Porsche PCM5.0 THC3 Manual

Porsche PCM5.0 THC3 Manual

Porsche 2019 cayenne 12", volkswagen 2019 touareg 15" video interface
Hide thumbs

Advertisement

Quick Links

Download this manual
PORSCHE PCM5.0 THC3
- Porsche 2019 Cayenne 12"
- Volkswagen 2019 Touareg 15"
- MODEL : PCM-50-190219
- DATE : 2019.04.03
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the PCM5.0 THC3 and is the answer not in the manual?

Questions and answers

Related Manuals for Porsche PCM5.0 THC3

Summary of Contents for Porsche PCM5.0 THC3

  • Page 1 PORSCHE PCM5.0 THC3 - Porsche 2019 Cayenne 12” - Volkswagen 2019 Touareg 15” - MODEL : PCM-50-190219 - DATE : 2019.04.03...
  • Page 2 Index 1. Main Spec 2. Block Diagram 3. Dimension 4. External Appearance 5. Connector Pin Assignment 6. Product Composition 7. DIP S/W Setting 8. Mode Change 9. Touch Control 10. OSD(On Screen Display) Control 11. Install Manual 12. Q & A...
  • Page 3 1. Main Spec. 1. Input Spec. (MULTI VIDEO INTERFACE) - 1 x HDMI Input - 1 x Analog RGB Input (Navigation System output) - 2 x A/V Input (External video source) - 1 x CVBS(REAR CAMERA) Input. (Rear camera source) - 1 x CVBS(FRONT CAMERA) Input.

  • Page 4: Block Diagram

    2. Block Diagram INTERFACE COMMAND EEPROM SYSTEM RECEIVER LVDS LVDS TFT-LCD LVDS Scaler LVDS RELAY HDMI HDMI (PIP) RGB+Sync FRONT CAMERA REAR CAMERA REAR CAMERA POWER...
  • Page 5 3. Dimension 156mm * 93mm * 22mm 156mm 22mm 93mm * This can change under manufacturer’s circumstance...

  • Page 6: External Appearance

    4. External Appearance LCD-IN LCD-OUT DIP S/W PROGRAM IMAGE R-TOUCH NAVI POWER/CAN HDMI...
  • Page 7 4. External Appearance LCD-OUT LCD-IN PROGRAM DIP S/W IMAGE R-TOUCH NAVI POWER/CAN HDMI...

  • Page 8: Connector Pin Assignment

    5. Connector Pin Assignment *POWER Connect *Touch Connect *NAVI Connect ① ② ③ ④ ① ② ③ ④ ⑤ ⑥ ⑦ ① Y- ① R DATA (Red) 1. ACC (Red) 9. CAN-L (Green) ② X- ② G DATA (Green) 2. N.C 10.

  • Page 9: Product Composition

    6. Product Composition RGB Navi Cable(7pin) 1 EA LVDS Cable 1 EA Interface 1 EA A/V Cable(20-pin) 1 EA OSD Board 1 EA Power Cable(7pin) 1 EA Touch Cable(KD-900) 1 EA...

  • Page 10: Dip S/W Setting

    * ON : DOWN , OFF : UP * DIP S/W Example FUNCTION DIP S/W Selection ON : Not Used NAVI Porsche 2019 Cayenne 12” OFF : Used ON : Not Used DVB-T(AV1) OFF : Used Volkswagen 2019 Touareg 15”...
  • Page 11 8. Mode Change Control Porsche 2019 Cayenne 12” • DIP-SW 1 must be OFF in order to install Navigation Return OEM dispaly mode change • Short press the NAV button to switch screens. • Long press(1 second) the NAV button to switch screens.
  • Page 12 8. Mode Change Control Volkswagen 2019 Touareg 12” • DIP-SW 1 must be OFF in order to install Navigation - Switch mode by pressing for 1 seconds - Short press to switch OEM...

  • Page 13: Touch Control

    9. Touch Control DVB-T/DVD Control DVB-T Press Touch(Anywhere) Press Icon...
  • Page 14 10. OSD(On Screen Display) Control OSD Control Board MENU When there is no OSD screen, pressing OSD ON When OSD screen is displayed, press OSD EXITT Item Selection, Value Selection MENU DOWN Item up Increase selected value DOWN Item down Decrease selected value Mode State First Menu...
  • Page 15 10. OSD(On Screen Display) Control OSD Config First Menu Second Menu Third Menu Description DIGTAL-INAVI NAVI-RGB Setting the Connected NAVI Model ELT_DVBT20 DVB-T(DMB) Setting the Connected DVB-T Model Config ELT_980XU Slim Setting the Connected DVD Model Reset Execute Reset to default value of Config menu...
  • Page 16 10. OSD(On Screen Display) Control OSD Option First Third Second Menu Description Menu Menu Disable feature Set up manufacturer of NAVI COM NV17 woodworking device for UART Touch use Original Camera RearCam-Type Equipped with external ExtDevice camera + 12V continuous supply + 12V supply only in Rear RearCam-Power AUTO...
  • Page 17 10. OSD(On Screen Display) Control OSD Option First Third Second Menu Description Menu Menu Detected by CAN FrontCam-Det WIRE Detected by Front-Det Wire After RearCam shows FrontCam and returns to FrontCam-RcvOpt previous state Disable feature DVB-T device control UI output function UI DVB-T (DMB) Disable feature Option...
  • Page 18 10. OSD(On Screen Display) Control OSD Option -> FrontCam-RcvOpt Front Camera Auto Mode 0 second = FrontCam-RcvOpt menu OFF 1~30 second = FrontCam-RcvOpt menu ON & time control NAVI NAVI REAR FRONT AV1(DVB-T) AV1(DVB-T) AV2(DVD) AV2(DVD) Select time of display 1~30 second...
  • Page 19 10. OSD(On Screen Display) Control OSD Image NAVI-RGB menu DVD,DVB-T(DMB),NAVI-AV,REAR,FRONT menu First Menu Second Menu Third Menu Action First Menu Second Menu Third Menu Action Brightness Adjust the value of brightness Brightness Adjust the value of brightness Contrast Adjust the value of contrast Contrast Adjust the value of contrast Color-RED...
  • Page 20 10. OSD(On Screen Display) Control OSD – Screen Menu First Third Second Menu Description Menu Menu Output screen horizontal Horizontal movement Output screen vertical Vertical movement Scale X Up Reduce / increase output screen width Screen Scale X Down Scale Y Up Reduce / Increase Output Screen Height Scale Y Down...
  • Page 21 10. OSD(On Screen Display) Control OSD – OSD Menu First Third Second Menu Description Menu Menu Horizontal value OSD Menu Horizontal Shift Vertical value OSD menu vertical Shift OSD Menu Display Time (in value Display Time seconds) value Transparency OSD menu transparency Language OSD menu display language Reset...
  • Page 22 10. OSD(On Screen Display) Control * IR learning function * In order to work with the IR learning function, a separate IR cable is required. 1. In DVB-T / DVD menu, select User in Sys (OSD list) or User (learned contents). 2.
  • Page 23 10. OSD(On Screen Display) Control OSD – Utility Menu First Third Second Menu Description Menu Menu Factory Reset Execute Initialize all settings Utility FDSYOOKRX-180209 Version (Check for future upgrades) Last Source : FDSYOOKRX-180209 Software Version Software Month Software Year Special Version National : CN=CHINA, KR=KOREA, JP=JAPAN, US=United States Hardware Version PIP model : S3=Sync3, PP=PIP, LV=LVDS...
  • Page 24 11. Install Manual 1. Installation Navigation Connection *KD-900 navigation DVD IR DVB-T IR SYNC BLUE Analog RGB GREEN Resistive Touch KD-900...
  • Page 25 11. Install Manual 2. Installation AV1/DVB-T/DMB Remote Control Connection ① or ② DVD IR DVB-T IR 선택1 SYNC BLUE ① GREEN GEX-909DTV DVB-T-IR ② 선택2 TUE-T440...
  • Page 26 11. Install Manual 3. Installation AV2/DVD Remote Control Connection DVD IR DVB-T IR SYNC BLUE GREEN DVD-IR DHA-S690...
  • Page 27 11. Install Manual 4. Installation External Reverse(Rear) Camera Connection : OSD Screen selection CAN REAR-POWER (Red) 16. N.C 15. GND (Black) 14. Mode (Green) 13. Front-Power (Red) 12. Rear-Power (Red) 11. N.C 10. CAN-H (Orange) 9. CAN-L (Green) 8. CAN-H (Red) 7.
  • Page 28 11. Install Manual 5. Installation External Front Camera Connection 16. N.C FRONT-POWER (Red) 15. GND (Black) 14. Mode (Green) 13. Front-Power (Red) 12. Rear-Power (Red) 11. N.C 10. CAN-H (Orange) 9. CAN-L (Green) 8. CAN-H (Red) 7. CAN-L (Blue) 6. CAN-H (Purple) 5.
  • Page 29 11. Install Manual 6. Installation LVDS connection Screen head unit (commander)
  • Page 30 11. Install Manual 7. Installation CAN connection Remove the original gray connector. Attach the connector carefully to the locking part.
  • Page 31 12. Q & A 1. Not possible to switch mode - Check connection of OSD Key pad wire - Check CAN connection 2. Display wrong size of picture - Check Dip s/w setting 3. Display black screen in OEM mode - Check connection of LVDS/LCD cable 4.
