Content of the upgrade:
-
DAC-Board
-
2 cables
-
2 transistor heat sinks
1. Switch OFF the I22 and disconnect AC-cable.
2. Open top cover of the I22.
3. Unscrew back plate off the I22. (4 screws)
4. Install both cables on audio board. (see picture RED arrows)
5. Install DAC board using the 4 screws from the back plate.
Primare AB • Renvägen 1 • SE-35245 Växjö • Sweden • Tel +46 470 729215 • www.primare.net
I22 DAC-upgrade
