTERS, LP and ELECTRICAL LP Gas (Liquid Propane) (Cont’d) Return to Index LP Pigtail Return to Index The LP pigtail is a hose used to connect to the regulator on the tank through which the LP fuel flows. This safety feature is generally recognized by the large green nut that attaches to the outside of the valve on the regulator.

  • Page 47: Electrical System

    Section 4 LIVING QUARTERS, LP and ELECTRICAL Electrical System Return to Index Connecting the power cord to a non-grounded or improperly grounded power source can result in a dangerous and possibly fatal electric shock. The electrical power supply provided for the recreational vehicle is a dual system, operating with 110 volt AC and/or 12 volt DC.

  • Page 48: General Electrical Information

    Section 4 LIVING QUARTERS, LP and ELECTRICAL General Electrical Information Return to Index The electrical power supply provided for your Aviator is a dual system, operating with 110 volt AC and/or 12 volt DC. The 110 volt power is provided by connecting your Aviator to an appropriate 50 amp (VAC) RV type properly grounded power source.

  • Page 49: Battery Maintenance

    Section 4 LIVING QUARTERS, LP and ELECTRICAL Batteries (Cont’d) Return to Index The condition of the batteries is displayed on the monitor panel by pressing and holding the “Battery” test switch. Your Monitor panel is located in the bathroom. Readings are as follows: C = 12.70 to 12.85 VDC, G = 12.10 to 12.15 VDC, F = 11.60 to 11.65 VDC, L = up to 6.00 VDC.

  • Page 50: Battery Safety

    Section 4 LIVING QUARTERS, LP and ELECTRICAL Battery Safety Return to Index ALWAYS SHIELD YOUR EYES WHEN WORKING NEAR BATTERIES. BATTERIES CAN EXPLODE. DO NOTSMOKE OR EXPOSE BATTERY TO ELECTRIC SPARK OR FLAME. WHEN CHARGING OR DISCHARGING, BATTERIES GENERATE HYDROGEN. HYDROGEN AND AIR IS A VERY EXPLOSIVE MIXTURE. DO NOT SHORT ACROSS THE BATTERY TERMINALS.

  • Page 51: Power Converter (Overview)

    Section 4 LIVING QUARTERS, LP and ELECTRICAL Power Converter (Overview) Return to Index The power converter converts VAC (Voltage Alternating Current) from an external power supply to VDC (Voltage Direct Current). You also have a Distribution Panel which distributes the VAC and the VDC power to your Aviator.

  • Page 52: Ground Fault Circuit Interrupter (Gfci)

    Section 4 LIVING QUARTERS, LP and ELECTRICAL Ground Fault Circuit Interrupter (GFCI) Return to Index The 110 volt outlet in the bathroom is equipped with a protective circuit interrupter. The Ground Fault Circuit Interrupter (GFCI), is designed to break the flow of current to the protected outlets when an imbalance of current is detected.

  • Page 53: Testing The Gfci Circuit

    Section 4 LIVING QUARTERS, LP and ELECTRICAL Testing The GFCI Circuit Return to Index 1. Make sure power to the circuit is ON 2. Push the reset button. 3. The red reset button should pop out. 4. All power should be interrupted to outlets protected by the GFCI. 5.

  • Page 54: Plumbing

    Section 5 PLUMBING Plumbing Return to Index Your Aviator plumbing system has the dual ability to be self-contained with on-board storage, or use facilities provided by an external pressurized source. The fresh water system consists of those items which are used to deliver water for your use, while the waste water system is made up of the drains and tanks which store and remove water that has been used.

  • Page 55: To Disconnect From An Outside Source Of Water

    Section 5 PLUMBING To Disconnect from an Outside Source of Water Return to Index 1. Turn off the outside source of water at the source. 2. Carefully disconnect the hose from the city water inlet connection. (Spraying may occur) 3. Remove the hose and store. 4.
  • Page 56 Section 5 PLUMBING Filling the Fresh Water Tank (Cont’d) Return to Index When traveling, you may want to drain the tank or keep the quantity of water to a minimum. This will reduce the total weight of your Aviator for travel. The location of the fresh water and the waste water tank drain valve will vary from floor plan to floor plan but is generally located beneath the unit, near the respective tank.

  • Page 57: Water Pump

    Section 5 PLUMBING Water Pump Return to Index The Shurflo model# 4008 water pump supplied with your Aviator is designed to deliver smooth consistent flow of fresh water at all ranges of operation, while only drawing about 8 to 10 amps of DC current.

  • Page 58: Monitor Panel

    Section 5 PLUMBING Monitor Panel Return to Index Monitor Panels show levels for all water tanks, and battery conditions along with switches for water pump, water heater, and tank heater pads. The condition of the batteries is displayed on the monitor panel by pressing and holding the “Battery”...

  • Page 59: Sanitizing The Fresh Water System

    Section 5 PLUMBING Sanitizing the Fresh Water System Return to Index Sanitize the system before initial use, after extended periods of non-use, at least once a year during continuous use, and if there is suspicion that the system has been contaminated. Sanitizing the System Return to Index •...

  • Page 60: Water System Winterization

    Section 5 PLUMBING Water System Winterization Return to Index When storing your Aviator through periods of freezing weather, in an unheated environment, it will be necessary to winterize the water system. Damage to water system components will result if the proper winterization steps are not taken.
  • Page 61 Section 5 PLUMBING Winterizing with RV Approved Antifreeze Only Return to Index Purchase 4-6 gallons of RV approved, non-toxic antifreeze. 1. Unhook from all water sources and drain fresh water tank and all sewage tanks. Note: Black tank needs to be emptied into an approved black tank dump station. DO NOT empty the black tank onto the ground.

  • Page 62: Winterizing With Rv Approved Antifreeze Only

    Section 5 PLUMBING Winterizing with RV Approved Antifreeze Only (cont’d) Return to Index DO NOT USE AUTOMOTIVE ANTIFREEZE TO WINTERIZE POTABLE (DRINKABLE) WATER SYSTEMS. SUCH SOLUTIONS ARE HIGHLY TOXIC. INGESTION MAY CAUSE SERIOUS INJURY OR DEATH. DANGER! INDICATES A HAZARDOUS SITUATION WHICH, IF NOT AVOIDED, WILL RESULT IN DEATH OR SERIOUS INJURY.

  • Page 63: Waste Water System

    Section 5 PLUMBING Waste Water System Return to Index The waste water system in your Aviator is two separate systems. A gray water system that consists of the drain lines and holding tank for waste water from the sinks and tub, and a black water system which includes the holding tank and drain for toilet wastes.

  • Page 64: Holding Tanks

    Section 5 PLUMBING Holding Tanks Return to Index Your Aviator has the termination valves and handles located on the off door side near the rear of the unit. The termination handles are located in the exterior convenience center while the termination valves are located under the rear of the unit.

  • Page 65: To Empty The Holding Tanks

    Section 5 PLUMBING To Empty the Holding Tanks Return to Index 1. Remove the sewer drain hose from its storage compartment on the side of the coach. 2. Remove the cap from your Aviator drain and connect the drain hose to it. 3.

  • Page 66: Toilet

    Section 5 PLUMBING Toilet Return to Index The toilet installed in your aviator is connected to the pressurized fresh water system. A single lever arrangement controls flushing and the flow of water into the bowl. • To add water to the toilet before using, lift the flush lever until the desired water level is reached. (As a general rule, more water is required only when flushing solids.) •...

  • Page 67: Water System Maintenance And Troubleshooting

    Section 5 PLUMBING Water System Maintenance and Troubleshooting Return to Index As with any mechanical system, your plumbing is subject to the development of problems. Most of these problems can be greatly reduced, if not eliminated, by following a schedule of planned inspections and maintenance.

  • Page 68: Appliances

    Section 6 APPLIANCES Appliances Return to Index Each appliance in your Aviator is warranted by its manufacturer. It is very important that you review all the literature provided on your SD Card or in the Owner’s packet that came with your Aviator. Fill out and mail any warranty registration cards required by the appliance manufacturers.
  • Page 69 Section 6 APPLIANCES To Prevent Fire or Smoke Damage (Cooktop) (Cont’d) READ ALL INSTRUCTIONS BEFORE USING THE COOKTOP. THE FOLLOWING INSTRUCTIONS ARE BASED ON SAFETY CONSIDERATIONS AND MUST BE STRICTLY FOLLOWED TO ELIMINATE THE POTENTIAL RISKS OF FIRE, ELECTRIC SHOCK OR PERSONAL INJURY.

  • Page 70: Lighting The Cooktop Surface Burners

    Section 6 APPLIANCES Lighting the Cooktop Surface Burners Return to Index The Cooktop surface burners can be lit with either a match or the Piezo pilotless ignition. Be sure all control knobs are in the OFF position before supplying gas to the appliance. Be sure the main LP gas supply is on before lighting the burner.

  • Page 71: If The Cooktop Piezo Ignitor Is Not Functioning

    Section 6 APPLIANCES Cooktop Piezo Ignition (Cont’d) Return to Index 4. When the burner lights, adjust the surface burner control knob between HI and LOW to select the desired flame size. 5. After cooking, turn the surface burner control knob to the OFF position. If the Cooktop Piezo Ignitor is not functioning Return to Index •...

  • Page 72: Cooktop Shutdown Instructions

    Section 6 APPLIANCES Cooktop Shutdown Instructions Return to Index When your Aviator is not in use or while traveling, turn all three cooktop knobs to the OFF position and turn off the main gas supply. NOTE: DO NOT USE CANNERS OR OVERSIZED COOKWARE. THE PAN SHOULD NOT BE MORE THAN ONE INCH LARGER THAN THE BURNER GRATE.

  • Page 73: Convection Microwave Oven Food

    Section 6 APPLIANCES General Convection Microwave Oven Operation (Cont’d) Return to Index • There is a control panel lock on your Convection Microwave oven. Locate the STOP/CANCEL button and press and hold for 5 seconds. You will see a lock icon appear and hear two beeps. To unlock the Convection Microwave Oven, press and hold the STOP/CANCEL button for 5 seconds and the lock icon will disappear and you will hear two beeps.

  • Page 74: Refrigerator Auto Mode

    ON/OFF button to OFF and then back to ON. WHEN IN AUTO MODE, IF THE REFRIGERATOR FAILS TO OPERATE, REFER TO THE MANUFACTURERS USER MANUAL PROVIDED WITH THE FOREST RIVER OWNER’S PACKET. Refrigerator Temperature Control Return to Index With each press of the coldest button an amber led light will light indicating the desired temperature.

  • Page 75: Furnace

    Section 6 APPLIANCES Furnace Return to Index WHEN REFUELING OR PARKED NEAR GASOLINE PUMPS, SHUT OFF ALL LP GAS APPLIANCES. FAILURE TO HEED THIS WARNING COULD CAUSE A FIRE OR EXPLOSION RESULTING IN DEATH OR SEVERE PERSONAL INJURY AS WELL AS DAMAGE TO YOUR AVIATOR AND/OR SURROUNDING AREA.
  • Page 76 Section 6 APPLIANCES Furnace (Cont’d) Return to Index DO NOT INSTALL SCREENS OVER THE VENT FOR ANY REASON. DOING SO CAN CAUSE UNSAFE FURNACE OPERATION. BE SURE THE FURNACE AND ALL IGNITION SYSTEMS ARE ‘OFF’ DURING REFUELING AND WHILE VEHICLE IS IN MOTION READ THE FURNACE MANUFACTURERS USERS MANUAL.

  • Page 77: Water Heater

    Section 6 APPLIANCES Water Heater Return to Index CAREFULLY FOLLOW THE WATER HEATER MANUFACTURERS DETAILED INSTRUCTIONS REGARDING THE CORRECT OPERATION OF YOUR WATER HEATER. FAILURE TO DO SO COULD VOID YOUR WARRANTY. Water heaters require very little care. However, the most common cause of problems with your water heater is initiating operation before the tank is filled with water.

  • Page 78: Turn On Water Heater

    Section 6 APPLIANCES Water Heater (Cont’d) Return to Index If You Smell Gas • DO NOT light any appliance. • DO NOT touch any electric switch. • DO NOT use any telephone in the unit. • Immediately call your gas supplier from an outside phone. Follow the gas suppliers’ instructions. NOTE: IF YOU CANNOT REACH YOUR GAS SUPPLIER, CALL THE FIRE DEPARTMENT.

  • Page 79: Water Heater Storage And Draining

    Section 6 APPLIANCES Water Heater (Cont’d) Return to Index Water Heater Storage and Draining Return to Index If your Aviator will be stored during winter months, drain the water heater to prevent damage from freezing. 1. Turn off electrical power to water heater either at the switch or the breaker. 2.

  • Page 80: Wall Thermostat- Heating And Cooling (Main Room)

    Section 6 APPLIANCES Wall Thermostat- Heating and Cooling (Main room) Return to Index Many factors influence the ambient temperature inside your Aviator. The purpose of a thermostat is to keep the air temperature at the level you have selected. There are several things you can do to help manage the inside temperature, to avoid over-stressing your heating and cooling appliances.

  • Page 81: Television (Tv)

    Section 6 APPLIANCES Television (TV) Return to Index Your Aviator uses Sony 32” TV’s. Refer to your SD Card, Tablet, or paper manual for operating instructions of your TV. On the Model EX523 LED TV you can also use the I-manual on the TV menu itself.

  • Page 82: Outside Entertainment Center (Optional)

      Section 6 APPLIANCES Outside Entertainment Center (optional) Return to Index Your Aviator has an option for an outside entertainment center. This consists of outside speakers and a Multidisc player, as well as an option for a 32” Sony® TV. The Multidisc player can play CD’s or DVD’s, can play MP3’s, and also has Aux input for playing devices that have an Aux out capability, and is also an AM and FM tuner.

  • Page 83: Blu Ray Player

    Section 6 APPLIANCES Blu Ray Player: Return to Index Your Aviator comes standard with a Sony® 1000 watt Blu Ray 5.1 Home Theater System. This multi- functional HTS has many features. Refer to the Blu Ray owner’s manual for more information. On Main TV When playing a disc in the Blu Ray player, you must remember to turn the BX330 TV Volume all the way down.

  • Page 84: Roof Air Conditioner

    Section 6 APPLIANCES Roof Air Conditioner Return to Index Your Aviator is equipped with a roof mounted air conditioner and has an option for a second Roof A/C which would be mounted in the bedroom. They both operate on 110 volt and on 12 volt power. Wall Thermostat Cooling, To Turn Roof A/C...

  • Page 85: Care And Maintenance

    Section 7 CARE AND MAINTENANCE General Care and Maintenance Return to Index Periodic minor maintenance and cleaning of your Aviator is necessary to retain the dependability, safety and appearance that will provide you with many miles of trouble free operation as well as protecting your investment.

  • Page 86: Seals And Adhesives

    Only a defect in workmanship or materials would be considered warranty and is at the sole discretion of the Aviator by Forest River division. When washing your Aviator, inspect the seals for signs of drying out and wear. Be aware that weather and road vibration will have an effect on seals, causing them to dry, crack or separate.
  • Page 87 Section 7 CARE AND MAINTENANCE Windows and Doors (Cont’d) Return to Index DO NOT COVER EMERGENCY WINDOW(S). THESE EXIT WINDOWS MUST REMAIN ACCESSIBLE AT ALL TIMES. BE SURE ALL OCCUPANTS AND GUESTS KNOW WHICH WINDOWS ARE THE EMERGENCY EXIT WINDOWS AND UNDERSTAND HOW TO USE THEM.

  • Page 88: Frame, Extrusions And Aluminum Surfaces

    INSPECT THE ROOF, USE EXTREME CAUTION WHEN ON THE ROOF OR USING WHATEVER METHOD YOU USE TO GAIN ACCESS TO THE ROOF. AVIATOR AND FOREST RIVER RECOMMEND THAT ONLY YOUR DEALER PERFORM ANY ROOF RELATED INSPECTIONS OR REPAIRS. SHOULD YOU SUSPECT ANY ROOF ISSUES CONTACT YOUR AVIATOR SELLING DEALER IMMEDIATELY.

  • Page 89: Lp Gas System

    Section 7 CARE AND MAINTENANCE LP Gas System Return to Index To ensure proper operation, have the LP gas system checked frequently for leaks and road damage. The entire system including regulator pressure, should be checked annually or sooner, if you suspect a problem.

  • Page 90: Winter Precautions

    Section 7 CARE AND MAINTENANCE Winter Precautions Return to Index • Winter Precautions Water Systems: Return to Index In severe cold it is wise to monitor the water temperature in the tank and take steps to drain and winterize if necessary. It is also a good idea, in severe cold, to open lower cabinet doors in the kitchen and bath to allow warm air to circulate around water fixtures.

  • Page 91: Winter Storage Tips

    Section 7 CARE AND MAINTENANCE Winter Storage Tips Return to Index 1. Park your Aviator on a level surface. 2. Winterize the chassis. 3. Clean your Aviator thoroughly, inside and out, as previously outlined in this section. 4. Turn off all electrical switches and appliances. 5.

  • Page 92: Winter Storage Preparation

    Section 7 CARE AND MAINTENANCE Winter Storage Preparation Return to Index When storing you Aviator for the winter, certain precautions need to be taken to protect your unit. Be sure to talk with your local dealer concerning any special requirements, for storage, in your particular geographic location.
  • Page 93 Section 7 CARE AND MAINTENANCE Winter Storage Preparation (Cont’d) Return to Index Item Each Each Every Procedure Trip Month Months Months Year Req. Electrical CHECK GFI CIRCUITS. System CHECK AND SERVICE BATTERY/S REMOVE FOOD & ICE FROM Appliances REFRIGERATOR AFTER EACH TRIP CHECK FOR OBSTRUCTIONS &...

  • Page 94: Formaldehyde From Building Materials

    Section 7 CARE AND MAINTENANCE Formaldehyde from Building Materials Return to Index Certain building products such as particleboard, fiberboard and hardwood plywood are manufactured with an adhesive containing urea-formaldehyde. These products emit a small quantity of formaldehyde into the air. Other products containing formaldehyde or urea-formaldehyde resins are some carpets, draperies, upholstery, fabrics, deodorizers, cosmetics and permanent press fabrics.

  • Page 95: Waterpur Tm

    Section 7 CARE AND MAINTENANCE WaterPur (Cont’d) Return to Index Gold Seal labeled products must meet the Water Quality Association’s Code of Ethics standards. Only the Water Quality Association can award the Gold Seal, and only products meeting comprehensive industry standards can earn it.

  • Page 96: Waterpur Tm Operating Instructions

    Section 7 CARE AND MAINTENANCE WaterPur Operating Instructions (Cont’d) Return to Index The replaceable cartridge, which is the heart of the WaterPur system, has been tested to meet the material requirements of NSF Standards 42, 53 and 58. It has been tested to meet the performance requirements of NSF Standard 42 for Class 1 Chlorine reduction and Standard 53 for Class 1 Turbidity and Cyst reduction.

  • Page 97: Waterpur Tm Operational Note

    Section 7 CARE AND MAINTENANCE WaterPur Operating Instructions (Cont’d) Return to Index WaterPur Operational Note: Return to Index The WaterPur cartridge is not to be autoclaved or steam sterilized. Use the WaterPur cartridge with microbiologically safe water. Activated carbon filters are not designed to kill or remove bacterial or viruses.

  • Page 98: Aviator Maintenance/Repair Schedule Records

    Section 7 CARE AND MAINTENANCE Aviator Maintenance/Repair Schedule Records Return to Index Maintenance / Repair Schedule Service Center Name / Address Page 98 Revised September 2012...
  • Page 99 Section 7 CARE AND MAINTENANCE Aviator Maintenance/Repair Schedule Records Return to Index Maintenance / Repair Schedule Service Center Name / Address Page 99 Revised September 2012...
  • Page 100 Section 7 CARE AND MAINTENANCE Aviator Maintenance/Repair Schedule Records Return to Index Maintenance / Repair Schedule Service Center Name / Address Page 100 Revised September 2012...
  • Page 101 Section 7 CARE AND MAINTENANCE Aviator Maintenance/Repair Schedule Records Return to Index Maintenance / Repair Schedule Service Center Name / Address Page 101 Revised September 2012...

  • Page 102: Aviator Maintenance/Service Date And Procedure Records

    Section 7 CARE AND MAINTENANCE Aviator Maintenance/Service Date and Procedure Records Return to Index Maintenance/Service Date and Service Center Name, Address, Travel Journal Procedure and Telephone Number Page 102 Revised September 2012...
  • Page 103 Section 7 CARE AND MAINTENANCE Aviator Maintenance/Service Date and Procedure Records Return to Index Maintenance/Service Date and Service Center Name, Address, Travel Journal Procedure and Telephone Number Page 103 Revised September 2012...
  • Page 104 Section 7 CARE AND MAINTENANCE Aviator Maintenance/Service Date and Procedure Records Return to Index Maintenance/Service Date and Service Center Name, Address, Travel Journal Procedure and Telephone Number Page 104 Revised September 2012...
  • Page 105 Section 7 CARE AND MAINTENANCE Aviator Maintenance/Service Date and Procedure Records Return to Index Maintenance/Service Date and Service Center Name, Address, Travel Journal Procedure and Telephone Number Page 105 Revised September 2012...
  • Page 106 Section 7 CARE AND MAINTENANCE Aviator Maintenance/Service Date and Procedure Records Return to Index Maintenance/Service Date and Service Center Name, Address, Travel Journal Procedure and Telephone Number Page 106 Revised September 2012...
  • Page 107 2 3 7 2 C e n t u r y D r i v e G o s h e n , I N 4 6 5 2 8 5 7 4 - 6 4 2 - 0 1 5 7 w w w .
