Rixen Digital Heating Thermostat Manual

Rixen Digital Heating Thermostat
Manual v1

User interface:

Only light pressure is needed to operate the 3 buttons. Display will dim after 15 seconds, tap
any of the 3 buttons to return to full illumination.
1. When the Heater is switched OFF
n/a
Heater On/Off
n/a
2. When Heater is switched ON
(and set temp is above room temp i.e heater running)
Set Temp up
Heater On/Off
Set Temp
down
3. When Heater is switched ON
(and set temp is below room temp, i.e. heater on standby)
Set Temp up
Heater On/Off
Set Temp
down
4. Setup Programming options:
a. Set display to Fahrenheit or Celsius
b. Temperature sensor select:
Internal (default) or
External Sensor (Note: external sensor needs to be ordered separately)
Internal temp sensor location
Room temperature
Heater status=Off
Room temperature
Heater running indicator
Set temperature display
Room temperature
Heater standby indicator
Set temperature display
To enter programming mode:
Hold the On/Off button until the display appears.
To toggle between Internal and external sensor tap
the up arrow (only one sensor active at a time).
To toggle between Fahrenheit and Celsius tap the
down arrow.
To leave programming mode tap the On/Off button.
