Ross Reels CLA Manual

Changing the Direction of the Retrieve on a CLA Reel

Changing the Direction of the Retrieve

1. Remove the Spool (1) from the Frame (3) by pressing the Spool Release Lever (2).
2. Use your thumb nail or a small slotted screwdriver to open the Retrieve Direction Switch (6) to a 90 degree
position.
3. To change the retrieve from left hand to right hand, rotate the Escapement Cover (5) counterclockwise until it
stops against the Retrieve Direction Switch (6). To change the retrieve from right hand to left hand, repeat step #2
and rotate the Escapement Cover (5) in a clockwise direction.
4. To complete the conversion for either direction, close the Retrieve Direction Switch (6) back into the Escapement
Cover (5).
5. Replace the Spool (1) on the Frame (3).
NOTE: When changing the direction of the retrieve, the direction in which the backing and line are wound onto the
spool must be reversed. When viewing the outer face of the spool, the backing and line should be wound on
in a clockwise direction for left hand retrieve and in a counterclockwise direction for right hand retrieve.
ALL PRODUCTS AND CONTENT ©2008-2009 ROSS REELS USA. ALL RIGHTS RESERVED
1. SPOOL
2. SPOOL RELEASE LEVER
3. FRAME
4. DRAG KNOB
5. ESCAPEMENT COVER
6. SELECTOR SWITCH
