R E A R S
Pakblast 50 Gal
PAKBLAST
50 GALLON
READ THIS MANUAL BEFORE OPERATING
06.11.2018
800346 7867
CHEMICAL CONTAINERS INC. LAKE WALES, FLORIDA

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Pakblast 50 Gal and is the answer not in the manual?

Questions and answers

Summary of Contents for Rears Pakblast 50 Gal

  • Page 1 R E A R S Pakblast 50 Gal PAKBLAST 50 GALLON READ THIS MANUAL BEFORE OPERATING 06.11.2018 800346 7867 CHEMICAL CONTAINERS INC. LAKE WALES, FLORIDA...
  • Page 3 Sprayer Safety: Operator Tranng Safety is a primary concern in the design and manufacture of our products. Unfortunately, our efforts to provide safe equipment can be wiped out by a single careless act of an operator. READ THE OPERATOR’S MANUAL In addition to the design and configuration of equipment, hazard control and ac- cident prevention are dependent upon the awareness, concern, prudence and proper training of personnel involved in the operation, transport, maintenance and storage...
  • Page 4 Sprayer Safety: Preparaton Never operate the tractor and implement until you read and completely understand this manual, the tractor operator’s manual, and each of the safety messages found on the safety decals on the tractor and the implement. Personal protection equipment, including a hard hat, safety glasses, safety shoes, and gloves are recommended during assembly, installation, operation, adjustment, maintenance, repair, removal, or transport of this implement.
  • Page 5 Sprayer Safety: Startng & Stoppng Implement operating power is supplied from the tractor’s PTO. Refer to your tractor manual for PTO engagement and disengagement instructions. Always operate the implement at its required PTO speed: either 540 or 1000 rpm. Know how to stop the tractor and implement quickly in case of an emergency.
  • Page 6 Sprayer Safety: Chemcals Never provide agricultural chemicals to anyone unless that person has been properly trained or licensed. Make certain the entire manufacturer’s label appears on the chemical container. Always follow the manufacturer’s instructions for storage, handling, and application. Before a spraying operation is started the spray system should be rinsed and all nozzles, screens, and strainers cleaned.
  • Page 7 The skin on various body parts does not absorb pesticides at the same rate. The figure, right, illustrates skin absorption rates based on a numerical scale in which the value of 1 for the forearm represents the lowest dermal absorption rate. That value forms the basis for the assignment of values to the other body parts.
  • Page 8 Sprayer Safety: Pre-operaton Install and secure all guards and shields before starting or operating. Frequently check fan blades. They should be free of nicks and cracks. The fan guard must be kept clean and in good repair. The mechanical cabinet access guards, fan guard, sag chains, driveline shields, and gearbox shields should be used and maintained in good working condition.
  • Page 9 Be aware of the meteorological conditions and plan spray applications during op- portune times. High winds and low humidity will increase drift and adversely affect your spray program. Avoid spraying near lakes, streams, pastures, population areas (houses, schools, playgrounds, hospitals) beehives or sensitive non-target crops. Always spray downwind from these sensitive areas and do not spray during adverse wind or low humidity conditions.
  • Page 10 v Sprayer Safety: Operaton The use of this equipment is subject to certain hazards which cannot be protected against by mechanical means or product design. All operators of this equipment must read and understand this entire manual, paying particular attention to safety and operating instructions, prior to use.
  • Page 11 Do not allow riders on the implement or tractor at any time. There is no safe place for any riders. Disengage PTO and place transmission into neutral before attempting to start the engine. Do not operate unless all personnel, livestock, and pets are out of your application area.
  • Page 12 Never try to unclog a nozzle by blowing through it. Always carry extra spray tips. Never operate tractor and implement under trees with low hanging limbs: the op- erator can be knocked off the tractor and run-over. Stay alert for holes, rocks and roots in the terrain and other hidden hazards. Keep away from drop-offs.
  • Page 13 Sprayer Safety: Tres Failure to follow proper procedures when mounting a tire on a wheel or rim can produce an explosion which may result in serious injury or death. Do not attempt to mount a tire unless you have the proper equipment and experi- ence to do the job.
  • Page 14 Sprayer Safety: Mantenance Good maintenance is your responsibility. Poor maintenance is an invitation to trouble. Follow good shop practice. Keep service area clean and dry. Be sure electrical out- lets and tools are properly grounded. Use adequate light for the job at hand. Make sure there is plenty of ventilation.
  • Page 15 x When completing a maintenance or service function, make sure all safety shields and devices are installed before placing the unit back in service. Remove hydraulic pressure prior to doing any maintenance. Block the implement securely, disengage the PTO, and turn off the engine. Never use your hands or any part of your body to locate a hydraulic leak.
  • Page 16 Sprayer Safety: Transport Comply with state and local laws governing highway safety and movement of farm machinery on public roads. reflective red border fluorescent yellow/orange The use of flashing amber lights is acceptable in most localities. However, some localities prohibit their use. Local laws should be checked for all highway lighting and marking requirements.
  • Page 17 Sprayer Safety: Storage With pull-type units, never unhitch the implement without using the tongue jack. The tongue is very heavy. Attempting to lift the tongue without using the tongue jack could cause personal injury. Overloading the jack can cause failure with pos- sible serious injury or even death.
  • Page 18 Sprayer Safety: Safety Decals This is the SAFETY-ALERT symbol. This symbol is used to visibly mark operating hazards. YOU MUST FOLLOW THE DIRECTIONS POSTED BESIDE THE SAFETY-ALERT SYMBOL TO AVOID BODILY INJURY OR DEATH. Before you operate any machinery, read the operator’s manual. A copy of every SAFETY-ALERT decal on your implement is included in your operator’s manual with a map of each decal on your implement.
  • Page 19 xv Read ths manual completely before operatng: follow all safety nstructons.
  • Page 20 Pak-Blast 50 gallon KEEP ALL FASTENERS TIGHT WHEEL BOLTS, CLAMPS, TANK MOUNTS, BLADE HANGERS, GEARBOX MOUNT GUARDS, VALVE BRACKETS, MOTOR SHAFT SET SCREWS, PUMP HOSE CLAMP COTTER PINS, BOOM CYLINDERS, TENSION JAM NUT, ETC., ETC... CHECK ALL FASTENERS REGULARLY AS A PART OF YOUR MAINTENANCE SCHEDULE.

  • Page 21: Safety Decal Locations

    Decal 91 is only present on units with hydraulic controls. Make certain all decals listed here are present on the sprayer and in good condition. Replacement decals are available from your dealer or direct from Rears. Read this manual completely before operating: follow all safety instructions.

  • Page 22: Pre-Operation Check List

    Pak-Blast 50 gallon Pre-operation check list 1. Top off the gearbox oil if needed. You will find instruc- tion for how to check the oil level in your gearbox and a list of recommended lubricants included on the parts page for your gearbox in this manual. 2.

  • Page 23: Operation Tips

    Use the Calibration In- structions for Rears Airblast Sprayers to select an operat- ing gear and speed for your application. 3 Take care when driving over rough ground- protect Beginning of season the sprayer from excessive shocks when bouncing.

  • Page 24: Hook-Up Instructions

    Pak-Blast 50 gallon Hook-up instructions fig.1 1 Read and understand all instructions before beginning. 2 For your safety, do not make adjustments to the 3-point connections with the tractor running. 3 Position tractor and implement on a level surface. Check air pressure in all tires. 4 The sprayer tank should be empty.
  • Page 25 Pak-Blast 50 gallon side view top view Measure distance between the end of your tractor PTO shaft and the center of the lift arm ball sockets. The ball sockets must be level with the PTO shaft: slide a broom handle through the ball sockets to aid measurement.

  • Page 26: Lubrication And Maintenance

    Pak-Blast 50 gallon fl.oz agitator bearings front and rear of tank Lubrication and maintenance All lube points have been made accessible. Lubrication does not require disassembly. Always use a Lithium base NLGI Grade 2 grease. We recommend Texaco Multifak Shell Alvania 2 , and Mobil Mobilux Use an oil compatible with your pump or gearbox- listed on the schedule, below.
  • Page 27 Pak-Blast 50 gallon pak blast. No. Part # Description No. Part # Description MB050F 50 gallon frame LDLATCH lid latch manifold mount bracket SITE002P037 volume sight-gauge tubing MBM22R manifold, right AG06215 agitator bearing- see bearing parts list MBM22L manifold, left MB710 braglia control mount plate MBTG22...
  • Page 28 Pak-Blast 50 gallon 800 346 7867 CHEMICAL CONTAINERS INC.
  • Page 29 Pak-Blast 50 gallon troubleshooting: excessive pressure drop Check the suction and discharge strainers- clean screens. Check the pump oil level: see the pump maintenance sec- tion of this manual. Check suction and discharge lines- all lines must be free of damage and fittings must be tight. Spray system is not calibrated properly: the pump does not have the capacity to deliver the gallons per minute needed for your spray tip selection.
  • Page 30 Pak-Blast 50 gallon 4 26 GEARBOX SHAFT AGITATOR belts 4/3VX560 agitation 4L370 PUMP 26 27 28 29 4/3V fan belt drive agitation belt drive for A58 fan belt, see following section No. Part # Description No. Part # Description AGP06206 agitator pulley 5/8”bore x 6”dia KB5043 idler spindle...
  • Page 31 Pak-Blast 50 gallon SHUT DOWN TRACTOR, SET BRAKE AND REMOVE KEY WHEN WORK- ING ON SPRAYER. NEVER OPERATE SPRAYER WITH GUARDS MISSING. ALWAYS SUPPORT SPRAYER DURING MAINTENANCE: SET ON GROUND OR PLATFORM. NEVER WORK ON SUS- PENDED IMPLEMENT. previous page group A previous page group B installing replacement belt 1.
  • Page 32 Pak-Blast 50 gallon INDEX fig ii SHUT DOWN TRACTOR, SET BRAKE fig i AND REMOVE KEY WHEN WORK- ING ON SPRAYER. NEVER OPERATE SPRAYER WITH GUARDS MISSING. ALWAYS SUPPORT SPRAYER DURING tension micro-v fan belt drive MAINTENANCE: SET ON GROUND OR for A58 fan belt, see following section PLATFORM.

  • Page 33: Side-To-Side

    Pak-Blast 50 gallon SHUT DOWN TRACTOR, SET BRAKE AND REMOVE KEY WHEN WORK- ING ON SPRAYER. NEVER OPERATE SPRAYER WITH GUARDS MISSING. ALWAYS SUPPORT SPRAYER DURING MAINTENANCE: SET ON GROUND OR PLATFORM. NEVER WORK ON SUS- PENDED IMPLEMENT. tension A58 fan belt drive for micro-v fan belt, see previous section CHECK NEW BELT TENSION AT 4 &...
  • Page 34 Always use an AGMA No.2 EP rated gear lubricant, such as Mobilgear 600 XP 68. MGB22 is a sealed bearing housing. There is no oil level gauge. When repairing the drive case, the recommended lubricant level is 12 ounces. Check oil level at least every 6 years. FAN SELECTION Measure from face of casting to end of shaft...
  • Page 35 Pak-Blast 50 gallon Set blade pitch SET BLADE PITCH WITHIN RECOMMENDED RANGE OR BELT DAMAGE WILL RESULT BELT TENSIONER BLADE PITCH RANGE micro-V page 14 A-58 page 15 When delivered, your blade pitch should be set at 6. Follow these in- structions to adjust your blade pitch.

  • Page 36: Fan Installation

    Pak-Blast 50 gallon DANGER! DO NOT REMOVE FAN GUARD WITH TRACTOR RUNNING. BEFORE REMOVING FAN GUARD SHUT DOWN TRACTOR, SET BRAKE AND Blades removed for REMOVE KEY. illustration purposes only NEVER OPERATE SPRAYER WITHOUT FAN GUARD INSTALLED. Fan Shaft Fan Cover Washer Fan Installation 1.
  • Page 37 Pak-Blast 50 gallon 126 Line Strainer Assembly 1” inlet 1-1/4” inlet 1-1/2” inlet Description 126ML-4- 126ML-5- 126ML-6- complete strainer- include screen mesh mesh # mesh # mesh # 50492-1-PP 63065-1-1/4PP 63066-1-1/2PP strainer head 16903-1-SSPP 15941-1-SSPP 16 mesh screen, gray 16903-3-SSPP 15941-2-SSPP 30 mesh screen, yellow 16903-4-SSPP...
  • Page 38 Pak-Blast 50 gallon right manifold line pump pressure supply line left manifold line dump- tank return line handgun valve tank return/mix valve this valve tank return/mix line 100 gallon unit with trellis fan housing shown, left. LFG600 BR170 see parts page The mix/return valve must remain...
  • Page 39 Pak-Blast 50 gallon BR170 selector valve with pressure regulator 170.1902.18 170.104.3 170.214.2 170.1902.18 (x4) 170.1902.18 29.1604.2 (x2) 170.1902.18 170.1003.12 (x2) 9.301.7 170.104.1 170.304.1 170.602.26 170.215.1 170.1902.16 23.1003.16 23.1003.16 170.1608.1 LFG600 170.1604.4 170.1604.4 170.1003.10 73.602.22 170.214.1 73.602.58 170.6.1 170.7.1 170.1617.16 170.1609.1 170.602.24 170.602.25 170.601.23...
  • Page 40 Pak-Blast 50 gallon braglia dump valve or spray control valve brown blue braglia dump valve and pressure regulating valve 800 346 7867 CHEMICAL CONTAINERS INC.
  • Page 41 Pak-Blast 50 gallon Braglia valve assemblies No. Part # Description 180.1910.9HS Dump valve, 1” port, black cap 180.1910.9 Dump valve, 1” port, orange cap, obsolete 180.1910.19HS Dump valve, 3/4” port, black cap 180.1910.19 Dump valve, 3/4” port, orange cap, obsolete 180.232.6 valve signal control cable call...
  • Page 42 right left...
  • Page 43 braglia metered bypass set-up Before calibrating your metered bypass valves be sure you have water in your spray tank. The tank should be at least 1/4 full before engaging the PTO. Make sure the dump valve and handgun valve are closed. The spray tips installed should match your desired application rate.
  • Page 44 Pak-Blast 50 gallon 180.601.2 BLACK CAP ORANGE CAP OBSOLETE SEE MOTOR/BODY COMPATIBILITY CHART 141.602.17 142.602.18 180.602.49 180.232.5 180.602.49 MOTOR/BODY 180.620.35 22RPM 180.620.4 8.5RPM MOTOR COMPATIBILITY 180.507.12 180.620.35 180.620.6* CHART DISCARD WHEN BLACK CAP ORANGE CAP UPGRADE TO 180.620.35 180.218.153 180.1910.9HS BLACK MOTOR 180.218.4* 1”...
  • Page 45 Pak-Blast 50 gallon 180.601.2 GREEN CAP GREEN CAP OBSOLETE SEE MOTOR/BODY SEE MOTOR/BODY COMPATIBILITY COMPATIBILITY CHART CHART 141.602.17 142.602.18 180.232.5 180.602.49 180.602.49 180.620.6.25 180.620.6 MOTOR/BODY MOTOR COMPATIBILITY 180.1910.10 180.620.6.25* CHART 180.620.6 pressure regulating valve parts OBSOLETE 180.218.153 180.218.4* OBSOLETE *LIMITED AVAILABILITY 180.4.8 180.614.7 68.602.9...

  • Page 46: Valve Troubleshooting

    Pak-Blast 50 gallon 180.1910.9HS 180.1910.19HS 180.1910.9/180.1910.19 valve repair LOCK ONLY USED WITH ORANGE CAP MOTOR ASSY valve troubleshooting Valve doesn’t activate. Check cable connections- look for oxidation and clean. Check fuse. ONLY USE 1.25A time delay fuse. Repeated fuse blow out. Disconnect power cable and remove lock 29 with screwdriver.

  • Page 47: Valve Disassembly

    Pak-Blast 50 gallon fig. i important To install ball 23 align notch on stud 18 opposite valve disassembly the discharge port Disconnect power supply and remove all lines from valve ports. Insert ball as shown. Hold the valve firmly, gripping the side ports, and remove nipple 25 from valve using a CH32 wrench.
  • Page 48 Pak-Blast 50 gallon 3/4”-14 NPT 1” NPT R7 hydraulic spray valve No. Part # Description DAH2W075 R7 hydraulic actuated valve, complete DAHV2WKIT repair kit includes all • items DAH2WV13 valve body inlet 759051 valve assembly V75-026 • o-ring, viton V75-131 •...
  • Page 49 Pak-Blast 50 gallon Read this manual completely before operating: follow all safety instructions.

  • Page 50: Pump Operation

    PUMP OPERATION Do not over-speed your pump Refer to the performance chart for your specific pump to Maintain proper oil level find the maximum operating speed. Your pump is de- signed to operate at or below this speed. Over-speeding The crankcase oil serves two important functions. The oil lu- will cause valves to prematurely fail and could cause bricates all moving parts in the pump and affects the hydraulic other internal damage.

  • Page 51: Pump Maintenance

    PUMP MAINTENANCE HANDLE AGRICULTURAL CHEMICALS WITH CARE USE THE PERSONAL PROTECTIVE EQUIPMENT After each use RECOMMENDED BY THE CHEMICAL MANUFACTURER Run pump for five minutes with clean water. These few minutes WHEN MAINTAINING SPRAY EQUIPMENT! of flushing are well spent: extend diaphragm life, minimize chemical buildup throughout your spray system.

  • Page 52: Troubleshooting

    Pak-Blast 50 gallon TROUBLESHOOTING The AR diaphragm pump delivers volume determined by pump speed. Set pressure with your adjustable relief valve. Problem Source No pressure Plugged strainer Clean screen- see suction care on pump operation page. Suction hose obstruction Clear obstruction Very little pressure Collapsed suction hose outside or inside tank Replace collapsed hose...

  • Page 53: Outboard Bearing

    Mechanical agitation Part # Description 5/8” shaft 3/4” shaft AG06210ASSY AG07510ASSY complete rear bearing AG06203ASSY AG07503ASSY complete front bearing AG062ESS AG075ESS packing nut w/packing AG025 (6”) AG025 (11”) packing AG062C AG075C locking ring AGBSH062 AGBSH075112 bushing AG06210 AG07510 rear housing w/busings AG06203 AG07503 front housing w/busings...
  • Page 54 Pak-Blast 50 gallon BR123W Standard BR2/BR2DC nozzle configuration: A side- ceramic orifice/core, nylon strainer B side- steel orifice, brass core, brass strainer Specify sizes for orifice/core/strainer. Complete Spraying Systems selection. BR0505F BR0807 heavy spring BR0807H BR0209 BR0508 BR05042 BR0509 BR0503 BR0880 BR0506 BR0112...
  • Page 55 Pak-Blast 50 gallon universal joint disassembly Remove all (4) snap rings in cross assembly 1. Note: Yoke arms must be true. If a yoke arm is sprung by striking with excessive force, the cross will bind in operation. Position joint in loose vice 2. Strike top arm of unsupported yoke to drive the top cup up.
  • Page 56 Pak-Blast 50 gallon 800 346 7867 CHEMICAL CONTAINERS INC.
  • Page 57 4. The most recent four chemicals must be specifi- cally identified (ref. OSHA 1910.1200 (d)(e)(f)(g) (h)). Rears reserves the right to require submission of a Safety Data Sheet for any product Rears deems necessary. Rears reserves the right to refuse any equipment that does not meet the requirements for repair.

  • Page 58: Limited Warranty

    Rears does hereby warrant to the original purchaser of each product manufactured by Rears for a period of ninety (90) days from the date of purchase or five hundred (500) hours of operation, which-ever occurs first, that such product will be free from defects in material and workmanship under normal use with normal maintenance service.
