Summary of Contents for Ag Leader Technology Raven Accu-Flow ISO Kit
Page 1
DirectCommand Ag Leader Technology Installation Raven Accu-Flow ISO Kit Note: Indented items indicate parts included in an assembly listed above Part Name/Description Part Number Quantity Raven Accu-Flow ISO Kit 4200140 GEN 2 Large Module Mounting Kit 2001370 Deutsch Dust Plug – 12 Pin 2002899-12N Installation Instructions –...
Important by closely following these step-by-step instructions. If you have Notices questions, call Ag Leader Technology at 515-232-5363 ext. 1. Direction words (LEFT and RIGHT) are commonly used when describing an installation procedure. Interpret direction words as if standing behind equipment and looking forward.
DirectCommand Ag Leader Technology Installation Raven Accu-Flow ISO Kit This section contains illustrations of components common to all Common DirectCommand installations. Their purpose is to ensure proper Components identification and installation in the sections that follow. ISO Liquid Module ISO Swath Module PN: 2006375 Rev.
DirectCommand Ag Leader Technology Installation Raven Accu-Flow ISO Kit CAUTION: Implement should be lowered to ground or on Safety mechanical safety stops before starting work. Do not work on Notices implement supported by hydraulic system only. CAUTION: Be sure to wear proper eye protection when using any power tools, such as when drilling any mounting holes.
Ag Leader Technology DirectCommand Installation Raven Accu-Flow ISO Kit Parts required for procedure: Installing From DirectCommand Kit: the Liquid (1) Large Module Mounting Kit PN: 2001370 Product (1) ISOBUS Breakout Cable PN: 4002597-008 (1) Liquid Rate Control Module...
Page 7
DirectCommand Ag Leader Technology Installation Raven Accu-Flow ISO Kit 5. Plug the 24-pin FCI connector of the ISOBUS Breakout Cable, PN: 4002597-008 to the mating connector of the Liquid Rate Control Module. 6. Connect the 6-pin Metripack plug of the ISOBUS Implement Cable PN: 4004110-12 to the 6-pin Metripack receptacle of the ISOBUS Breakout Cable.
Ag Leader Technology DirectCommand Installation Raven Accu-Flow ISO Kit Parts required for procedure: Installing From DirectCommand Kit: the Accu- (1) Flow Control Channel Cable PN: 4003970-6 Flow (1) Dust Plug – 12 pin PN: 2002899-12N Cabling Optional Cables From DirectCommand Kit ...
Page 9
DirectCommand Ag Leader Technology Installation Raven Accu-Flow ISO Kit Connect the 2-pin plug of the Flow Control Channel Cable to the mating receptacle on the Liquid Rate Control Module. Note: Steps 7-10 are for toolbars that utilize a Main On/Off Valve and Auxiliary Valve.
These manufacturer's instructions must be followed to ensure even product distribution across the width of the toolbar. Ag Leader Technology is not responsible for application errors resulting from improper component design, selection, or assembly.
Page 11
DirectCommand Ag Leader Technology Installation Raven Accu-Flow ISO Kit 4. Connect the Local CAN Terminating Plug, PN: 4002870 to the mating receptacle of the ISOBUS Breakout Cable. 5. Connect the 6-pin Deutsch plug of the ISOBUS Breakout Cable to the mating receptacle of the Local CAN Breakout Cable.
Ag Leader Technology DirectCommand Installation Raven Accu-Flow ISO Kit Parts required for procedure: Installing an (1) Implement Switch PN: 4001507 Implement (1) Implement Switch Ext. Cable Switch See Table B (Optional) (1) CAN Implement Switch Cable PN: 4002658 ...
Page 13
DirectCommand Ag Leader Technology Installation Raven Accu-Flow ISO Kit Weatherpack Tower of the Implement Switch Extension Cable, PN: 2000453-X. Begin routing the Extension Cable towards the CAN Implement Switch Module avoiding pinch points, sharp edges and allowing extra slack. For a centered orientation plug the 3-pin Weatherpack Shroud labeled...
Ag Leader Technology DirectCommand Installation Raven Accu-Flow ISO Kit Refer to the Quick Reference Guide, PN: 2006010-ENG, for further Setting Up instructions on setting up the Display. the Display The following table describes each of the settings required to create a configuration.
Page 15
DirectCommand Ag Leader Technology Installation Raven Accu-Flow ISO Kit SERVO VALVE CONTROL SETTINGS Control Valve Valve Valve Response Flow Control Valve Configuration Response 1 Response 2 Threshold Raven Accu-Flow 20 gpm, Single Valve System Inline Servo (FAST VALVE) Raven Accu-Flow...
