Mounting Bracket AZURA® S
The mounting bracket can be mounted onto the side panel of AZURA® devices with a S foot-
print. It is used to mount a manual injection valve.

Tools

Ablauf
1. Position the mounting bra-
cket onto the bore holes in
the side panel. In this posi-
tion, the mounting bracket
must sit flatly on the surface.
2. Slide the washers
over the thread of the two
smaller cylinder bolts. Using
the Allen screwdriver, size 2,
screw the mounting bracket
onto the housing.

Mounting a valve

Tools

Process

1. Remove the lid from the lever.
2. Loosen the screw of the lever
screwdriver size 2.5 mm.
3. Pull off the lever from the adapter plate
2
.
4. Loosen the 2 screws of the adapter plate
2
with the screwdriver size 3 mm.
5. Detach the adapter plate
3
feather key .
6. Detach the feather key
4
.
Supplement AZURA® Mounting Bracket S, V6848, version 2.0
Allen screwdriver, size 2 mm
ƒ
Allen screwdriver, size 3 mm
ƒ
Abbildung
each
1
Fig. 1:
Rear view: Mounting bracket with valve
Allen screwdriver, size 3 mm
ƒ
Allen screwdriver, size 2.5 mm
ƒ
1
with the
2
from the
3
from valve head
Figure
Fig. 2:
Exploded view
1
1
2
3
4
Page 1
