  • Page 1 Android User Guide V2.0...

  • Page 2: Table Of Contents

    Diagnostic Tool Overview......................... 4 iLAND App: iOS versus Android....................... 5 Getting Started ....................6 Installing the Diagnostic Tool ......................6 iLAND App Setup for Android ......................7 User Registration..........................11 Activating the Diagnostic Tool ......................14 Using the iLAND App..................15 Logging in to the App ........................

  • Page 3: Introduction

     Please read this manual carefully before operating your device.  Please keep this manual safe for future use.  App updates may change the look or text of the iLAND app. The illustrations and instructions within this manual are for reference purposes only.

  • Page 4: Product Introduction

    Land Rover models from 1987 to present, with many functions and capabilities available for late-model Land Rovers (2003 and newer). iLAND is compatible with iOS and Android mobile devices via the free iLAND app, available for download from the Apple App Store and Google Play Store.

  • Page 5: Kit Contents

    Introduction Kit Contents  Diagnostic Tool  Quick Start Guide  Activation Card  Box Diagnostic Tool Overview 1. LED status ring 2. OBD diagnostic connector 3. Device serial number LED status ring colors COLOR SOLID FLASHING Green Power Connected Blue Bluetooth®...

  • Page 6: Iland App: Ios Versus Android

    Introduction iLAND App: iOS versus Android When using the iLAND diagnostic app, please note that there are some differences when using it on devices running iOS versus Android operating systems:  While most menu options are similar, there are some instances where you will have slightly different options (e.g.

  • Page 7: Getting Started

    Getting Started Installing the Diagnostic Tool Getting Started Getting Started CAUTION: Always turn the ignition switch OFF before connecting or disconnecting the Diagnostic Tool. Locate your vehicle’s diagnostic port. Depending upon the model of the vehicle, this port is normally located under the dashboard or near the center console. The above illustration notes the five possible locations of the diagnostic port.

  • Page 8: Iland App Setup For Android

    “User Registration”, page If you have an existing iLAND app account, sign in with your email address and password. See “Logging in to the App”, page NOTE: The first time the app is opened on your device, you will be prompted for access...
  • Page 9 Getting Started 3. Activate the Diagnostic Tool You will receive a prompt to activate the Diagnostic Tool. If you have not yet activated the Diagnostic Tool, press Activate. See “Activating the Diagnostic Tool”, page 14 for instructions. If you wish to activate at a later time, press Cancel and continue to the next step.
  • Page 10 Getting Started 4. Model Selection NOTE: If you have not purchased iLAND Pro, you will only be able to activate one model. This selection cannot be changed once it is made. NOTE: If you have purchased iLAND Pro, you will be able to download vehicle software for all models after initial setup of the app.
  • Page 11 Getting Started 6. Ready to Use Models which have been purchased and downloaded will be highlighted. It is possible to add additional model coverage to the app by purchasing additional subscriptions within the app. “Software Subscriptions”, page...

  • Page 12: User Registration

    Getting Started User Registration To create a user account for the iLAND app, perform the following steps: 1. Open the iLAND App Open the iLAND Diagnostics app and select Create an Account.
  • Page 13 Getting Started 2. Set Your User Details Fill out the noted fields with your information, then press Add User Detail to continue.
  • Page 14  Confirm your chosen password in the noted field.  Press the CAPTCHA button and enter the revealed code into the noted field.  After all fields have been filled out, press the Register button to continue. Return to “iLAND App Setup for Android”, page...

  • Page 15: Activating The Diagnostic Tool

     Activation Code: Enter the Activation Code, which is on the Activation Card that comes with the kit. Carefully scratch away the silver coating with a coin to reveal the code printed underneath.  Press Next to continue. Return to “iLAND App Setup for Android”, page...

  • Page 16: Using The Iland App

    Logging in to the App Using the iLAND App Using the iLAND App To log in to the iLAND app with your account, perform the following steps: 1. Ensure that your device has an internet connection. 2. Open the iLAND app.

  • Page 17: Navigating The App

    Using the iLAND App Navigating the App HomePage The HomePage is the first screen that opens after you have logged into the app. Press an option to select it.  EOBD Diagnostics: Generic diagnostics with no model selection. See “Starting Diagnostics”, page...
  • Page 18 Using the iLAND App Navigating menus To return to the previous menu, press the arrow in the banner at the top of the screen. In the example shown, you would press < to return to the Show Menu screen. In report-style screens, there is usually a Back button at the bottom that you can press to return to the previous screen.

  • Page 19: Reports And Settings

    Using the iLAND App Reports and Settings The Reports and Settings menu has several options:  My Report: See page  Diagnostic Feedback: See page  Change Password: See page  Update Entitlement: See page  Firmware Restore: See page ...
  • Page 20 To aid in reporting any potential issues with app performance or results (e.g. actuation tests, data streams), use Diagnostic Feedback to send details to iLAND support. Press Confirm on the prompt, then select the vehicle log related to your issue.
  • Page 21 Adding a description of the issue is optional, but important in working towards a resolution. If possible, please include:  Vehicle model and year  Vehicle Identification Number (VIN)  Detailed description of the issue Press Submit Result to send the information to iLAND support.
  • Page 22 Using the iLAND App Change Password To change the password to your account, press Change Password. Enter your old password in the designated field, then enter your new password in the designated fields and press OK to submit. You will receive a prompt if the password change is successful.
  • Page 23 Using the iLAND App Firmware Restore CAUTION: During a firmware restoration, do not perform other operations on your device. CAUTION: Keep the Diagnostic Tool plugged into the vehicle and powered on throughout the firmware restoration process. If support determines it necessary, this option can be used to restore the current firmware version to your Diagnostic Tool.
  • Page 24 Using the iLAND App Settings In Settings:  The current version of the iLAND app will be displayed.  Units of measurement can be toggled between Metric and Imperial.

  • Page 25: Support And Coverage

    Support and Coverage In Support and Coverage:  Press Email to email iLAND support, then select your email client from the prompt. NOTE: The email client options displayed depend upon what is currently installed and set up on your device.

  • Page 26: Diagnostic Tool Firmware Updates

    Using the iLAND App Diagnostic Tool Firmware Updates Atlantic British may release firmware updates for your Diagnostic Tool in order to add improvements or resolve issues. To check for an available firmware update: 1. Connect the Diagnostic Tool to the vehicle's diagnostic port (see “Installing the Diagnostic...
  • Page 27 Using the iLAND App 4. If the app detects that a firmware update is available for the Diagnostic Tool, the update will begin automatically. Keep your device near the Diagnostic Tool and stay plugged into the vehicle until the update completes.

  • Page 28: App Software Updates

    Using the iLAND App App Software Updates When your device is online, the iLAND app will automatically check for software updates for the model(s) you have selected. If a software update is available, you will be prompted by the app to download and install it. Follow the prompts to complete this process and ensure your device maintains an internet connection throughout.

  • Page 29: Closing The App

    Using the iLAND App Closing the App When you exit an app on your mobile device, it usually continues to run on standby in the background. To completely close the app on your device, perform the following steps: 1. View all the running apps on your device. How you do this depends on your device and the Android version it is running.

  • Page 30: Software Subscriptions

    Using the iLAND App Software Subscriptions The iLAND diagnostic kit includes access to diagnostics and software updates for one Land Rover model for three years from point of activation. This allows access to wireless diagnostics, component configuration, and the latest app software updates as they become available.
  • Page 31 Using the iLAND App Purchasing a new subscription To purchase a new subscription, press Reports and Settings > Update Entitlement > Subscription Information. Press Purchase next to the model you wish to purchase, then follow the instructions.
  • Page 32 Using the iLAND App Viewing existing subscriptions/voucher codes To view the status of subscriptions and voucher codes used by your account: 1. Press Reports and Settings > Update Entitlement > Voucher Consumption Record. 2. On the next screen, select the code you wish to view.
  • Page 33 Using the iLAND App Viewing a subscription’s/voucher code’s status To view the status of a voucher code, press Reports and Settings > Update Entitlement > Query Voucher Info. Enter a voucher code to display its configuration, renewal term, status (e.g. used/unused), and date of activation (if applicable).

  • Page 34: Starting Diagnostics

    Using the iLAND App Starting Diagnostics Once the iLAND app and Diagnostic Tool are activated, you may begin diagnosing vehicles under your current model activation(s). NOTE: Bluetooth® must be enabled on your device in order for it to communicate with the Diagnostic Tool.
  • Page 35 Using the iLAND App 5. Press Search Bluetooth to being pairing the Diagnostic Tool to the app. NOTE: Once the Diagnostic Tool is paired successfully, it is not necessary to pair again the next time a diagnostic session is started.
  • Page 36 Using the iLAND App 6. Verify that the serial number displayed matches the one on your Diagnostic Tool, then press PAIR. NOTE: It is not necessary to check the box to allow access to your contacts and call history.
  • Page 37 Using the iLAND App 7. The connection status will be displayed. Once your device has paired to the Diagnostic Tool successfully, you will be returned to the selected vehicle screen.
  • Page 38 Using the iLAND App 8. Press Confirm to begin diagnostics. 9. Select the model year of your vehicle. 10. Select the vehicle engine type.
  • Page 39 Using the iLAND App 11. The next menu will list all available diagnostics and system management functions for that model. These functions usually include:  Health Report: Checks all vehicle systems and lists any existing fault codes. Report can be saved and shared. See “Running a Health Report”, page...

  • Page 40: Running A Health Report

    Using the iLAND App Running a Health Report A Health Report lists your vehicle’s basic information and diagnostic test results in a concise, easy-to-read format. Saving and sharing Health Report files can be useful as a reference for yourself or a customer.
  • Page 41 Using the iLAND App 2. The Diagnostic Tool will begin scanning all available systems and report its findings in the app. The progress of the scan will be displayed at the top of the list. Press Pause to pause the scan at any time, or Back to cancel and return to the previous menu.
  • Page 42 Using the iLAND App 3. The progress will disappear from the list once the scan is completed. All scanned system names will be listed, along with the scan results of each. Detected Diagnostic Trouble Codes (DTCs) or “faults” will be highlighted in red text. From here, you can: ...

  • Page 43: System Selection

    Using the iLAND App System Selection Using the System Selection option allows (when available) for you to read and clear Diagnostic Trouble Codes (DTCs), as well as read a live data stream from a selected system on the vehicle. 1. After starting diagnostics (see “Starting Diagnostics”, page...
  • Page 44 Using the iLAND App 3. The available options for the selected system will be displayed. Reading fault codes 1. From the main menu of the selected system, press Read Fault Code.
  • Page 45 Using the iLAND App 2. The selected system will be scanned, and any stored fault codes will be displayed, along with their DTC designation and current state.
  • Page 46 Using the iLAND App Clearing fault codes 1. From the main menu of the selected system, press Clear Fault Memory to clear any inactive fault codes from the selected system’s Electronic Control Unit (ECU). NOTE: Fault codes with an “active” or “intermittent” status cannot be cleared until the underlying issue with the vehicle is resolved and the ECU has updated the code’s status to...
  • Page 47 Using the iLAND App Viewing live data streams 1. From the main menu of the selected system, press Read Data Stream. 2. Press to check the boxes of each data stream you wish to view, then press Confirm.
  • Page 48 Using the iLAND App 3. On the Value screen, any selected data stream types will be displayed in a table format, along with its current real-time value and unit of measurement. If your total selections create multiple data pages, you can press the arrow icons near the bottom to move between pages.
  • Page 49 Using the iLAND App 4. On the Graph screen, any selected data stream types will be displayed in graph format, along with its current real-time value and unit of measurement displayed above each graph. If your total selections create multiple data pages, you can press the arrow icons near the bottom to move between pages.

  • Page 50: Special Functions

     Resetting the oil service counter after an oil change  Programming a new key to work with the vehicle  Replacing a tire pressure monitoring sensor in the wheel Atlantic British has a number of how-to videos for common special function features available on their website: www.roverparts.com 1.
  • Page 51 Using the iLAND App NOTE: Availability of the listed function is dependent upon the model and year. A listed function may not necessarily be supported; you will be prompted if this is the case. 2. In the next menu, special functions are contained under functional sub-headings. For example, key programming is usually listed under Alarms/Security or a similar sub- heading.

  • Page 52: Troubleshooting

    Troubleshooting Logging Into the App Troubleshooting Troubleshooting CHECK Does your device have an internet Open the iLAND app and Connect your device to the internet. connection? continue Have you created an account? Continue “User Registration”, page 11 directions to set up your account.
  • Page 53 “connected” in possible issues and the list of paired resolutions. Bluetooth® devices on your device? Start the iLAND Did the app open Continue “FAQ: Starting the app. successfully? app”, page 56 for a list of possible issues and resolutions.
  • Page 54 Troubleshooting STEP ACTION CHECK NOTE If the vehicle is model year 2006 or newer, select System Selection, then select ABS or Engine Management Controller. Ensure the The ignition vehicle's ignition may time out on is ON. older vehicles. Select Read Did DTCs read System is 1.

  • Page 55: Frequently Asked Questions

    If you install the iLAND app on a different device, log in to the app with the account tied to the Diagnostic Tool you wish to use. If prompted to activate the Diagnostic Tool during initial setup, select Cancel to continue.
  • Page 56 Troubleshooting FAQ: Logging in I receive the message “Network error” when I try to log in. This message will appear if your device is not online. Check your device’s internet connection. I receive the message “User Does Not Exist” when I try to log in. NOTE: Once the Diagnostic Tool has been activated on an account, it will be registered to that account ONLY;...
  • Page 57  If the above situations do not apply to you, then delete and reinstall the iLAND app on your device, following the correct procedure from the Google Play Store.

  • Page 58: Contact Information

    Troubleshooting Contact Information Atlantic British USA East Coast 6 Enterprise Avenue Clifton Park, NY 12065 Toll Free: (800) 533-2210 Direct*: (518) 664-6169 Fax*: (518) 664-6641 * add “00 (1)” for international Phone hours: Mon-Thu 8am-7pm (Fri 6pm) EST Website: www.roverparts.com Technical support email: iland-app@atlanticbritish.com...

  • Page 59: Specifications

    Specifications Diagnostic Tool Specifications Specifications Model DS402 Operating Temperature Range 0~50°C Working Voltage DC 9~18V Working Current ≤130mA Communication Mode Bluetooth® BLE 4.2 Dimensions (L)74mm x (W)47.1mm x (H)24mm Weight <100g...
