Lorex LHB900 Series Quick Reference Manual

HD Wire-Free Security System
2 / 2
English Version 6.0
Before You Start
• Upgrade your DVR firmware and mobile app to the latest versions.
• Please note that an upload speed of 3 Mbps is required for remote video
streaming. Up to 3 devices may connect to the system at the same time.
• Ensure you have completed initial setup of the Lorex Secure app and the
DVR as detailed in the Quick Connection Guide.

Lorex Cirrus: App Overview

Main menu
Date and time
stamp
Wireless signal
strength indicator
Save a snapshot
of the current live
view
Tap to start manual
recording; tap again
to stop
Tap to switch to full HD video
quality; tap again for reduced
video quality that is optimized
Quick Reference Guide
www.lorex.com
Cast to your
Configure settings for
monitor
selected channels
Select channels for
live viewing from all
connected devices
Battery strength
indicator
Device - Channel name
Split-screen options
Tap to enable the
camera's intercom; tap
again to stop
Tap to switch between
muted and unmuted
for streaming

Lorex Cirrus: Playback

Play back recorded video using the Lorex Cirrus app.
To play back recorded video:
1. Launch the Lorex Cirrus app.
2. Tap , then tap Playback.
3. Set search options for playback:
a. Tap a recorder to reveal available
channels.
b. Tap channels to include in search.
c. Tap a date from the calendar to
seach for recordings from. Dates with
recordings available are marked with a
red dot.
NOTE: Tap to filter recordings by type
and resolution.
4. Tap Play to begin playback.

Playback Controls:

You can use playback mode in portrait or landscape mode. Landscape mode
shown below:
Playback 03/11/2020
date
Video
playback
Slower Play / Pause Faster Next Frame

Lorex Cirrus: Camera Settings

Change camera settings using the Lorex Cirrus app.
To change camera settings:
1. Launch the Lorex Cirrus app.
2. Tap a channel in Live View to select it.
3. Tap to open settings for the selected
channel.
4. Configure the following as needed:
a. Channel Name: Enter a name of your choice
for the channel (e.g., Porch Camera).
b. Record Length: Set the recording length
when motion is detected.
c. Video Resolution: Set 720p or 1080p
recording.
5. Tap SAVE to save settings.

Lorex Cirrus: Device Settings

Change recorder name and format storage using the Lorex Cirrus app.
To change device settings:
1. Launch the Lorex Cirrus app.
2. Tap a channel on the device you want to
edit from Live View.
3. Tap , then tap Settings.
4. Configure the following as needed:
a. Device Name: Enter a name of your choice
for the recorder (e.g., Wire-Free System).
b. Format: Tap to select a storage device
(hard drive or microSD card) to format. Tap
Format to confirm the selected device and
begin formatting.
IMPORTANT: Formatting a storage device
will erase all recordings and snapshots.
This step cannot be undone.
NOTE: Only the admin user can format
memory.
5. Tap Save to save settings.
c
a
b
Playback time
Video timeline.
Tap to start
playback from
the selected
time. Pinch or
spread fingers
to change the
time period.
Stop Snapshot Manual Mute / Unmute
Recording
a
b
c
a
b
LHB900_QRG_EN_R6
