Outer layer
Flame resistant polyolefin
(Equivalent to UL-94 standard V-0)
Middle layer
Aluminum laminated film
Inner tube
Polyurethane
For general pneumatic and water
piping in environments exposed
to sparks from arc welding, etc.
How to measure the
minimum bending radius
Bend the tube into the U-form at a
temperature of 20°C. Fix one end and
close loop gradually. Measure 2R when
the deformed ratio of the tube diameter at
bending reaches 5%.
Burst Pressure Characteristics
Curve and Operating Pressure
4.0
3.0
Burst pressure
2.0
1.0
Max. operating pressure
0.0
−20 0
Operating temperature (°C)
1
Courtesy of Steven Engineering, Inc.-230 Ryan Way, South San Francisco, CA 94080-6370-Main Office: (650) 588-9200-Outside Local Area: (800) 258-9200-www.stevenengineering.com
Flame Resistant (Equivalent to UL-94 Standard V-0)
FR Three-layer Polyurethane Tubing
Series
Model
Inner tube O.D. (mm)
Inner tube I.D. (mm)
Outer layer thickness (mm)
Specifications
Fluid
Applicable fittings
Max. operating
pressure
Burst pressure
Min. bending radius (mm)
2R
Ambient and fluid temperature
Material
Note 1) Applicable for general industrial water. Please consult with SMC if using for the other kind
Note 2) The minimum bending radius is the representative value measured as shown in the left
Note 3) The color of all inner tubes is black.
TRTU0604
TRTU0805
TRTU1065
TRTU1208
20 40 60
TRTU
Model TRTU0604
Black (B)
White (W)
Note 3)
Outer
Red (R)
layer
Blue (BU)
color
Yellow (Y)
Green (G)
Note 1)
At 20°C
At 40°C
At 60°C
Note 2)
Inner tube
Middle layer
Outer layer
of fluid. Also, the surge pressure must be under the maximum operating pressure.
If the surge pressure exceeds the maximum operating pressure, it will result in damage to
fittings and tubes.
figure. Allow extra length when piping since the tube may be bent if used under the
minimum bending radius.
TRTU1065 B 20
Tubing model
Model Inner tube O.D. x I.D. (mm)
6 x 4
8 x 5
10 x 6.5
12 x 8
b — 20 m roll „ — 100 m reel
TRTU0805 TRTU1065
6 8
4 5
1 1
Air, Water
FR one-touch fittings: Series KR-W2
Metal one-touch fittings: Series KQB2
0.8 MPa
0.65 MPa
0.5 MPa
Refer to the burst pressure characteristics curve.
50 60
−20 to +60°C Water: 0 to 40°C (No freezing)
Polyurethane
Aluminum laminated film
Polyolefin (Equivalent to UL-94 standard V-0)
How to Order
Color
Symbol Color
B
Black
W
White
R
Red
BU
Blue
Y
Yellow
G
Green
RoHS
TRTU1208
10 12
6.5 8
1 1
70 80
Length per roll
Symbol Length
20
20 m roll
100
100 m reel
