Spandan ECG
User 'S Manual

Advertisement

loading
Need help?

Need help?

Do you have a question about the Spandan ECG and is the answer not in the manual?

Questions and answers

Summary of Contents for Sunfox Spandan ECG

  • Page 1 Spandan ECG User ’S Manual...
  • Page 2 Spandan ECG device and Android Application is mainly designed for general household use, Hospitals and clinics. Spandan ECG is a unique technology in its clan which provides patients and health conscious people, access to their heart health. This manual will guide you to use Spandan ECG device and Application smartly.

  • Page 3: Safety Information

    Always consult your doctor. People with prior heart disorders, Self-diagnosis of measurement should consult a doctor before and self-treatment/ diagnosis and after using the unit. is dangerous. Buy the electrodes at www.sunfox.in...
  • Page 4 What kind of Test, Spandan ECG Device and Application performs ? (a) Arrhythmia Test This test is recommended when chest Palpitations or Chest Pains are felt spontaneously, it is helpful in a couple of minutes of a Cardiac arrest. Hence,...
  • Page 5 To perform an Arrhythmia test via Spandan Portable ECG device follow these steps. Step 1 Go to Google Play Store and Download Spandan Portable ECG Application. Step 2 Open Spandan Application on your smartphone.
  • Page 6 Step 3 Connect Spandan ECG Device to your Android smartphone with given micro USB cable. Step 4 Select option Arrhythmia test and grant Access to the Spandan Application to access the Spandan ECG device by Pressing “OK”.
  • Page 7 Step 5 Connect the chest leads as shown in the app screen and Press the Start Test button to start the test. Step 6 “Generate Report” and save it for future use.
  • Page 8 Step 7 Receive the Spandan AI reports at the registered email account. Step 8 Generate PDF reports and share it with your Consult Doctors from Remote area.
  • Page 9 (b) ECG Test For ECG test tap on the 7-lead ECG test and follow the process.
  • Page 10 R e p e a t t h e “ S t a r t R e c o r d i n g P r o c e d u r e ” h e n c e a t l a s t t a k i n g r e a d i n g f r o m V 1 t o V 6 , l e a d I I and...
  • Page 11 A f t e r c o m p l e t i n g t h e t e s t T a p o n “ G e n e r a t e R e p o r t “ i c o n .
  • Page 12 F i l l u p y o u r Information A n d T a p o n “ Proceed Button”.
  • Page 13 T a p o n “ S ave B u t t o n ” to s a v e y o u r r e p o r t s . Y o u c a n e x p o r t i t o r s h a r e i t a s P N G o r P D F o n y o u r m a i l , W ha t s a p p a n d o t h e r so c i a l me d i a...
  • Page 14 Correct Posture instructions for accurate ECG and Arrhythmia Test? Take off your shirt. Make sure your skin is dry, hairless, and oil-free. Shave hair that can possibly prevent electrode placement. Electrodes should have full contact with the patient's skin (This is to minimize your pain as leads consists jelly like liquid which cause pain when these are removed).
  • Page 15 For better electrode adhesion and oil-free skin, rub the area with an alcohol prep pad or gauze pad with benzoin tincture. Promote an environment that prevents the patient from sweating in large amount. Make sure the electrode conducting gel is fresh and adequately moist. A dry electrode with inadequate gel reduces the conduction of the ECG signal.
  • Page 16 Often, electrode gel dry-out is a result of incorrect storage. Store electrodes as instructed by manufacturer and do not remove from their pouch until they are ready for use. Do not place electrodes on skin over bones, incisions (a surgical cut made in skin) , irritated skin, and body parts where there is lots of possible muscle movement.
  • Page 17 To take ECG, you need to be relaxed and comfortably seated, under comfortable room temperature. No bathing, drinking alcohol or caffeine, smoking, exercising or eating. Sit upright with your back straight.
  • Page 18 What you will get inside Spandan ECG Device Packaging? Spandan ECG Device World’s smallest ECG device, which can measure your ECG and 21 types of Arrhythmia’s. Connect the device with your smartphone using leads and electrodes and perform your test. It gives you the result within 30 seconds.
  • Page 19 Spandan device and single electrode can be used for 2 or 3 times. And in case if you have used your all electrodes you can buy it from market electrodes are easily available in the market. You can also buy the electrodes at www.sunfox.in.
  • Page 20 Spandan Healthy Heart Programme Spandan Application equipped with Special programme started to provides better guidance to use Spandan Portable ECG device. “Spandan Healthy Heart Programme” this feature provides the patient to go through the Blogs and Articles available about the different kinds of Arrhythmia, Leads Placements etc.
  • Page 21 Kinds of Arrhythmia Detection by Spandan Portable ECG Device 1. Atrial Rhythm 2. Atrial Flutter 3. Atrial Fibrillation 4. Atrial Tachycardia 5. A-V Block 6. Branch Bundle Block 7. Junctional Tachycardia 8. Junctional Rhythm 9. Polymorphic Ventricular Tachycardia 10. Slow Atrial Fibrillation 11.
  • Page 22 Kinds of heart dysfunctions detection by Spandan portable ECG device 1. AVNRT (Atrioventricular Nodal Re-entrant Tachycardia) 2. AVRT (Atrioventricular Re-entrant Tachycardia) Atrioventricular reentrant tachycardia (AVRT), or atrioventricular reciprocating 3. AT+BBB (Atrial Tachycardia Branch Bundle Block) Or Ab (Aberration) 4. Accessory Pathway 5.
  • Page 23 Sunfox technologies are bringing the future to the present. Spandan AI is the official AI module developed by engineers and researches of Sunfox to make detection of classified abnormalities like STMI and ST segment elevation. Equipped with the feedback technology,...
  • Page 24 other types of wasted and recycle its responsibility to promote the sustainable reuse of material resources. Household users should contact either the retailer where they purchased this product , or their local government office, for details of where and how they can return this item for environmentally safe recycling.

  • Page 25: Warranty Card

    • This limited warranty is available if the Spandan fails to function within normal tolerances due to defects in materials or internal defects during the specified warranty period. • Sunfox Technologies will inspect the Spandan and determine whether a warranty credit is due. Sunfox hold all the rights of warranty.
  • Page 26 • The warranty is against manufacturing defects only, therefore repair or replacement is on the sole discretion of the Sunfox, depending on whether the unit has been properly operated & handled during the warranty period, without any tampering. • The warranty covers none of the following: - Transport cost or risk of transport.
  • Page 27 Other Disclosures Sunfox Technologies does not warrant the suitability of a lead for any specific patient, since fitness for use is a medical decision. Sunfox Technologies will not be liable for any damages, whether direct, consequential, or incidental, caused by lead defects, failures, or malfunctions, whether such a claim is based on warranty, contract, tort, or otherwise.
  • Page 28 To avail warranty, signed & stamped warranty card from retailer and original invoice copy are required. Email us : care@sunfox.in Model No Sign & Stamp Serial No Date of purchase Purchase through Invoice Number...
