Never use other acids, enzymes or detergents, as
this may risk creation of poisonous gas or cause
malfunctioning.
The cover has an inner cover which can also be
removed for easy cleaning.
•Pull the grip to release.
•After cleaning the inner cover, replace by holding
the grip and pressing down inner cover to water
tank.

PRECAUTIONS

Avoid unit malfunction by taking note of the
following:
•Do not fill over 80ml ("MAX") at any time.
•Do not switch on the power when the tank is
empty.
•Do not touch the Ultrasonic vibration plate.
•Clean regularly as per Maintenance instructions to
avoid malfunctioning
•Always unplug from the power supply before
•For hygiene purposes, pour away remaining water
from "DRAIN SIDE" of the tank, and wipe with a
clean dry cloth after each use.
•Essential oils can stain. In case of oil spillages on
other surfaces, wipe away with a soft cloth.
•Only use the measuring cup provided to add water
to the tank. Never fill directly from the tap.
•Do not let mist blow directly onto furniture,
clothing, walls, etc.
•Keep away from direct sunshine, heat sources, air
conditioners, or fans.
•Always keep on a stable flat surface. Do not place
on carpet or any unstable area.
•Keep away from electronic equipment, such as TV
and audio equipment.
•Do not tip the product. This may cause water to
enter the mechanism and cause malfunctioning.
•Do not use for more than 3 hours any time.

TROUBLESHOOTING

Please refer to the table below in case product is not working
properly.
Problem Possible Cause
Solution
•Is there enough
•Add water to the tank
Will not
•Disconnect, check the cables
water in the tank?
switch
•Is the power cord
on or off
and reconnect carefully.
connected properly?
•Not enough water?
•Add correct amount of water in
No mist
•Too much water?
or
the tank.
•Dirt on the
•Tank must never be filled over
abnormal
ultrasonic plate?
mist
80ml of water
•Cover and inner
•Please refer to maintenance
cover are not
instructions.
installed properly?
•Remove and re-install
•Dirt on the air intake
correctly, so vapors can be
on the underside of
the base?
released freely.
•Clean the air intake of any dust
restricted airflow will affect
mist.
•Cover and inner
•Remove and reinstall correctly,
Water
cover not installed
leakage
so vapors can be released
properly?
from
freely.
• Has the unit tipped
•Follow accidental leakage
product
over?
instructions.
•Low temperature or
•Under these conditions, the
high humidity?
mist may condense quickly into
water droplets.

SPECIFICATIONS

Approx 5.9" x 5.9" x 5.2"
Dimensions
Weight
(excluding
Approx 9.2 oz.
adaptor)
Power Input/Output
AC 100-240V 50.60HZ / DC 12V 1A
Adapter Certification
UL, CE, RoHS
Approx. 67"
Length of Cord
Electric consumption
Approx. 9W
Water tank capacity
80ML
LED light
6 Bulbs
Materials
Upper parts PP, lower base ABS
Method
of
mist
Ultrasonic vibration at approx 2.4MHz
production

WARRANTY

Smiley Daisy provides free 180 days product
replacement warranty for this product, which starts
from the date of your purchase. Please keep your
sales receipt handy in a safe place.
AROMA DIFFUSER
User Manual
Visit our website for
PO Box 2252
Livingston, NJ 07039 U.S.A.
tips, tricks, coupons and
201-455-7770 M-F 9am-5pm
more!
(EST)
www.smileydaisy.com
