- Page 1 PRO KICK FOOSBALL 55206 ITEM NUMBER: For all your replacement part needs, please visit: www.franklinsports.com/55206 Made In China -- Toy contains small Franklin Sports Inc. balls and small parts. Not for children under 3 yrs. Stoughton, MA 02072 Adult assembly required.
- Page 2 PARTS LIST Click on a part below to order online. Side Aprons End Aprons Support Braces Rep. Part: 55206-R1 Rep. Part: 55206-R2 Rep. Part: 55206-R3 Soccer Field Ball Returns Scorers Rep. Part: 55206-R4 Rep. Part: 55206-R5 Rep. Part: 55206-R6 Black Player Rods Blue Player Rods Foosballs Rep.
- Page 3 ASSEMBLY INSTRUCTIONS GENERAL NOTE 1. Find a clean place to begin the assembly of 2. Remove all the parts from the box and verify your Pro Kick Foosball Game. that you have all of the listed parts as shown on the parts list page. STEP 1 PARTS NOTE...
- Page 4 STEP 3 PARTS NOTE Slide the Soccer Field (A4) into the grooves. STEP 4 PARTS NOTE Slide the Black Player Rods (A7) and the Blue Player Rods (A8) into the holes in the Side Apron (A1). STEP 5 PARTS NOTE Slide the remaining Side Apron (A1) into the remaining Support...
- Page 5 STEP 6 PARTS NOTE Slide the End Aprons (A2) into the Support Braces (A3). Use Small Screws (B4) to secure the aprons to the Support Braces (A3). STEP 7 PARTS NOTE Slip the Handles (B2) and the Caps (B3) onto the ends of the player rods.
- Page 6 STEP 9 PARTS NOTE Use Large Screws (B5) to secure the Ball Returns (A5) to the End Aprons (A2). STEP 10 PARTS NOTE Insert the Scorers (A6) into the holes on top of the Ball Returns (A5). YOU ARE NOW READY TO PLAY! For replacement parts: ITEM#: 55206...
