Summary of Contents for Global American 1507603
- Page 1 Quick Reference Guide Mini PCI Serial Interface Module 1507603...
- Page 2 Copyrights This Quick Reference Guide is copyrighted and all rights are reserved. It does not allow any non authorization in copied, photocopied, translated or reproduced to any electronic or machine readable form in whole or in part without prior written consent from the manufacturer. In general, the manufacturer will not be liable for any direct, indirect, special, incidental or consequential damages arising from the use of inability to use the product or documentation, even if advised of the possibility of such damages.
- Page 3 1.1 <Connector Location> JCSEL1 CN_COM1/2 CN_COM3/4 JCSEL2 1.2 <Jumper Location & Reference> JCSEL1 JCSEL2 CN_COM1/2/3/4 1.3 <Specifications> Specifications Form Factor Mini-PCI TYPEIIIB Controller OXmPCI954-LQ-A Accessories 2X10 com port cable X2...
- Page 4 1.4<Jumper Setting> JCSEL1 JCSEL2 RS-232 RS-485 RS-422 RS422/485 output form COM2 1.5 <Driver Setting> 1. Please choose Device Manager...
- Page 5 2. Then you can see Other devices 3. Please choose Other PCI Bridge Device then press Reinstall Driver...
- Page 6 4. Please choose NO, not this time press Next 5 . Please choose Install from a list on specific location.
- Page 7 6 . Please select file location CDROM:\OXFORD\Ox954_V4_09 Press OK~ 7. After Other PCI Bridge Device Driver setting please choose PCI Serial Port then press mouse right key select properties...
- Page 8 8. Please choose Reinstall Driver 9. Please choose NO, not this time press Next...
- Page 9 10. Please choose Install from a list on specific location press next 11. Please select file location CDROM:\OXFORD\Ox954_V4_09 Press OK...
- Page 10 12. After driver install , please enter Device Manager then select PCI Communications Port (COM5) press properties. 13. Please select Data rate...
- Page 11 14. Please press Detect Crystal Frequency. Repeat for all remaining COM ports.
- Page 12 Any advice or comments about our products and service, or anything we can help you with please don’t hesitate to contact with us. We will do our best to support your products, projects and business. Address: Global American, Inc. 17 Hampshire Drive Hudson, NH 03051 Telephone: Toll Free (U.S. Only) 800-833-8999...
