Page 1: Table Of Contents
Screen care and maintenance Warranty info and cer ﬁcate 21-22 Reproduc on including prin ng, distribu ng or modifying of this PDF manual is forbidden. Visit us online today at h ps://www.projectorscreens.com.au | P: 07 5546 1960 © Copyright 2002-2019 Oz Theatre Screens.
Page 2 4596 X 2026 4446 X 1876 Oz Theatre Screens can also produce custom size screens upto 6 metres wide and 2.4 metres high in some fabrics and formats. Contact us for other formats such as 4:3 and 16:10. Visit us online today at https://www.projectorscreens.com.au or call (07) 5546 1960...
Page 3: To The Owner
. We at OZ THEATRE SCREENS would like to thank you for purchasing this high quality projec on screen manufactured in Australia. You have supported a 100% owned and operated Australian business...
Page 4: Accessories Kit
Your OZ THEATRE MAJESTIC SCREEN COMES WITH THE FOLLOWING: 4 Lengths of alloy frame extrusion wrapped Fidelio velvet Packaged and sealed on foam shelving. 12 small sec ons of screen grip. 1 pair of cu ers and 1 spline roller 8 tapped corner plates 1 Pair of gloves with grub screws...
Page 5: Tools Required
Tools required: The following tools are required for assembly of your Oz Theatre Majestic Projection Screen 1. Power or ba ery drill with 3mm bit and philips head bit. 2. Spirit level and or tape measure to ensure screen sits straight on your wall.
Page 6: Hanging Rail
Install hanging rail ﬁrst. Once you know the height of your screen on the wall, take the supplied hanging rail and measure up from the top of the image 75mm. The top of the rail sits at the top of the frame which is 75mm higher than top of the screen image.
Page 7 How the screen frame sits on the rail on the wall. WALL Gyprock Wall stud Drill your holes in the rail just under the centre of straight sec on. screen fabric If needed, use a centre punch to keep drill holes in right spot.
Page 8: Frame Assembly
Frame assembly: DO NOT ASSEMBLE YOUR SCREEN 1. Find an area large enough to work on the screen. ON A HARD FLOOR. ASSEMBLE ON CARPETED FLOOR ONLY. NOTE: Do not unroll the projection fabric until frame is fully assembled. Unpack your drop sheet and lay out in an area large enough to work on your screen.
Page 9 Frame assembly con nued: Repeat this for the other long side so you end up joining the 2 long sides and one of the short sides. See below. 4. Insert the remaining 2 sets of plates into the last short piece of frame and then insert both ends into their corresponding channels at the same time.
Page 10 Frame assembly con nued: Once you’re happy with your frame joins and grub screws are all ghtened up. Hang the frame only (fabric insert is a er this sec on) on the rail and adjust your frame so it’s in the correct posi on. Move le or right to ﬁnalise it’s spot.
Page 11: Evo 4K Fabric A Achment
FIXING THE SCREEN FABRIC TO THE FRAME See PAGES 16-18 FOR ACOUSTIC VISION FABRIC ATTACHMENT 1. Put on gloves supplied and place the tube at the end of the frame and unroll over the back of the assemble frame. The fabric should lay approx 10cm over all edges of the frame. Once rolled out, adjust so it sits evenly over the back of the frame on all 4 sides.
Page 12 4. Once the ﬁrst piece is put in place on the ﬁrst long side (top or bo om) Pull the material moderately ght and insert another small piece on the opposite side at #2. Then go across the frame and insert 3 and 4. You may need to pull the material a li le ghter as the span is longer le to right.
Page 13 Inser ng the corner keepers. Two people makes shorter work as one can hold the material outward while the other inserts the screen grip material. Remember. You want a ﬂat screen not a drum skin. Don’t try and over stretch the Evo 4K fabrics. It only needs to be ﬂat.
Page 14 Once the ﬁrst sec on is in place, move to the opposite side and pull material outward as you roll it from the from the centre to the corner, go back and forth un l you get a smooth ﬁnish as per images below. Hold the screen grip slightly upward and roll it down into the channel as you go along.
Page 15 You can either leave the smaller sec ons in place and simply cut the longer sec ons to size as you get to each one. OR you can completely remove the small pieces as you get to each one. Both ways work well, the la er being the more logical choice.
Page 16 Once all the sec ons are in place. Check the screen grip strips and press down in any areas where it’s s ll raised up slightly. Check all areas of screen for ﬂatness and check if using Acous c Vision material that’s it’s si ng fairly ght.
Page 17: Acous C Vision A Achment
Fixing Acous c Vision to the frame. NOTE: The Acous c Vision4K fabric is supplied in the full width of 250cm or 320cm for larger sizes. The fabric MUST BE TURNED on an angle to remove any chance of seeing moire pa erns. Turn fabric so each side of the frame has approx 30-100mm overhang.
Page 18 Once you have pinned the fabric as per instruc ons on the previous pages, you can carefully trim oﬀ the excess material to make it easier to work with. Scissors are recommended, if using the supplied knife be careful. Leave yourself about 100mm on all 4 sides. Then start splining the fabric ﬁrmly into the channel and insert the strips star ng on one of the short sides, then the adjacent top and...
Page 19 The end result. A perfectly ﬂat and taut Acous cally transparent screen...
Page 20 Screen care Cleaning the screen surface: Your Oz Theatre Projec on Fabric can be easily damaged if handled, installed or cleaned incorrectly. Please pay special a en on to these cleaning instruc ons. Never a empt to use inappropriate cleaning chemicals on the screen. In the event of soiling the screen surface may be cleaned using the following: Cleaning guidelines : You will generally require 3 new micro ﬁbre cloths or 3 new cleaning towels - DO NOT use scourers or abrasive materials on your screen material...
Page 21 Oz Theatre Screens The lifetime warranty covers the usefulness of the screen. It does not cover small blemishes in the velvet frame that can only be seen from obscure angles and that do not eﬀect the on screen image quality or performance, the same applies...
Page 22 HEATRE SCREENS HEATRE SCREENS Copyright Oz Theatre Screens 2002-2019 Version 1.2.8 Sept 2019...
