Installation Procedure
05 November, 2004
Digital Audio Option
Background
This procedure describes the process required to install the Digital Audio Option into an existing WSD/HDe Digital Disk Recorder. Only
qualified technical personnel should perform this installation procedure.
This installation procedure requires you to remove the WSD/HDe chassis from the equipment rack (if it is rack-mounted). The entire
installation procedure should take less than an hour (60 minutes) to perform, including removal of the WSD/HDe chassis from an
equipment rack. If the WSD/HDe is not rack mounted, the procedure should take less than 30 minutes to perform.
It is strongly advised for you to first read over this entire document before beginning this procedure, to make sure you understand the task
you are about to perform. If you have any questions about or difficulty in performing this procedure, contact Accom Technical Support
between the hours of 8:00am and 4:00pm Pacific Standard Time (PST) at +1-650-328-3818. Or e-mail J. Vyas at jvyas@accom.com
Parts Included
The Digital Audio Option Installation Kit includes the following items:
(1) PCI Board / Digital Audio 8-Track
Accom Part Number 9400-0920-01
(2) Cable Assembly / 20-Pin Mini Ribbon
Accom Part Number 9000-0776-00
(1) Cable Assembly / 26-Pin-D Digital Audio
Accom Part Number 9000-0741-00
(1) Adaptec SCSI RAID Controller 2100S
Accom Part Number 2500-0335
(1) Audio Breakout Panel
Accom Part Number 9500-0328-00
(2) Audio Breakout Panel / Leg Stand
Accom Part Number 8900-1406-00
(2) Audio Breakout Panel / Rack Ears
Accom Part Number 8900-1407-00
Tools Required
The following tools are required to perform this installation:
Philips-Head Screw Driver / Large Size
Continued on next page...
Document Revised: 5-Nov-04 @ 8:09 AM
PERMISSION FROM ACCOM, INCORPORATED.
©2004 / Accom, Incorporated
Copyright © 2004 / Accom, Incorporated
(4) Rubber Foot
Accom Part Number 1901-0441
(4) Philips-Head Screws / 6-32 x 1/4"
Accom Part Number 1901-0251
(14) Philips-Head Screws / 6-32 x 3/16"
(12) screws are required for retrofit; (2) are extra
Accom Part Number 1901-6328
(4) Label / WSD-HD Options
Accom Part Number 8901-1252-01
(2) SCSI Disk Drive / 18GB or 36GB or 73GB
Accom Part Number 1600-0148 for 18GB; -0149 for 36GB; -0146 for 73GB
Philips-Head Screw Driver / Medium Size
