  • Page 2 VdS Zertifizierung n° G209195 Certificazione russa 01111 Russian certificate Russisches Zertifikat Prodotto secondo la norma di rispetto ambientale Manufactured in accordance with the regulations and 2002/96/CE respect for the environment as in Produktion im Einklang mit allen gültigen Umweltschutzbestimmungen SETRONIC Verona...
  • Page 3 ENGLISH MANUAL...

  • Page 5: Table Of Contents

    Typical of possible connections ..........83 BEAM DETECTOR ILIA MAINTENANCE AND CONTROL ADDITIONAL CONTROLS TROUBLE SHOOTING Mod. MII SETRONIC Verona rev. 01...
  • Page 6 HIGH SENSITIVITY LINEAR BEAM DETECTOR MODEL ERHS0712 SETRONIC Verona Mod. MII rev. 01...

  • Page 7: Basic Characteristics

    Power supply 24 V DC Ÿ It is available, on request, the Control unit model CSRLS in the DUST version, with special Ÿ thresholds applicable in critical environments characterised by high levels of dust, steam or other vapours Mod. MII SETRONIC Verona rev. 01...

  • Page 8: System Description

    ILIA with the Dust version controller is thus a highly reliable response to the needs of problematic environments with dust, steam, fumes or particular working processes where other technologies are unable to assure the required security and accurate and precise detection. SETRONIC Verona Mod. MII rev. 01...

  • Page 9: Working Principle

    Mod. MII SETRONIC Verona rev. 01...

  • Page 10: Calibration And Assembly Procedure

    Perform the calibration by the ground controller to follow the menu <Auto Adjust>. Now cover the Transmitter Unit or Receiver Unit with a card or opaque object. When you cover the Unit check that the yellow led remains continuously on. SETRONIC Verona Mod. MII rev. 01...

  • Page 11: Main Calibration Procedures

     to ‚ change the fire threshold value (the value of the highest ž disturbance value seen by Detec shall be less than the threshold setted); wait for 2 sec and press OK to confirm the setting. ž Mod. MII SETRONIC Verona rev. 01...

  • Page 12: Procedure For Further Adjustment

    5. Change the password for access to the menu press „ or ƒ until you get to <Change password; press OK; ž enter the new password, using the direction buttons „‚ƒ; ž press OK to confirm the setting. ž SETRONIC Verona Mod. MII rev. 01...

  • Page 13: Technical Features

    Stand By max 48 mA 1 DETECTOR CONNECTED Typical (alarm or fault relay active) max 50 mA Stand By max 261 mA 8 DETECTORS CONNECTED Typical (alarm or fault relay actives) max 270 mA Mod. MII SETRONIC Verona rev. 01...

  • Page 14: Setting Of Diaphragm

    Distance from 15 m up to 120 m Distance from 10 m up to 80 m POS 0 POS 1 POS 2 POS 3 POS 4 POS 5 90 100 110 120 130 140 150 160 170 180 190 200 metri SETRONIC Verona Mod. MII rev. 01...
  • Page 15 HIGH SENSITIVITY REFLECTION SYSTEM DETECTOR MODEL ERRHS0712 Mod. MII SETRONIC Verona rev. 01...

  • Page 16: Basic Characteristics

    Power supply 24 V DC Ÿ It is available, on request, the Control unit model CSRLS in the DUST version, with special Ÿ thresholds applicable in critical environments characterised by high levels of dust, steam or other vapours SETRONIC Verona Mod. MII rev. 01...

  • Page 17: System Description

    ILIA with the Dust version controller is thus a highly reliable response to the needs of problematic environments with dust, steam, fumes or particular working processes where other technologies are unable to assure the required security and accurate and precise detection. Mod. MII SETRONIC Verona rev. 01...

  • Page 18: Working Principle

    SETRONIC Verona Mod. MII rev. 01...

  • Page 19: Calibration And Assembly Procedure

    Perform the calibration by the ground controller to follow the menu <Auto Adjust.>. Now cover the Reflection Unit with a card or opaque object. When you cover the Reflection Unit check that the yellow led on the TRx Unit remains continuously on. Mod. MII SETRONIC Verona rev. 01...

  • Page 20: Main Calibration Procedures

     or ‚ to change the fire threshold value (the value of the highest ž disturbance value seen by Detec shall be less than the threshold setted); wait for 2 sec and press OK to confirm the setting. ž SETRONIC Verona Mod. MII rev. 01...

  • Page 21: Procedure For Further Adjustment

    5. Change the password for access to the menu: press „ or ƒ until you get to <Change password; press OK; ž enter the new password, using the direction buttons „‚ƒ; ž press OK to confirm the setting. ž Mod. MII SETRONIC Verona rev. 01...

  • Page 22: Technical Features

    Stand By max 42 mA 1 DETECTOR CONNECTED Typical (alarm or fault relay active) max 45 mA Stand By max 190 mA 8 DETECTORS CONNECTED Typical (alarm or fault relay actives) max 200 mA SETRONIC Verona Mod. MII rev. 01...

  • Page 23: Setting Of Diaphragm

    Distance from 15 m up to 65 m Distance from 10 m up to 50 m POS 0 POS 1 POS 2 POS 3 POS 4 POS 5 90 100 110 120 130 140 150 160 metri Mod. MII SETRONIC Verona rev. 01...
  • Page 24 CONTROLLER FOR BEAM DETECTOR MODEL CSRLS MODEL CSRLS - Dust SETRONIC Verona Mod. MII rev. 01...

  • Page 25: Display Message And Programming Step

    DISPLAY MESSAGE AND PROGRAMMING STEPS 1. Menu access protect by password SETRONIC Verona Main Screen Normal Operation Normal Operation PRESS OK Press the arrows „ ƒ and moving the blinking cursor by Insert password arrows  ‚ it is possible to change the default password that FFFF is FFFF.

  • Page 26: Modify Of Transmitter Level And Check Of The Signal Level Received

    3. Modify of Transmitter level and check of the signal level received If necessary, log on to the menu with password by following the steps in point 1 Insert password Insert password FFFF PRESS OK <sensibility> Menu access SETRONIC Verona Mod. MII rev. 01...

  • Page 27: Auto Calibration Of Transmitter Level

    Data not changed OK to exit At the end of operation PRESS OK 4. Auto calibration of Transmitter level PRESS OK Insert password as for step 1 Insert password FFFF PRESS OK Mod. MII SETRONIC Verona rev. 01...
  • Page 28 90%. This to avoid that the detector goes in over signal when the air come back to a clean condition. When the detector is up to 100%… PRESS OK Saving data... Wait for saving data SETRONIC Verona Mod. MII rev. 01...

  • Page 29: Alarm Auto Test

    PRESS OK Loading data Wait for the loading of the data from device:1 Press OK key Press OK to start the test and wait for the alarm signal to Test Alarm (LED Alarm lighted) Mod. MII SETRONIC Verona rev. 01...

  • Page 30: Alarm Reset

    If the Controller is equipped with Remote Reset Module (MRS), close the terminal blocks (+) and (-) by a clean contact for at least 3 seconds. 7. System Configuration PRESS OK Insert password Insert password as for step 1 FFFF PRESS OK SETRONIC Verona Mod. MII rev. 01...
  • Page 31 Press the arrows ‚ is possible to set up the serial line Com Error check as closed loop (Close) or Open Error, if the wish is to have two different stub lines with n detector connected (function available only with expansion card inserted). PRESS OK Mod. MII SETRONIC Verona rev. 01...

  • Page 32: Modify Of The Password For Menu Access

    Example with alarm on zone (detector) 1, 5 e 6 (the dash Alarm:1---56-- shows the zone out of the incoming event) Note: the Led ALARM is on and the output related to the zone(s) is activated SETRONIC Verona Mod. MII rev. 01...
  • Page 33 TRx. The message will be complete with the number of the corresponding detector. NOTICE: in all conditions above mentioned, in case of an alarm of one or more zone (detector), the first line of the display will always show the alarm condition. Mod. MII SETRONIC Verona rev. 01...

  • Page 34: Choose The Right Cable

    (i.e. switches from “open” to “closed”) min. line resistance at which the device reconnects RSCmin 35 Ω (i.e. switches from “open” to “closed”) max. leakage current with the switch open (isolated ILmax 140 mA state) SETRONIC Verona Mod. MII rev. 01...

  • Page 35: Socket Circuit With Protection

    SOCKET CIRCUIT WITH PROTECTION cod. SSMP-C SETRONIC VERONA - SSMP DIP-SWITCH FOR THE ADDRESS OF THE SMOKE BEAM DETECTORS DIP SWITCH ADDRESS ZONE 1 ZONE 2 ZONE 3 ZONE 4 ZONE 5 ZONE 6 ZONE 7 ZONE 8 SET OF DIP SWITCH 4 (END LINE) FOR END LINE RESISTOR...

  • Page 36: Typical Connection To A Conventional Control Panel With End Line Resistor

    TO THE CONTROL PANEL SETRONIC Verona Mod. MII rev. 01...

  • Page 37: Typical Connection To An Addresable Control Panel

    Mod. MII SETRONIC Verona rev. 01...

  • Page 38: Connection To Mrs Reset Module

    SETRONIC Verona Mod. MII rev. 01...

  • Page 39: Typical Of Possible Connections

    Mod. MII SETRONIC Verona rev. 01...
  • Page 40 Position DIP 4 at ON for the last base ETC. ETC. of both lines SETRONIC Verona Mod. MII rev. 01...
  • Page 41 Mod. MII SETRONIC Verona rev. 01...

  • Page 42: Beam Detector Ilia Maintenance And Control

    5. If the display shows "C-Err: 123 ..." (until the last of the detectors programmed) and "Fault: 123 ..." (until the last of the detectors programmed) even after waiting for 5 seconds, then there is a break in the supply line. 6. Reconnect the cables and make sure that the clamps are inserted securely. SETRONIC Verona Mod. MII rev. 01...

  • Page 43: Trouble Shooting

    ALARM AND TROUBLE In case of cabling of two stub lines verify Ø LEDs stay on after the that the second serial line (COM LINE2: switching off of the automatic ON) has been enabled. test lamp Mod. MII SETRONIC Verona rev. 01...
  • Page 44 In this case adjust the t r a n s m i t t e r b y m e a n s o f t h e <Adjustment> menu until you reach a reading of 100%. SETRONIC Verona Mod. MII rev. 01...
  • Page 45 If after the reset the signal is still present it means that the short circuit has not been solved. Mod. MII SETRONIC Verona rev. 01...
  • Page 46 You are advised that as Setronic Verona constantly strives to improve its products it reserves the right to make any changes it considers necessary without prior warning. The same reservation applies to any corrections of printing errors including of details and measurements that may have found their way into this booklet.
  • Page 47 Staffa regolabile per linea ILIA. Disponibile anche per linea ARDEA ed Argo. Adjustable Bracket for ILIA line. Available for Ardea and ARGO line too. Einstellbarer Montagebügel für die linie ILIA. Lieferbar auch für ARDEA und Argo. SAA-G Mod. MII SETRONIC Verona rev. 01...
