180Cc Tuff-Stack™ Repair Kit - Marco Graco XM70 20GXM3B00 Part Numbers And Schematics Manual

Tuff-Stack™ Repair Kit for 180cc Lower Displacement Pump
Item# Part#
Fig. 12
— 20G24F970
103 —
103a 20G244882
103b 20G244876
103e 20G244858
104 —
104a 20G244882
104b 20G244876
104e 20G244858
109 20G244892
112 20G253029
116 20G245128
117 20G244855
119 20G244996
— 20G247394
122 20G244895
123 20G238436
— 20G224458
— 20G238438
— 20G224459
125 20G262484
— 20G244896
127 20G244890
143 20G116801
159 20G262483
— 20G244895
— 209V021
Quantities listed with repair kit are number of individual pieces.
26
Graco XM70™ Plural Component Sprayer
®
PART NUMBERS AND SCHEMATICS GUIDE
Description
Tuff-Stack™ Repair Kit for 180cc Lower Displacement Pump
(Includes Item #'s: 103, 104, 109, 112, 116, 119, 122, 125, 127, 143, and 159)
Throat Packings
Male Gland (Quantity of Four)
Female Gland (Quantity of Four)
V-Packing Carbon-Filled, PTFE (Quantity of 10)
Piston Packings
Male Gland (Quantity of Four)
Female Gland (Quantity of Four)
V-Packing Carbon-Filled, PTFE (Quantity of 10)
PTFE O-Ring, Top Cylinder Medium (Quantity of 10)
Ball Piston, 3/4" (19 mm) (Quantity of Three)
Ball Inlet, 1-1/4" (32 mm) (Quantity of Three)
Shim Inlet, Ball Guide (Quantity of Nine)
Throat Seal Plug, 1-3/4" (Quantity of 10)
Throat Seal Plug, 2-1/2" (Quantity of 10)
Filter O-Ring, Thin, PTFE (Quantity of 10)
Strainer, 30 mesh screen, 5.65" (Quantity of 25)
Strainer, 30 mesh, 5.65" (Quantity of Two)
Strainer, 60 mesh, 5.65" (Quantity of 25)
Strainer, 60 mesh, 5.65" (Quantity of Two)
Filter O-Ring, Medium, PTFE (Quantity of 10)
Fitler O-Ring For Series A Pumps (Quantity of 10)
O-Ring, PTFE, Thin (Quantity of 10)
Foot Valve Spring
Top Cap O-Ring, PTFE (Quantity of 10)
Top Cap O-Ring For Series A Pumps (Quantity of 10)
Operator's Manual – Graco Xtreme Pump Lowers
® ®
