Kichler Lighting Showscape 12217 Instruction Sheet

Landscape low voltage transformer
Hide thumbs

Advertisement

Available languages

Available languages

Table of Contents

Kichler® is a registered trademark of
The L.D. Kichler Co. All Rights Reserved.
This instruction sheet covers the installation of the following Kichler® Transformers: 12217
200 WATT DIGITAL TRANSFORMER Input: 120VAC 60Hz 2A max. Output: 12VAC/15VAC 200VA max.
Read these instructions carefully before installing this unit. Save all safety warnings and instructions for
future reference.
• This device is only accepted for use as a component of a landscape lighting system where the suitability of
the combination shall be determined by National Electric Code or local authorities having jurisdiction.
• WARNING: Risk of electric shock, use only with low voltage landscape fixtures and accessories. DO not use
with swimming pool or spa lighting fixtures. Do not submerge transformer.
• Caution: Use only with maximum 180 watt, 180VA lamp load and a minimum 60 watt lamp load as speci-
fied below in Finding Transformer Load.
• Do not connect two or more power supplies in parallel.
• Do not touch the product. It may get hot during normal use.
• Suitable for indoor or outdoor use.
• WARNING: Risk of Fire. If installation involves running wiring through a building structure, special wiring
methods are needed. Consult a qualified electrician.
• Transformer should be mounted close to power source. Extension cords should not be used with this unit.
• WARNING: RISK OF ELECTRIC SHOCK. Install power unit 5 feet (1.525m) or more from any pool, spa, or
fountain.
(a) indoor within 10 feet (3.05m) of a pool, spa or fountain, or
(b) outdoor, connect power to unit to a receptacle protected by a GFCI.
• WARNING: Risk of Electric Shock. When used outdoors, install only to a 115/120 volt hood covered Class-A
GFCI protected receptacle, marked "Wet Location", that is weatherproof with the power unit connected to
the receptacle. If one is not provided, contact a qualified electrician for proper installation. Ensure that the
power unit and cord do not interfere with completely closing the receptacle cover.
• Mount the rain-tight transformer at least one 1ft (.305m) above ground level with the wire terminals facing
down. NOTE: Do not energize transformer until installation of system is complete.
• Direct burial rated wire is to be buried a maximum of 6" (152.4mm) beneath the surface of the ground.
• Risk of fire. Do not place insulation under terminal plate. Check connection after installation.
ATTACH YOUR RECEIPT HERE
Serial Number
Questions, problems, missing parts? Before returning to your retailer, call our customer
service department at 1-800-554-6504, 8 a.m. - 4:30 p.m, EST, Monday - Friday.
LANDSCAPE LOW VOLTAGE
Purchase Date
1
ITEM #0805278
TRANSFORMER
MODEL #12217
Español p. 13

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Showscape 12217 and is the answer not in the manual?

Questions and answers

Related Manuals for Kichler Lighting Showscape 12217

Summary of Contents for Kichler Lighting Showscape 12217

  • Page 1 ITEM #0805278 LANDSCAPE LOW VOLTAGE Kichler® is a registered trademark of TRANSFORMER The L.D. Kichler Co. All Rights Reserved. MODEL #12217 Español p. 13 This instruction sheet covers the installation of the following Kichler® Transformers: 12217 200 WATT DIGITAL TRANSFORMER Input: 120VAC 60Hz 2A max. Output: 12VAC/15VAC 200VA max. Read these instructions carefully before installing this unit.
  • Page 2 INSTALLATION INSTRUCTIONS 1) Finding Transformer Load: Low voltage systems require the use of a transformer to reduce standard 120-VOLT power from your home to 12-VOLTS. To determine the transformer size you will need: A) Total the wattage of all incandescent bulbs and multiply by 1.25 B) Total the wattage of all LED bulbs/fixtures, divide by .7 &...
  • Page 3 INSTALLATION INSTRUCTIONS 8) Determine the gauge of Low Voltage Landscape Lighting Cable and the Transformer Voltage Tap to use in order to avoid excessive voltage drop, which leads to dimming or non-functioning lights at the end of the wire. For optimum light output, the voltage at the lamp socket should range between 10.8 to 12 volts for incandescent fixtures.
  • Page 4 THE FOREGOING WARRANTY IS IN LIEU OF ALL OTHER WARRANTIES, EXPRESS OR IMPLIED, INCLUDING THOSE OF MERCHANTABILITY, FITNESS FOR ANY PARTICULAR PURPOSE OR INFRINGEMENT. ORIGINAL PURCHASER SHALL IN NO EVENT BE ENTITLED TO, AND KICHLER LIGHTING SHALL NOT BE LIABLE FOR, INDIRECT, SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES OF ANY NATURE, INCLUDING BUT NOT LIMITED TO LOSS OF PROFIT, PROMOTIONAL AND/OR MANUFACTURING EXPENSES, OVERHEAD, INJURY TO REPUTATION AND/OR LOSS OF CUSTOMERS.
  • Page 5 OPERATION LANDSCAPE LOW VOLTAGE TRANSFORMER Model# 12217 **READ FIRST** IMPORTANT GENERAL PROGRAMMING NOTES: Press the MENU button repeatedly for the green light to rotate around the digital display until the desired function to be programmed is lit and then press the ENTER button.
  • Page 6 OPERATION This transformer has 3 programming options to control the landscape lights on/off function. Please select one of the options below and skip to the instruction step as noted: n Setting the TIMER ON/OFF: transformer control to This setting allows you to control both the time the lights turn on and off. Skip to step AA for programming.
  • Page 7 OPERATION AA) Setting the TIMER ON/OFF: transformer control to This setting allows you to control both the time the lights turn on and off. a) Press MENU until the Green TIME ON/OFF LED indicator is lit and the digital display is flashing, then press ENTER. b) The digit display shows “...
  • Page 8 OPERATION BB) If Using the PHOTO EYE for transformer control, first install the PHOTO EYE Cable: Photo EYE Mounting Location Advice: Placing the sensor in areas receiving less sunlight at dusk (east side of house, behind trees and bushes, under a deck) will have the transformer come on earlier in the evening.
  • Page 9 OPERATION CC) Setting the transformer control to PHOTO EYE AUTO ON/OFF: This setting allows the PHOTO EYE to turn the lights on at dusk and off at dawn. No timer settings are used. a) Press MENU until the Green PHOTO EYE AUTO ON/OFF LED indicator is lit and the digital display is flashing, then press ENTER.
  • Page 10 OPERATION DD) Setting PHOTO EYE ON / TIMER the transformer control to OFF: This setting allows the PHOTO EYE to turn the lights on and you set the time they go off. a) Press MENU until the Green PHOTO EYE ON TIMER OFF LED indicator is lit, then press ENTER.
  • Page 11 OPERATION Manual ON/OFF Override: This setting allows you bypass all programming modes and manually turn the lights on and off. a) Press MENU until the Green MANUAL ON/OFF LED indicator is lit and then press ENTER. b) Press the UP arrow button to turn on the lights. Press the DOWN arrow button to turn off the lights.
  • Page 12 OPERATION Photo Eye TEST Function: This setting allows you to test your landscape lighting after installation and programming is completed: NOTE: When using the TEST function during daylight hours, be sure to completely cover the PHOTO EYE for the lights to turn on. The photo eye needs to sense darkness in order to function, even in TEST mode.
  • Page 13 ITEM #0805278 TRANSFORMADOR DE BAJO Kichler® es una marca registrada de The L.D. VOLTAJE PARA PAISAJISMO Kichler Co. Todos los derechos reservados. MODELO #12217 Esta ficha de instrucciones cubre la instalación de los siguientes transformadores Kichler®: 12217 TRANSFORMADOR DIGITAL DE 200 W Alimentación: 120VAC 60Hz 2A máximo. Salida:12VAC/15VAC 200VA máximo. Lea con cuidado estas instrucciones antes de instalar esta unidad.
  • Page 14 INSTRUCCIONES DE INSTALACIÓN 1) Identificación de la carga del transformador: Los sistemas de bajo voltaje requieren del uso de un transformador para reducir la alimentación eléctrica estándar de 120 voltios de su hogar a 12 voltios. Para determinar el tamaño de transformador que necesitará: A) Totalizar el vataje de todos los focos incandescentes y multiplicarlo por 1.25.
  • Page 15 INSTRUCCIONES DE INSTALACIÓN 8) Determine el calibre del cable para la iluminación de bajo voltaje para paisajismo y la toma de tensión del transfor- mador que se usará para evitar una caída excesiva del voltaje, que lleva a que las luces reduzcan su intensidad o no funcionen hacia el extremo final del cable.
  • Page 16 INCLUÍDAS AQUELLAS DE COMERCIABILIDAD, ADECUACIÓN PARA CUALQUIER PROPÓSITO PARTICULAR O INFRACCIÓN. EL COMPRADOR ORIGINAL EN NINGÚN CASO TENDRÁ DERECHO A, Y KICHLER LIGHTING NO SERÁ RESPONSABLE POR, DAÑOS INDIRECTOS, ESPECIALES, INCIDENTALES O CONSECUENTES DE CUALQUIER NATURALEZA, INCLUÍDOS SIN LIMITACIÓN, LA PÉRDIDA DE UTILIDADES, LOS GASTOS PROMOCIONALES O DE FABRICACIÓN, LOS GASTOS GENERALES, EL DAÑO A LA REPUTACIÓN...
  • Page 17 OPERACIÓN TRANSFORMADOR DE BAJO VOLTAJE PARA PAISAJISMO Modelo 12217 **LEER PRIMERO** IMPORTANTES NOTAS GENERALES DE PROGRAMACIÓN: Presione el botón MENU varias veces para que la luz verde gire alrededor de la pantalla digital hasta que la función que se desea programar se ilumine y después presione el botón ENTER.
  • Page 18 OPERACIÓN El ajuste del reloj ya está completo. La luz verde del reloj (CLOCK) y la hora actual con AM/PM permanecerán encendidas por un minuto antes de que la pantalla se ponga en blanco. Este transformador tiene 3 opciones de programación para controlar la función de encendido y apagado (ON/OFF) de las luces para paisajismo.
  • Page 19 OPERACIÓN AA) Ajuste del control del transformador a encendido y apagado del temporizador (TIMER ON/OFF): Este ajuste le permite controlar la hora en que las luces se encienden y se apagan. a) Presione MENÚ hasta que el indicador LED verde (TIMER) ON/OFF se ilumine y la pantalla digital esté...
  • Page 20 OPERACIÓN BB) Si se utiliza la FOTOCELDA para el control del transformador, primero instale el cable de la FOTOCELDA: Consejo de ubicación para el montaje de la Fotocelda: Si se coloca el sensor en áreas que reciben menos luz solar al atardecer (lado oriental de la vivienda, detrás de árboles y arbustos, bajo una terraza) el transformador se encenderá...
  • Page 21 OPERACIÓN CC) Ajuste del control del transformador a encendido y apagado automático de la fotocelda (PHOTO EYE AUTO ON/OFF): Este ajuste permite que la FOTOCELDA encienda las luces al anochecer y las apague al amanecer. No se utilizan ajustes del temporizador. a) Presione MENÚ...
  • Page 22 OPERACIÓN DD) Ajuste del control del transformador a encendido y apagado automático de la fotocelda (PHOTO EYE AUTO ON/OFF): Este ajuste permite que la FOTOCELDA encienda las luces y usted defina la hora en que se apagan. a) Presione MENU hasta que el indicador LED verde de encendido y apagado automático de la fotocelda (PHOTO EYE AUTO ON/OFF) se ilumine y después presione ENTER.
  • Page 23 OPERACIÓN Anulación temporal del encendido y apagado automático: Este ajuste le permite ignorar todos los modos de programación y encender y apagar manualmente las luces. a) Presione MENU hasta que el indicador LED verde de encendido y apagado manual (MANUAL ON/OFF) se ilumine y después presione ENTER. b) Presione el botón de la flecha hacia ARRIBA para encender las luces.
  • Page 24 OPERACIÓN Función de prueba (TEST) de la Fotocelda: Este ajuste le permite probar sus luces para paisajismo después de la instalación y de haber completado la programación. NOTA: Cuando use la función de prueba (TEST) durante las horas del día, asegúrese de cubrir por completo la FOTOCELDA para que las luces se enciendan.
