Skytrac DVI-300 Installation Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

DVI-300 INSTALLATION MANUAL
DOCUMENT REVISION: 01.004
(DOC0456)
Applies to: DVI-300 (105-300-01, 105-300-02, 105-300-03, 105-300-04)
Note: Access the latest revision at
Aug 21, 2015
SKYTRAC Systems Ltd.
Tel. +1 250 765-2393
Fax +1 250 765-3767
Web: www.skytrac.ca
Email:
support@skytrac.ca
UNCONTROLLED COPY IF PRINTED
www.skytrac.ca/support

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DVI-300 and is the answer not in the manual?

Questions and answers

Summary of Contents for Skytrac DVI-300

  • Page 1 DVI-300 INSTALLATION MANUAL DOCUMENT REVISION: 01.004 (DOC0456) Applies to: DVI-300 (105-300-01, 105-300-02, 105-300-03, 105-300-04) Note: Access the latest revision at www.skytrac.ca/support Aug 21, 2015 SKYTRAC Systems Ltd. Tel. +1 250 765-2393 Fax +1 250 765-3767 Web: www.skytrac.ca Email: support@skytrac.ca UNCONTROLLED COPY IF PRINTED...
  • Page 2 The DVI-300 is under warranty for one year from date of shipment from SKYTRAC Systems. For failed units caused by defective parts or workmanship, contact SKYTRAC Systems for an RMA #. SKYTRAC Systems will provide the return address to ship the equipment to at the time of issuing the RMA #.

  • Page 3: Table Of Contents

    Unpacking and Inspecting the System Components................17 3.5.1 Product Mounting .......................... 17 Installation Materials ..........................18 3.6.1 Installation Kit for the DVI-300, Installation Kit for the ISAT-200 ..........18 3.6.2 Wiring Harness ..........................18 ELECTRICAL INSTALLATION........................19 Document Rev. 01.004...
  • Page 4 DVI-300 Installation Manual General ..............................19 Line Functions ............................19 4.2.1 DVI-300 25 Pin Connector Pin-out....................19 4.2.2 DVI-300 pin DB-9 Connector Pin-Out................... 20 ISAT-200 System Installation Reference Drawings ................21 4.3.1 DVI-300 Installation Wiring Diagram Notes .................. 21 CONFIGURATION OF THE DVI-300 ......................
  • Page 5 TABLE 8 — ENVIRONMENTAL TESTING SUMMARY ..................14 TABLE 9 — COMPONENT WEIGHTS ......................17 TABLE 10 ---- DVI-300 25 PIN CONNECTOR PIN DESCRIPTIONS ..............19 TABLE 11 ---- DVI-300 9 PIN CONNECTOR PIN DESCRIPTIONS ..............20 TABLE 12 ---- VOLTAGE THRESHOLDS FOR DIM CONTROL INPUT ............22 TABLE 13 ---- EMERGENCY SWITCH OPERATION ..................
  • Page 6 DVI-300 Installation Manual LIST OF FIGURES FIGURE 1 — ISAT-200 SYSTEM BLOCK DIAGRAM ..................9 Document Rev. 01.004 DOC0456 Page 6 of 31 Restricted Proprietary and Confidential Information UNCONTROLLED COPY IF PRINTED...

  • Page 7: General

    CDP-300 provides an interface to read and send email messages, receive and answer SatPhone calls, and display ISAT-200 parameters. The DVI-300 along with the CDP-300 provides a rich interface for accessing the global voice and text communications features of the SKYTRAC System’s Iridium based ISAT-200. This combined interface is referred to as the CDU-300.

  • Page 8: Audience

    This section describes the steps required for the continued airworthiness of the DVI-300 system. Section 9 — Firmware Updates This section indicates the methods available to update the DVI-300 and where to find the required instructions. Section 10 — DVI-300 Human Machine Interface This section provides a brief description of the DVI-300 human machine interface components.

  • Page 9: System Components

    The ISAT-200 is the primary component of the ISAT-200 System. The ISAT-200 provides position reporting and messaging with global coverage in near real time. The DVI-300 is a user cockpit control head to the ISAT-200 system. Please refer to the ISAT-200 installation manual for more information regarding installation of the ISAT- 200.

  • Page 10: Dvi-300

    DVI-300 INSTALLATION COMPONENTS An installation kit is offered for the installation of the DVI-300. The contents of the Installation Kit can be found in the DVI-300 Installation Kit Bill of Materials. The installation kit contains the mating connector to the DVI-300 back shell and necessary hardware to attach it.

  • Page 11: Table 2- Dvi-300 Installation Kit

    NVIS A backlighting with push button emergency switch 101-200-01, 101-200-02 * Note – Please contact STS Client Services for software version requirements for peripherals if updating a peripheral from an ISAT-100 installation. Table 2– DVI-300 Installation Kit TYPE PART DESCRIPTION COMPATIBILITY...

  • Page 12: System Specifications

    DVI-300 Installation Manual 2 SYSTEM SPECIFICATIONS 2.1 GENERAL This section contains the specifications and a list of the physical and electrical requirements for the DVI-300. 2.2 POWER REQUIREMENTS FOR THE DVI-300 SYSTEM Table 3— Power Requirements COMPONENT POWER REQUIREMENTS DVI-300 Input Voltage: 20.5 to 32.2 Vdc, 27.5 Vdc nominal...

  • Page 13: Optical Specifications

    Weight 0.27kg (0.6 lbs) Mounting DZUS rails using 4 1/4 Turn Studs. 2.4.1 OPTICAL SPECIFICATIONS Table 6— DVI-300 Indicator Brightness Specifications Indicator Brightness Day Mode: 150 fl Minimum. Night Mode: (dimmable from Day Mode) Backlighting Brightness Day Mode: NA Night Mode: 1 fl +/- 0.5 fl (dimmable) Table 7—...

  • Page 14: Environmental Test Summary

    DVI-300 Installation Manual [(A1) (F1)]-CXB [(SBM) (UG)] XXXXXXZBBXXXMXXXXX The tests demonstrated that the DVI-300 does not exhibit any unsafe performance when exposed to the specified environmental test conditions, and that installation of the DVI-300 in accordance with the installation instructions in this manual will not pose a hazard to the continued safe flight and landing of the aircraft.
  • Page 15 DVI-300 Installation Manual 19.0 Induced Signal Susceptibility 20.0 RF Susceptibility 21.0 RF Emissions 22.0 Lightning Induced Transient Susceptibility 23.0 Lightning Direct Effects 24.0 Icing 25.0 Electrostatic Discharge 26.0 Fire, Flammability Document Rev. 01.004 DOC0456 Page 15 of 31 Restricted Proprietary and Confidential Information...

  • Page 16: Mechanical Installation

    The following installation regulations must be adhered to: When installing the DVI-300 the installer must have a working knowledge of aircraft electronics installation, and be a holder of either an FAA Repairman’s Certificate or a Transport Canada equivalent. All installations should meet the requirements of FAA advisory circular AC43.13-1B.

  • Page 17: Dvi-300 Component Weights

    3.5.1 PRODUCT MOUNTING To operate as part of the CDU-300, the DVI-300 has to be mounted right below CDP-300. If the DVI-300 is mounted already, disconnect the connector for DVI-300 and remove the DVI-300 from the aircraft DZUS rails. Place the CDP-300 over the DVI-300 and secure them together using CDU-300 Mounting Brackets on both sides.

  • Page 18: Installation Materials

    3.6.2 WIRING HARNESS Determine the location of the DVI-300 in order to determine wiring harness lengths. Create the wiring harness for your model of DVI-300 referencing applicable approved installation drawings for your airframe. Ensure the wiring harness complies with the requirements of FAA advisory circular AC43.13-1B.

  • Page 19: Electrical Installation

    System wiring diagrams with installation notes are also included. When installing the DVI-300, the installer must have a working knowledge of aircraft electronics installation and be a holder of either an FAA Repairman’s Certificate or a Transport Canada equivalent. All installations should meet the requirements of FAA advisory circular AC43.13-1B.

  • Page 20: Dvi-300 Pin Db-9 Connector Pin-Out

    Reserved for future use - Do not connect Reserved Reserved for future use - Do not connect 4.2.2 DVI-300 PIN DB-9 CONNECTOR PIN-OUT. Table 11---- DVI-300 9 Pin Connector Pin Descriptions PIN # PIN NAME FUNCTION/DESCRIPTION Do not connect Receive Data Transmit Data Document Rev.

  • Page 21: Isat-200 System Installation Reference Drawings

    4.3.1 DVI-300 INSTALLATION WIRING DIAGRAM NOTES The following notes pertain, in general, to the DVI-300 Installation Wiring Diagram Illustrations. All signal and power shield continuity must be individually maintained through bulkhead disconnects. Please refer to the ISAT-200 System Installation Reference Drawings or STC drawings for additional installation notes.

  • Page 22: Configuration Of The Dvi-300

    300 uses a hysteresis window to switch between these two modes. If the DVI-300 is in bright mode, it will switch to dim mode only when the voltage increases above the dim mode threshold. If the DVI-300 is in dim mode, it will switch to bright mode only when the voltage falls below the bright mode threshold.
  • Page 23 The indicators are turned ON to full brightness in bright (day) mode. In dim (night) mode, the indicators brightness is set to medium level of brightness. At any time, the brightness of the indicators can be controlled manually using the keypad function key as indicated in the DVI-300 User’s Guide (DOC0499). 5.1.1.2 BACKLIGHTING The backlighting is ON in bright (day) mode.

  • Page 24: Post Installation Tests

     Use the DVI-300 to place a sat phone call to a ground based telephone. Confirm that the call is established and both parties can hear each other clearly. Adjust the system volume if necessary. To make calls using the DVI-300, voice communication must be enabled in the ISAT.

  • Page 25: Emi Test

    Test Template (DOC0478) for EMI test procedures. The purpose of this test report is to verify that the operation of the DVI-300 does not interfere with basic aircraft systems and avionics. Since the DVI-300 cannot operate without an ISAT-200, the DVI-300 and ISAT-200 should be installed and function tested.
  • Page 26 DVI-300 Installation Manual Operate the DVI-300 unit for at least 10 minutes. During this time use the keypad on the DVI-300 to send several text messages. These operations will exercise the ISAT-200 to DVI-300 communications link. Because the DVI-300 only instructs the ISAT to place a phone call, it is not necessary to place test phone calls when testing the DVI-300.

  • Page 27: Airworthiness Limitations

    DVI-300 Installation Manual 7 AIRWORTHINESS LIMITATIONS 7.1 INSTALLATION LIMITATIONS No Limitation on installation is identified. 7.2 OPERATION LIMITATIONS No Limitation on installation is identified. Document Rev. 01.004 DOC0456 Page 27 of 31 Restricted Proprietary and Confidential Information UNCONTROLLED COPY IF PRINTED...

  • Page 28: Maintenance And Continued Airworthiness

    LEDs. If an LED is non-functioning, have the DVI-300 replaced by an authorized technician. 8.2 MAINTENANCE INSTRUCTIONS With the exception of the lighting as explained in Section 8.1 above, the DVI-300 does not require any maintenance. Document Rev. 01.004...

  • Page 29: Firmware Updates

    DVI-300 Installation Manual 9 FIRMWARE UPDATES The DVI-300 is equipped with a serial port to enable firmware updates to the device. Detailed instructions on how to update the firmware are included in the DVI-300 User's Guide. Refer to SKYTRAC’s website at www.skytrac.ca...

  • Page 30: Dvi-300 Human Machine Interface

    DVI-300 User's Guide. 10.2 KEYPAD The DVI-300 has a thirteen button keypad which is used for dialling numbers and when used as part of a CDU- 300 composing messages. 10.3 ANNUNCIATORS Two annunciators on the panel indicate a variety of conditions.
  • Page 31 STATEMENT OF CONFIDENTIALITY The information in this document is the property of SKYTRAC System Ltd. hereafter referred to as SKYTRAC. SKYTRAC submits this document with the understanding that it will be held in strictest confidence and will not be disclosed, duplicated or used, in whole or in part, for any purpose other than the evaluation of the qualifications of SKYTRAC, without prior written consent.

This manual is also suitable for:

105-300-01105-300-02105-300-03105-300-04
