MODEL #: FP51005
1. Shut o gas to the appliance.
2. Extinguish any open ame.
3. If odor continues, leave the area immediately.
4. After leaving the area, call your gas supplier or
re department.
Failure to follow these instructions could result in
re or explosion, which could cause property
damage, personal injury, or death.
INSTALLER: Leave this manual with
the appliance.
CONSUMER: Retain this manual for
future reference.
Do not store or use gasoline or other
ammable vapors or liquids in the vicinity
of this or any other appliance.
An LP-cylinder not connected for use shall
not be stored in the vicinity of this or any
other appliance.
Installation and service must be performed
by a quali ed installer, service agency, or
the gas supplier.
If the information in this manual is not
followed exactly, a re or explosion may
result causing property damage, personal
injury, or loss of life.
Advertisement
Related Manuals for GLOBAL OUTDOORS FP51005
Summary of Contents for GLOBAL OUTDOORS FP51005
- Page 1 ITM. / ART. MODEL #: FP51005 INSTALLER: Leave this manual with the appliance. CONSUMER: Retain this manual for future reference. Do not store or use gasoline or other ammable vapors or liquids in the vicinity of this or any other appliance.
- Page 2 WARNING Read and follow all instructions and warnings in this Owner’s Manual thoroughly before installing, operating, or servicing this Fire Pit. Improper installation, use, maintenance, adjustment or storage can cause re or explosion, resulting in serious injury or property damage. prepare for use: Keep away from Combustible/Flammable Items •...
-
Page 3: Dangers And Warnings
DANGERS AND WARNINGS THIS PRODUCT USES PROPANE ONLY • Use propane cylinders with the following required measurements only: 30.5 cm/12 in (diameter) x 45.7 cm/18 in (tall) with capacity 9 kg/19.84 lbs.) • Max gas supply 28cm/11 in w.c. (2.74kpa) •... -
Page 4: Preparation For Assembly
PREPARATION FOR ASSEMBLY Before beginning assembly of Fire Pit, make sure all parts are present. Compare parts with package contents list. If any part is missing or damaged, do not attempt to assemble Fire Pit. Estimated Assembly Time: 25 minutes NOTE: You must follow all steps to properly assemble Fire Pit. - Page 5 ASSEMBLY INSTRUCTIONS Make sure the gas supply system is turned to “OFF”. WARNING This re pit requires air ow under the unit. Do not place on uneven surface or on grass, turf or carpet. If the repit is put on uneven ground, it will create di culty in operation of the sliding door.
- Page 6 ASSEMBLY INSTRUCTIONS a) Turn Cylinder Valve on the top of Propane Tank clockwise to close o gas supply. See Figure 4a Cylinder Valve b) Screw Regulator Coupling clockwise by hand only. Make sure it is fastened. See Figure 4b Regulator Coupling Push Door (C) closed.
- Page 7 ASSEMBLY INSTRUCTIONS a) Place Fire Glass (F) evenly in Fire Bowl (A). Use caution when handling Fire Glass as it is sharp. See Figure 7a b) Do not place any Fire Glass over the Screen. See gure 7b c) Completely cover the entire Burner Ring with Fire Glass. See gure 7c Failure to completely cover the Burner Ring with the Fire Glass will cause ame to extinguish occasionally.
- Page 8 ASSEMBLY INSTRUCTIONS ITEM PICTURE DESCRIPTION ITEM PICTURE DESCRIPTION Long Glass Lower Buckles Short Glass Screw Upper Buckles Bolt Driver Glass Enclosure Assembly and Installation WARNING Make sure glass enclosure is xed in the correct position and all screws are tightened; otherwise the glass enclosure may slide or fall.
-
Page 9: Care And Maintenance
• Use manufacturer-approved or -supplied replacement parts and accessories only. Use of unauthorized replacement parts may void the warranty. • Please contact Global Outdoors, Inc. at 1-844-613-9170 for replacement Hoses, Igniters, Fire Glass, Nylon Cover, Regulator and Feet. • Keep Fire Pit free and clear from combustible materials. - Page 10 No Igniter battery or igniter battery low on Replace with new igniter battery. power No spark No power in igniter Igniter battery is incorrectly inserted Reinsert the battery properly. between ignition wire Igniter broken or cracked Call customer service for replacement part. and burner Ignition wire is loose or disconnected to hole while...
- Page 11 this page is intentionally left blank...
-
Page 12: Warranty
WARRANTY TM/MC/MR The manufacturer's warranty will be voided by, and manufacturer disclaims any responsibility for, the following actions: • Modi cation of the re bowl and/or components including the gas valve assembly. • Use of any component part not manufactured or approved by manufacturer. •...
