The Pulsed operation setting allows an output to activate as long as the button is held.
The Timed operation setting allows an output to activate when the transmitter button is pressed, and remain
activated for 10 seconds or until the transmitter button is pressed again.
The Latched operation setting allows an output to activate when the transmitter button is pressed, and remain
activated until the transmitter button is pressed again.
DISARM WITH AUXILIARY FUNCTION
If auxiliary 1 is installed to activate the vehicle's trunk release, the system can be programmed to automatically disarm
the alarm when the trunk is opened using the transmitter. In this manner, the trunk can be accessed without first
disarming the alarm.
REMOTE SENSOR DISABLE
When parking the vehicle in areas susceptible to unwanted disturbance from animals or strong weather conditions that
could cause the sensors to trigger, the sensor inputs can be temporarily bypassed using the remote transmitter,
preventing possible false alarms.
To disable the sensor inputs.
1. Arm the system normally.
2. Within 5 seconds of arming the system, press the arm button again.
• The siren will chirp 5 times and the parking lights will flash 5 times to indicate the sensors are disabled.
• The sensors will remain disabled until the next arming cycle.
E L E C T R O N I C S
Page 8
Copyright 2003 All Rights Reserved
I N C .
In House/Instructions/Manuals/AS635/805 Owner's Manual.cdr
SECURITY SYSTEM
WITH STARTER
AS635/805
OWNER'S MANUAL
Advertisement
Table of Contents
Summary of Contents for Accele AS635/805
- Page 1 • The siren will chirp 5 times and the parking lights will flash 5 times to indicate the sensors are disabled. • The sensors will remain disabled until the next arming cycle. OWNER’S MANUAL E L E C T R O N I C S I N C . Page 8 Copyright 2003 All Rights Reserved In House/Instructions/Manuals/AS635/805 Owner’s Manual.cdr...
- Page 2 • The LED will emit double flashes. To ensure the safety and security of the system while it is remote started, the AS635/805 employs several 3. Release the brake pedal. safeguards. In the event the alarm is triggered while the engine is remotely running, the remote start will immediately shutdown to prevent unauthorized users from attempting to drive the vehicle.
- Page 3 The Automatic Rearming feature is designed to protect the vehicle in the event the system is accidentally disarmed. With the If two vehicles are equipped with AS635/805 systems, for convenience, both can be operated using the Automatic Rearming feature enabled, the alarm will automatically re-arm 30 seconds after disarming. If the optional Passive Door same remote transmitter.
- Page 4 SILENT ARMING/DISARMING SYSTEM OPERATION The AS635/805 system can be programmed to operate without Arm and Disarm chirp indications. When programmed REMOTE ARMING for full-time silent operation, the siren will sound only when the system is triggered. The system is also capable of The system monitors 6 independent areas (zones) while armed: doors, hood/trunk, shock sensor and optional temporary silent operation if desired.
