- Page 1 Extending Power AmplifierAM8300 User’ Manual AM8328 System Extending Power Amplifier AM8300 Welcome to use the central audio system. To make the better use of this equipment, please read this instruction carefully prior to use. http://www.auxdio.com http://www.dsppatech.com...
- Page 2 AM8300 is the partition extended power amplifier used for the multi-room network music system. Every set of AM8300 is able to provided 4 additional partitions for the user, so as to meet the needs of the user for multiple partitions. One AM8328 host is able to connect 16 AM8300 extending boxes by the “hand-in-hand”...
- Page 3 Note: Whenever you want to add several sets of AM8300 to AM8328, make sure to set the address ID of AM8300 and prevent the repeated ID! After setting ID, it is required to reboot...
- Page 4 Central Audio System Description of Connection 1. Connecting AM8300 to host, “hand-in-hand” connection mode...
- Page 5 Central Audio System 2. Connecting AM8300 to AM8328 host, star connection mode If you want to achieve the star connection mode, it is required to provide one exchanger. Exchanger In case of the insufficient length of the network cable, you may make the network cable by yourself in accordance with the connection method as shown below.
- Page 6 Central Audio System 3. Connecting AM8300 to BM828R control panel Remark: two-channel Infrared remote controller input connection, there may be 15 panel controllers on any channel connected by “hand-in-hand” mode...
- Page 7 Central Audio System Packing List Product Quantity AM8300 host 1 set Power line 1 piece Operation instruction 1 copy Quality certificate and warranty card 1 copy Performance Specification Item Indicator Number of partition 4 partitions Rated output power Stereo, 8×30W/8Ω...
- Page 8 http://www.dsppatech.com...
