Modbus / CAN – Datalogger

(Order Code: HD67324-B2-E-232-4GB, HD67324-B2-E-485-4GB,

HD67324-B2-E-CAN-4GB)

for Website information:

www.adfweb.com?Product=HD67324

for Price information:

www.adfweb.com?Price=HD67324-B2-E-232-4GB

www.adfweb.com?Price=HD67324-B2-E-485-4GB

www.adfweb.com?Price=HD67324-B2-E-CAN-4GB

Benefits and Main Features:

Very easy to configure

Electrical isolation

Temperature range: -40°C/85°C (-40°F/185°F)

User Manual

ADFweb.com Srl – IT31010 – Mareno – Treviso

User Manual Modbus / CAN - Datalogger

Document code: MN67324_ENG

Revision 1.200

For other M-Bus products:

Need help?

Do you have a question about the HD67324-B2-E-232-4GB and is the answer not in the manual?

Questions and answers

Summary of Contents for ADF Web HD67324-B2-E-232-4GB

Page 1 Revision 1.200 Page 1 of 44 Industrial Electronic Devices User Manual Revision 1.200 English Modbus / CAN – Datalogger (Order Code: HD67324-B2-E-232-4GB, HD67324-B2-E-485-4GB, HD67324-B2-E-CAN-4GB) for Website information: For other M-Bus products: www.adfweb.com?Product=HD67324 See also the following link: Converter M-Bus to www.adfweb.com?Product=HD67021...
Page 2: Table Of Contents
User Manual Modbus / CAN - Datalogger Document code: MN67324_ENG Revision 1.200 Page 2 of 44 Industrial Electronic Devices INDEX: UPDATED DOCUMENTATION: Dear customer, we thank you for your attention and we remind you that you Page need to check that the following document is: INDEX Updated UPDATED DOCUMENTATION...
Page 3: Security Alert
User Manual Modbus / CAN - Datalogger Document code: MN67324_ENG Revision 1.200 Page 3 of 44 Industrial Electronic Devices SECURITY ALERT: ENERAL NFORMATION To ensure safe operation, the device must be operated according to the instructions in the manual. When using the device, legal and safety regulation are required for each individual application.
Page 4: Connection Scheme
User Manual Modbus / CAN - Datalogger Document code: MN67324_ENG Revision 1.200 Page 4 of 44 Industrial Electronic Devices CONNECTION SCHEME: Figure 1a: Connection scheme for HD67324-B2-E-232-xGB ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com Phone +39.0438.30.91.31...
Page 5 User Manual Modbus / CAN - Datalogger Document code: MN67324_ENG Revision 1.200 Page 5 of 44 Industrial Electronic Devices Figure 1b: Connection scheme for HD67324-B2-E-485-xGB ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com Phone +39.0438.30.91.31...
Page 6 User Manual Modbus / CAN - Datalogger Document code: MN67324_ENG Revision 1.200 Page 6 of 44 Industrial Electronic Devices Figure 1b: Connection scheme for HD67324-B2-E-CAN-xGB ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com Phone +39.0438.30.91.31...
Page 7: Configuration
User Manual Modbus / CAN - Datalogger Document code: MN67324_ENG Revision 1.200 Page 7 of 44 Industrial Electronic Devices CHARACTERISTICS: The HD67324 is a Modbus / CAN Datalogger. It has the following characteristics: Electrical isolation for bus (RS232, RS485, CAN, Ethernet) connection; Mountable on Rail DIN;...
Page 8: Power Supply
User Manual Modbus / CAN - Datalogger Document code: MN67324_ENG Revision 1.200 Page 8 of 44 Industrial Electronic Devices POWER SUPPLY: The devices can be powered at 8…24V AC and 12…35V DC. For more details see the two tables below. Vmin Vmax Vmin...
Page 9: Function Modes
User Manual Modbus / CAN - Datalogger Document code: MN67324_ENG Revision 1.200 Page 9 of 44 Industrial Electronic Devices FUNCTION MODES: HD67324-B2-E-xxx-xGB The device has got two functions mode depending of the position of the ‘Dip1 of Dip-Switch A’: The first, with ‘Dip1 of Dip-Switch A’ at “OFF” position, is used for the normal working of the device.
Page 10: Leds
User Manual Modbus / CAN - Datalogger Document code: MN67324_ENG Revision 1.200 Page 10 of 44 Industrial Electronic Devices LEDS: HD67324-B2-E-232-xGB HD67324-B2-E-485-xGB The device has got five LEDs that are used to give information of the functioning status. The various meanings of the LEDs are described in the table below. Normal Mode Boot Mode Blinks quickly: Boot state...
Page 11 User Manual Modbus / CAN - Datalogger Document code: MN67324_ENG Revision 1.200 Page 11 of 44 Industrial Electronic Devices HD67324-B2-E-CAN-xGB The device has got five LEDs that are used to give information of the functioning status. The various meanings of the LEDs are described in the table below. Normal Mode Boot Mode Blinks quickly: Boot state...
Page 12: Rs232
User Manual Modbus / CAN - Datalogger Document code: MN67324_ENG Revision 1.200 Page 12 of 44 Industrial Electronic Devices RS232: The connection from RS232 socket to a serial port (example one from a personal computer) must be made with a NULL MODEM cable (a serial cable where the pins 2 and 3 are crossed).
Page 13: Rs485
User Manual Modbus / CAN - Datalogger Document code: MN67324_ENG Revision 1.200 Page 13 of 44 Industrial Electronic Devices RS485: For terminate the RS485 line with a 120Ω resistor it is necessary to put ON dip 1, like in figure. The maximum length of the cable should be 1200m (4000 feet).
Page 14: Can
User Manual Modbus / CAN - Datalogger Document code: MN67324_ENG Revision 1.200 Page 14 of 44 Industrial Electronic Devices CAN: For terminating the CAN line with a 120Ω resistor it is necessary to put Dip1 of ‘Dip-Switch C’ at ON position. Cable characteristics: DC parameter: Impedance...
Page 15: Ethernet
User Manual Modbus / CAN - Datalogger Document code: MN67324_ENG Revision 1.200 Page 15 of 44 Industrial Electronic Devices ETHERNET: The Ethernet port is used for programming the device and managing the functions. The Ethernet connection must be made using Connector2 of HD67324-B2-E-xxx-xGB with at least a Category 5E cable. The maximum length of the cable should not exceed 100m.
Page 16: Use Of Sw67324
User Manual Modbus / CAN - Datalogger Document code: MN67324_ENG Revision 1.200 Page 16 of 44 Industrial Electronic Devices USE OF COMPOSITOR SW67324: To configure the Datalogger, use the available software that runs with Windows called SW67324. It is downloadable on the site www.adfweb.com and its operation is described in this document.
Page 17: New Configuration
User Manual Modbus / CAN - Datalogger Document code: MN67324_ENG Revision 1.200 Page 17 of 44 Industrial Electronic Devices NEW CONFIGURATION: By pressing the “New Configuration” button it is possible to create a new project. It is possible to assign the name and confirm it by pressing the “OK”...
Page 18: Load Configuration
User Manual Modbus / CAN - Datalogger Document code: MN67324_ENG Revision 1.200 Page 18 of 44 Industrial Electronic Devices LOAD CONFIGURATION: By pressing the “Load Configuration” button it is possible to load an existing project by selecting one of the list that appears.
Page 19: Save Configuration
User Manual Modbus / CAN - Datalogger Document code: MN67324_ENG Revision 1.200 Page 19 of 44 Industrial Electronic Devices SAVE CONFIGURATION: By pressing the “Save Configuration” button it is possible to save the project. There are two possibilities: saving the current configuration, by pressing the button “Save”...
Page 20: Update Device
User Manual Modbus / CAN - Datalogger Document code: MN67324_ENG Revision 1.200 Page 20 of 44 Industrial Electronic Devices UPDATE DEVICE: By pressing the “Update Device” button it is possible to load the created Configuration into the device; and also the Firmware, if is necessary.
Page 21 User Manual Modbus / CAN - Datalogger Document code: MN67324_ENG Revision 1.200 Page 21 of 44 Industrial Electronic Devices If the USB version is used, in order to load the parameters or update the firmware in the device, follow these instructions: Turn OFF the Device;...
Page 22 User Manual Modbus / CAN - Datalogger Document code: MN67324_ENG Revision 1.200 Page 22 of 44 Industrial Electronic Devices Note: When you install a new version of the software, if it is the first time it is better you do the update of the Firmware in the HD67324 device.
Page 23: Software Preferences
User Manual Modbus / CAN - Datalogger Document code: MN67324_ENG Revision 1.200 Page 23 of 44 Industrial Electronic Devices SOFTWARE PREFERENCES: By pressing the “Software Preferences” button it is possible to select the preferences of the software SW67324. ELECT ANGUAGE In this section is possible to select the language of the software.
Page 24: Configuration Setting
User Manual Modbus / CAN - Datalogger Document code: MN67324_ENG Revision 1.200 Page 24 of 44 Industrial Electronic Devices CONFIGURATION SETTING: By pressing the “Configuration Setting” button it is possible to configure the various informations that the DataLogger wants for functioning.
Page 25 User Manual Modbus / CAN - Datalogger Document code: MN67324_ENG Revision 1.200 Page 25 of 44 Industrial Electronic Devices About the meanings of the others fields: In the field “Serial Baudrate” the Baudrate of the serial line is defined; In the field “Serial Parity”...
Page 26 User Manual Modbus / CAN - Datalogger Document code: MN67324_ENG Revision 1.200 Page 26 of 44 Industrial Electronic Devices OLLS ABLE This section is used only if the Data Logger is set like ‘Master’. In the table the various requests that the Data Logger sends are defined.
Page 27 User Manual Modbus / CAN - Datalogger Document code: MN67324_ENG Revision 1.200 Page 27 of 44 Industrial Electronic Devices This section is used only if the Data Logger is set like ‘Sniffer’ or “Slave + Sniffer”. In the left list, there are the IDs of the slaves that the Data Logger sniffs: the device will record all the requests/responses addressed to these IDs.
Page 28 User Manual Modbus / CAN - Datalogger Document code: MN67324_ENG Revision 1.200 Page 28 of 44 Industrial Electronic Devices CONFIGURATION SETTING FOR CAN VERSION PTION About the meanings of the others fields: In the field “CAN Baudrate” the Baudrate of the CAN line is defined;...
Page 29 User Manual Modbus / CAN - Datalogger Document code: MN67324_ENG Revision 1.200 Page 29 of 44 Industrial Electronic Devices CAN F ILTERS This section is used to define the CAN messages to log inside the DataLogger. It is possible to define different filters in relation of the type of CAN communication used (CAN 2.0A and CAN 2.0B).
Page 30 User Manual Modbus / CAN - Datalogger Document code: MN67324_ENG Revision 1.200 Page 30 of 44 Industrial Electronic Devices CAN 2.0B 29 B For CAN 2.0B messages, it is possible to define two type of filters: Filters CobID: the DataLogger will accept/discharge specific CAN messages defined in the list.
Page 31 User Manual Modbus / CAN - Datalogger Document code: MN67324_ENG Revision 1.200 Page 31 of 44 Industrial Electronic Devices If the “Filters Mask” is set, the fields below have this meaning: In the field “Insert Mask of CobID” the Mask for the COB-IDs is defined.
Page 32: Download Data
User Manual Modbus / CAN - Datalogger Document code: MN67324_ENG Revision 1.200 Page 32 of 44 Industrial Electronic Devices DOWNLOAD DATA: By pressing the “Download Data” button it is possible to download the stored data of the DataLogger and see them in a grid. After selecting the correct COM port or the Ethernet settings, by pressing the “Get...
Page 33 User Manual Modbus / CAN - Datalogger Document code: MN67324_ENG Revision 1.200 Page 33 of 44 Industrial Electronic Devices In this section there is the grid with the downloaded data. For Modbus version, the grid is composed of the following fields: “Date Time”: date and time of the request/response;...
Page 34: Date & Time Settings
User Manual Modbus / CAN - Datalogger Document code: MN67324_ENG Revision 1.200 Page 34 of 44 Industrial Electronic Devices DATE & TIME SETTING: By pressing the “Date & Time Setting” button it is possible to update/read the Data Logger data/time and having others informations.
Page 35: Webserver Interface
User Manual Modbus / CAN - Datalogger Document code: MN67324_ENG Revision 1.200 Page 35 of 44 Industrial Electronic Devices WEBSERVER INTERFACE (only Modbus version): The HD67324-B2-E-xxx-4GB has an integrated Webserver that allows to managed the Data Logger’s functions and download the data as Binary File.
Page 36 User Manual Modbus / CAN - Datalogger Document code: MN67324_ENG Revision 1.200 Page 36 of 44 Industrial Electronic Devices When one of the buttons of the “Welcome” page are pressed, it is necessary to do the login, using the “Admin” and “Password” defined in the section “Configuration Setting ...
Page 37 User Manual Modbus / CAN - Datalogger Document code: MN67324_ENG Revision 1.200 Page 37 of 44 Industrial Electronic Devices & D Figure 15: “Data Logger Time & Date” window When the “Time & Date” button is pressed, the “Data Logger Time & Date”...
Page 38 User Manual Modbus / CAN - Datalogger Document code: MN67324_ENG Revision 1.200 Page 38 of 44 Industrial Electronic Devices DLOG C OMMANDS Figure 16: “Data Logger Commands” window When the “DLOG Commands” button is pressed, the “Data Logger Commands” window appears (Fig. 16). It has the following structure: “NEXT EVENT”...
Page 39 User Manual Modbus / CAN - Datalogger Document code: MN67324_ENG Revision 1.200 Page 39 of 44 Industrial Electronic Devices When the logged events are displayed, the events’ table has these fields: “NUM” fields: the number of the event is defined; “TYPE”...
Page 40: Mechanical Dimensions
User Manual Modbus / CAN - Datalogger Document code: MN67324_ENG Revision 1.200 Page 40 of 44 Industrial Electronic Devices MECHANICAL DIMENSIONS: Figure 17: Mechanical Dimensions for HD67324-B2-E-xxx-4GB ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com Phone +39.0438.30.91.31...
Page 41: Ordering Informations
HD67324 = Data Logger Order Code: HD67324-B2-E-485-4GB Data Logger for Modbus on RS485 with 4 Gigabytes of memory (Ethernet interface) Order Code: HD67324-B2-E-232-4GB Data Logger for Modbus on RS232 with 4 Gigabytes of memory (Ethernet interface) Order Code: HD67324-B2-E-CAN-4GB Data Logger for CAN with 4 Gigabytes of memory (Ethernet interface) ADFweb.com Srl –...
Page 42: Accessories
User Manual Modbus / CAN - Datalogger Document code: MN67324_ENG Revision 1.200 Page 42 of 44 Industrial Electronic Devices ACCESSORIES: AC34107 Null Modem Cable Fem/Fem DSub 9 Pin 1,5 m AC34114 Null Modem Cable Fem/Fem DSub 9 Pin 5 m AC34001 Rail DIN Power Supply 220/240V AC 50/60Hz –...
Page 43: Disclaimer
User Manual Modbus / CAN - Datalogger Document code: MN67324_ENG Revision 1.200 Page 43 of 44 Industrial Electronic Devices DISCLAIMER: All technical content within this document can be modified without notice. The content of the document is a under continual renewal. For losses due to fire, earthquake, third party access or other accidents, or intentional or accidental abuse, misuse, or use under abnormal conditions repairs are charged to the user.
Page 44: Warranties And Technical Support
User Manual Modbus / CAN - Datalogger Document code: MN67324_ENG Revision 1.200 Page 44 of 44 Industrial Electronic Devices WARRANTIES AND TECHNICAL SUPPORT: For fast and easy technical support for your ADFweb.com SRL products, consult our internet support at www.adfweb.com. Otherwise contact us at the address support@adfweb.com RETURN POLICY: If while using your product you have any problem and you wish to exchange or repair it, please do the following:...
