Summary of Contents for Rosewill NEON K90 RGB

  • Page 1 User Manual MECHANICAL GAMING KEYBOARD...
  • Page 2: Package Contents

    NEON K90 RGB Mechanical Gaming Keyboard User Manual INTRODUCTION Congratulations on your purchase of the NEON K90 RGB mechanical gaming keyboard. Its clean design imbued with durable mechanical switch technology will satisfy your typing and gaming needs. Featuring personalization of your keyboard with customizable keys and backlighting.
  • Page 3: Specifications

    • Dedicated Backlight Controls • N-Key Rollover • Detachable Magnetic Wrist Rest • Software Suite for Customization Settings SOFTWARE INSTALLATION 1. Go to www.rosewill.com/downloads 2. Search for “NEON K90 RGB” 3. Double-click “NEON K90 Engine Suite.exe” to start the software installation program...
  • Page 4: Keyboard Controls

    NEON K90 RGB Mechanical Gaming Keyboard User Manual KEYBOARD CONTROLS 1. DEDICATED MEDIA KEYS Default Media Previous Track Player Play/Pause Next Track Stop Default: Volume Control Press Once to Control Backlight Brightness Lock / Unlock Windows N-Key Rollover / 6-Key Rollover...
  • Page 5 NEON K90 RGB Mechanical Gaming Keyboard User Manual 2. DEDICATED BACKLIGHT CONTROLS Increase Backlight Brightness (Level 0-12) Decrease Backlight Brightness (Level 0-12) Increase Backlight Speed (Level 1-8) Decrease Backlight Speed (Level 1-8) Turn On/Off Backlight Note: The indicator will flash twice once adjustment reaches its limit.
  • Page 6: Backlight Mode

    NEON K90 RGB Mechanical Gaming Keyboard User Manual BACKLIGHT MODE NEON K90 RGB backlight effects and colors can be controlled directly on keyboard or via software suite. Modes that are set via software will always take priority and override direct keyboard settings.
  • Page 7 NEON K90 RGB Mechanical Gaming Keyboard User Manual Repeat to select preferred Full Backlight effect: Streamer, Rain, Mode Horse Race Lamp, (4 Effects) Twinkling Star Cycle through 10 preset Static Mode static colors. BACKLIGHT COLOR ADJUSTMENT Set 1 of 10 preset colors...
  • Page 8 NEON K90 RGB Mechanical Gaming Keyboard User Manual KEYBOARD SOFTWARE SUITE INSTRUCTIONS SOFTWARE SUITE OPERATIONS CUSTOMIZE: Redefine keys and button functions. MACROS: Easily record scripts of key presses. LIGHTING: Customize backlight effects and colors.
  • Page 9 NEON K90 RGB Mechanical Gaming Keyboard User Manual ACTIVE PROFILES MANAGEMENT Create up to 8 profiles of custom key assignments and backlighting. Save, edit and load your favorite profile instantly, from P1 to P8. PROFILE EDITOR LINKED PROGRAM: Set up profiles with specific key assignments that are only activated with dedicated programs or games.
  • Page 10: Key Assignment

    NEON K90 RGB Mechanical Gaming Keyboard User Manual KEY ASSIGNMENT KEY ASSIGNMENT: Select dedicated keys and customize their function.
  • Page 11 NEON K90 RGB Mechanical Gaming Keyboard User Manual Set up the shortcut to launch a specific program or website.
  • Page 12 NEON K90 RGB Mechanical Gaming Keyboard User Manual MACRO MANAGEMENT 1. Manage Macros and select one you would like to record. 2. You can select the required delay mode before recording. 3. Start recording. 4. Edit the delay time or key functions if necessary.
  • Page 13 NEON K90 RGB Mechanical Gaming Keyboard User Manual...
  • Page 14: Active Profile

    NEON K90 RGB Mechanical Gaming Keyboard User Manual LIGHTING 1. ACTIVE PROFILE: 1.1 Backlights can be turned off when the screen enters Sleep mode. 2. EFFECT: 2.1 Select the backlight effect from dropdown list. 2.2 Each backlight’s brightness and speed can be customized.
  • Page 15: Custom Effects

    NEON K90 RGB Mechanical Gaming Keyboard User Manual CUSTOM EFFECTS 1. There are 8 preset game modes 2. You can also customize the color for specific keys and set as a new template.
  • Page 16 Thank you for purchasing a quality Rosewill product. Please register your product at www.rosewill.com for complete warranty information and support for your product. Technical Support Information techsupport@rosewill.com • 1-800-575-9885 NEON K90 RGB Series_A...
