Motospeed SYNOPSIS CK62 User Manual

WWW.MOTOSPEED.CC
WWW.MOTOSPEED.CN
Ck62
GAMING KEYBOARD
1 2 3 4 G1 G2 G3 G4 G5 G6
F1 F2 F3 F4 F5 F6 F7 F8 F9 F10
INS HOME
DEL
System Requirements:
Windows XP /Vista/win7/Win8/
Win10/Mac/Android
Wired mode feature overview:
1. USB Full Speed 2.0, support up to 1000Hz true reporting rate
2. USB cable mode supports full key without punch
3. Support for Windows systems, Android systems, Mac systems, and other general purpose system devices
4. Support the potentiometer knob to adjust the volume and brightness: the factory default is the volume adjustment, when the
knob switch is pressed, the brightness is adjusted (individual mode)
5. Wired mode switching: Press the FN+Tab button (3-5 seconds) at the same time,Caps the indicator light below the button
flashes yellow 3 times.Light green again, switch wired mode successfully.
Note: When using wired mode, please turn off the Bluetooth power switch on the back to protect the battery.
Bluetooth mode feature overview:
1.Bluetooth is Broadcom BCM20730 Bluetooth 3.0; Bluetooth mode supports full-key no-rush.
2.Support for Windows systems, Android systems, Mac systems, and other general purpose system devices.
3.Bluetooth mode switching: Press the FN+Tab button (3-5 seconds) at the same time,Caps the indicator light below the button
flashes purple 3 times,Bright blue again, switch Bluetooth mode successfully.
4.How Bluetooth matches:
Step 1: open the Bluetooth power switch on the back
Step 2: short press FN+E/R/T and any one of these three buttons.
Step 3: long press FN+Q (3-5 seconds) for Bluetooth pairing ,Caps The indicator below the button flashes blue.
If the code is successful, the blue light is off. If the code is unsuccessful for 3 minutes, it will automatically exit and the
keyboard will sleep.Need to re-pair, press FN+Q again (3-5 seconds)
5.Support one pair of three Bluetooth devices:
When the FN+E R T button is pressed shortly to switch the device, the corresponding purple light flashes 3 times to indicate that
the switch is successful.After the Bluetooth keyboard is connected to the device, it will not operate for 10 seconds, automatically
turn off the backlight, and enter the sleep mode after 10 minutes.Click any button to wake up the original state.
F11 F12
PS PB
PU PD
END
1
SYNOPSIS
GAMING KEYBOARD
中文
尺寸:290X100X40MM
重量:468g
寿命:50,000,000times(次)
电流:200mA
电压：3.7V
数量:61键，采用双色键帽技术
Español
Tamaño: 290X100X40MM
Peso: 468g
Vida útil: 50,000,000 veces (veces)
Corriente: 200mA
Voltaje: 3.7V
Cantidad: 61teclas, tecla de dos colores
Português
Tamanho: 290X100X40MM
Peso: 468g
Tempo de vida: 50.000.000 vezes (vezes)
Corrente: 200mA
Tensão: 3.7 v
Quantidade: 61 teclas, keycap de duas cores
Ελληνικά
Μέγεθος: 290X100X40MM
Βάρος: 468g
Διάρκεια ζωής: 50.000.000 φορές (φορές)
Τρέχουσα: 200mA
Τάση: 3.7V
Ποσότητα: 61 πλήκτρα, δύο κεφαλές
Polski
Rozmiar: 290X100X40MM mm
Ciężar: 468g
Żywotność: 50 000 000 razy (razy)
Natężenie prądu: 200 mA
Napięcie: 3,7V
Ilość: 61 klucze, dwukolorowe nasadki
2
USER MANUAl
BORN FOR THE GAME
English
Size: 290X100X40MM
Weight: 468g
Lifetime: 50,000,000times
Current: 200mA
Voltage: 3.7V
Quantity: 61 keys, two-color keycap
Türk dili
Boyut: 290X100X40MM
Ağırlık: 468g
Ömür boyu: 50,000,000 kez (kez)
Akım: 200mA
Gerilim: 3.7V
Miktar: 61 tuş, iki renkli tuş takımı
Українська
Розмір: 290X100X40MM
Вага: 468г
Термін служби: 50 000 000 разів (разів)
Струм: 200мА
Напруга: 3.7V
Кількість: 61 ключі, двокольоровий keycap
Deutsch
Größe: 290X100X40MM
Gewicht: 468 g
Lebensdauer: 50.000.000 mal (mal)
Strom: 200mA
Spannung: 3,7 V
Anzahl: 61 Tasten, zweifarbige Tastenkappe
